- Page 1 AlphaPC 164LX Motherboard Windows NT User’s Manual Order Number: EC–R2ZQE–TE This is a revised document. It Revision/Update Information: supersedes the AlphaPC 164LX Motherboard Windows NT User’s Manual (EC–R2ZQD–TE).
- Page 2 January 1998 ©Digital Equipment Corporation 1998. All rights reserved. Printed in U.S.A. AlphaPC, AlphaServer, DIGITAL, DIGITAL Semiconductor, and the DIGITAL logo are trademarks of Digital Equipment Corporation. DIGITAL Semiconductor is a Digital Equipment Corporation business. FaxBACK and Intel are registered trademarks of Intel Corporation.
-
Page 3: Table Of Contents
1–1 Features of the AlphaPC 164LX Motherboard Power Requirements .......... - Page 4 4.10 Input Power Connector Pinouts ........4–8 4.11 Enclosure Fan Power Connector Pinouts .
- Page 5 Troubleshooting Password Bypass ..........8–1 Hardware Startup .
- Page 6 2–7 3–1 AlphaPC 164LX Configuration Jumpers ....... . 3–2 5–1 Fan/Heat-Sink Assembly .
- Page 7 AlphaPC 164LX Features ........
-
Page 9: About This Manual
About This Manual This manual describes the AlphaPC 164LX motherboard, a module for computing systems based on the DIGITAL Semiconductor Alpha 21164 microprocessor and the companion DIGITAL Semiconductor 21174 core logic chip. It describes the motherboard’s features and how to set its configuration jumpers. This manual helps users to install and populate the AlphaPC 164LX motherboard with memory modules and peripheral cards. - Page 10 Manual Conventions and Terminology Italic Type: Italic type emphasizes important information and indicates complete titles of documents. Terms: The following terms are used in this manual: This term... Refers to... Microsoft Windows NT installation The Microsoft Windows NT Workstation guide Installation Guide and the Windows NT Server Installation Guide.
-
Page 11: Features Of The Alphapc 164Lx Motherboard
Features of the AlphaPC 164LX Motherboard Table 2–1 provides an overview of the AlphaPC 164LX motherboard’s features. Table 2–1 AlphaPC 164LX Features Feature Description Microprocessor DIGITAL Semiconductor Alpha 21164 microprocessor (64-bit RISC) Core logic chip DIGITAL Semiconductor 21174 core logic chip, comprising a sin-... -
Page 12: Alphapc 164Lx Jumper/Connector/Component Location
Figure 2–1 AlphaPC 164LX Jumper/Connector/Component Location Top: Mouse Top: COM1 Bottom: Keyboard Bottom: COM2 Denotes Pin #1 FM-05933.AI4 Features of the AlphaPC 164LX Motherboard 2–2... -
Page 13: Alphapc 164Lx Jumper/Connector/Component List
Table 2–2 AlphaPC 164LX Jumper/Connector/Component List Item No. Description Item No. Description RTC battery (CR2032) Hard-drive LED connector Soft power connector PCI slot 0 (64-bit) Fan power, enclosure (+12V) System configuration jumpers Power (+3V, +5V, -5V, +12V, -12V) Flash ROM update enable/disable... -
Page 14: Power Requirements
Power Requirements 2.1 Power Requirements The AlphaPC 164LX motherboard has a total power dissipation of 100 W, excluding any plug-in PCI and ISA devices. Table 2–3 lists the power requirement for each dc supply voltage. The power supply must be ATX-compliant. -
Page 15: Physical Parameters
Physical Parameters The AlphaPC 164LX motherboard is specified to run within the environment listed in Table 2–4. Table 2–4 AlphaPC 164LX Motherboard Environmental Requirements Parameter Specification Operating temperature 10°C to 40°C (50°F to 104°F) Storage temperature –55°C to 125°C (–67°F to 257°F) Relative humidity 10% to 90% with maximum wet bulb temperature 28°C... -
Page 16: Atx Hole Specification
Physical Parameters 2.3.1 ATX Hole Specification Figure 2–2 shows the ATX Hole Specification for the AlphaPC 164LX. Figure 2–2 ATX Hole Specification .800 TYP Between Connectors 4.900 .650 .500 1.612 .400 1.300 .600 PCI Connector .625 (4 Places) 8.950 6.100 9.600... -
Page 17: Atx I/O Shield Requirements
Physical Parameters 2.3.2 ATX I/O Shield Requirements Figure 2–3 shows the ATX I/O shield dimensions for the AlphaPC 164LX. Figure 2–3 ATX I/O Shield Dimensions R 1.00 21.36 16.05 5.00 TYP 9.25 3.58 2.45 4.35 11.15 15.47 14.96 17.95 22.95 23.96... -
Page 19: Alphapc 164Lx Jumper Configuration
AlphaPC 164LX Jumper Configuration The AlphaPC 164LX motherboard has two groups of jumpers located at J27 and J28, as shown in Figure 2–1. These jumpers set the hardware configuration and boot options. Figure 3–1 shows these jumper configurations. 3.1 CPU Speed Selection The clock synthesizer at location U47 makes it possible to change the frequency of the microprocessor’s system clock output without having to change the clock crystal. -
Page 20: Alphapc 164Lx Configuration Jumpers
Bcache Size Jumpers (CF1 and CF2) Figure 3–1 AlphaPC 164LX Configuration Jumpers J27 System Configuration Jumpers IRQ3 Frequency Ratio IRQ3 IRQ2 IRQ1 IRQ0 Comments IRQ2 466 MHz Out Out Default 533 MHz IRQ1 600 MHz IRQ0 All other combinations Reserved... -
Page 21: Password Bypass Jumper (Cf3)
Section 8.5. 3.5 Flash ROM Update Jumper (J28) When J28–2/3 are jumpered together (default), the flash ROM is write-enabled. When J28–1/2 are jumpered together, the flash ROM is write-protected. AlphaPC 164LX Jumper Configuration 3–3... -
Page 23: Alphapc 164Lx Connector Pinouts
AlphaPC 164LX Connector Pinouts This chapter contains pinouts for all of the AlphaPC 164LX connectors. See Figure 2–1 for connector locations. 4.1 PCI Bus Connector Pinouts Table 4–1 shows the PCI bus connector pinouts. Table 4–1 PCI Bus Connector Pinouts... - Page 24 D[54] D[52] D[50] D[48] D[46] D[44] D[42] D[40] D[38] D[36] D[34] D[32] — — — C/BE#[6] C/BE#[4] D[63] D[61] D[59] D[57] D[55] D[53] D[51] D[49] D[47] D[45] D[43] D[41] D[39] D[37] D[35] D[33] — — AlphaPC 164LX Connector Pinouts 4–2...
-
Page 25: Isa Expansion Bus Connector Pinouts (J30, J31)
SBHE# IOCS16# LA23 IRQ10 LA22 IRQ11 LA21 IRQ12 LA20 IRQ15 LA19 IRQ14 LA18 DACK0# LA17 DRQ0 MEMR# DACK5# MEMW# DRQ5 DACK6# DRQ6 SD10 DACK7# SD11 DRQ7 SD12 SD13 MASTER# SD14 SD15 — — — — AlphaPC 164LX Connector Pinouts 4–3... -
Page 26: Sdram Dimm Connector Pinouts (J8 Through J11)
DQ16 DQ17 DQ18 DQ19 DQ20 CKE1 DQ21 DQ22 DQ23 DQ24 DQ25 DQ26 DQ27 DQ28 DQ29 DQ30 DQ31 DQ32 DQ33 DQ34 DQ35 DQ36 DQ37 DQ38 DQ39 DQ40 DQ41 DQ42 DQ43 DQ44 DQ45 DQ46 DQ47 DQMB4 DQMB5 AlphaPC 164LX Connector Pinouts 4–4... -
Page 27: Eide Drive Bus Connector Pinouts (J6, J7)
Pins 1 through 84 are on the front side and pins 85 through 168 are on the back side. The AlphaPC 164LX uses BA1 as both BA1 and ADDR12. Therefore, four-bank DIMMs using ADDR[11:0] are the maximum size. (Two-bank DIMMs can use ADDR[12:0].) Pull-down. -
Page 28: Diskette Drive Bus Connector Pinouts
— 4.6 Parallel Bus Connector Pinouts Table 4–6 shows the parallel bus connector pinouts. Table 4–6 Parallel Bus Connector Pinouts (J13) Signal Signal Signal Signal BUSY SLCT INIT SLIN — — — — — — AlphaPC 164LX Connector Pinouts 4–6... -
Page 29: Com1/Com2 Serial Line Connector Pinouts (J4)
RTS1 RTS2 CTS1 CTS2 4.8 Keyboard/Mouse Connector Pinouts Table 4–8 shows the keyboard/mouse connector pinouts. Table 4–8 Keyboard/Mouse Connector Pinouts (J5) Keyboard Pin Mouse Pin (Top) Keyboard Signal (Bottom) Mouse Signal KBDATA MSDATA KBCLK MSCLK AlphaPC 164LX Connector Pinouts 4–7... -
Page 30: Input Power Connector Pinouts
This pinout is ATX-compliant. 4.11 Enclosure Fan Power Connector Pinouts Table 4–11 shows the enclosure fan power connector pinouts. Table 4–11 Enclosure Fan (+12 V dc) Power Connector Pinouts (J2, J19) Voltage +12 V dc AlphaPC 164LX Connector Pinouts 4–8... -
Page 31: Speaker Connector Pinouts
— FAN_CONN_L Fan connected — 4.14 Power LED Connector Pinouts Table 4–14 shows the power LED connector pinouts. Table 4–14 Power LED Connector Pinouts (J24) Signal Name POWER_LED_L Power LED input — — — — AlphaPC 164LX Connector Pinouts 4–9... -
Page 32: Ide Drive Led Connector Pinouts
The Halt button is not used with the Windows NT operating system. Note: 4.18 Soft Power Connector Pinouts Table 4–18 shows the soft power connector pinouts. Table 4–18 Soft Power Connector Pinouts (J1) Signal Name Input System power on/off — AlphaPC 164LX Connector Pinouts 4–10... -
Page 33: Memory And Microprocessor Configuration
5.1 Configuring SDRAM Memory Although not an exhaustive list, Table 5–1 lists the tested SDRAM memory configurations available. For a list of vendors who supply components and accessories for the AlphaPC 164LX, see Appendix A. Refer to Figure 2–1 for DIMM connector locations. -
Page 34: Upgrading Sdram Memory
16Mb 16Mb 5.2 Upgrading SDRAM Memory You can upgrade memory in the AlphaPC 164LX by adding more DIMMs or replacing the ones that you have with a greater size. Refer to Figure 2–1 for DIMM connector locations. Use the following general guidelines: 1. -
Page 35: Preparatory Information
Increasing Microprocessor Speed 5.3.1 Preparatory Information Caution: Static-Sensitive Component – Due to the sensitive nature of electronic components to static electricity, anyone handling the microprocessor must wear a properly grounded antistatic wriststrap. Use of antistatic mats, ESD approved workstations, or exercising other good ESD prac- tices is recommended. -
Page 36: Installing The 21164 Microprocessor
Increasing Microprocessor Speed 6. Remove the heat sink by gently lifting it off the microprocessor. 7. Remove and discard the GRAFOIL heat conduction pad. 8. Thoroughly clean the bottom surface of the heat sink before affixing it to the new microprocessor. 9. -
Page 37: Fan/Heat-Sink Assembly
Increasing Microprocessor Speed Figure 5–1 shows the Fan/Heat-Sink Assembly on AlphaPC 164LX. Figure 5–1 Fan/Heat-Sink Assembly Screw, 6-32 x 0.875 in Qty 4 Guard, Fan Clip, Heat Sink/Chip/Fan Nut, Hex, 1/4-20, 2011-T3 Aluminum, 0.438 in Across Flats, Qty 2 Torque to 20 +/- 2 in-lbs... - Page 38 Increasing Microprocessor Speed 3. Place the GRAFOIL pad on the gold-plated slug surface and align it with the threaded studs. b. Attach the microprocessor heat sink. The heat-sink material is clear anod- ized, hot-water-sealed, 6061-T6 aluminum. The nut material is 2011-T3 alu- minum (this grade is critical).
-
Page 39: Interrupts And Isa Bus Addresses
This section lists the system and I/O interrupt assignments. It also lists the physical AlphaPC 164LX I/O space assignments. 6.1 Interrupts Table 6–1 lists each AlphaPC 164LX ISA interrupt and its source. Table 6–1 ISA Interrupts (Sheet 1 of 2) -
Page 40: Isa I/O Address Map
Available IRQ14 IRQ15 The # symbol indicates an active low signal. 6.2 ISA I/O Address Map Table 6–2 lists the AlphaPC 164LX ISA I/O space address mapping. Table 6–2 ISA I/O Address Map Range (hex) Usage 000-00F 8237 DMA #1... -
Page 41: Flash Rom Address Map
ISA I/O Address Map 6.2.1 Flash ROM Address Map The address range for the flash ROM is FFF8.0000–FFFF.FFFF. Flash space of 1MB is obtained by double mapping this 512KB space. FLASH_ADR19 register at I/O location 800 provides this function. Writing a 0 to this location enables the lower 512KB of flash. -
Page 43: Configuring For Windows Nt
The online documentation describes configuration information for Alpha systems running AlphaBIOS. The online documentation resides on a diskette labeled AlphaPC 164LX AlphaBIOS Firmware diskette. The documentation is available as a text file and a Help file compatible with Windows NT 4.0 and Windows 95. -
Page 44: Alphabios Conventions
AlphaBIOS 7.1.1 AlphaBIOS Conventions AlphaBIOS uses universally accepted keys and key combinations for navigating the interface and selecting items. If you are familiar with MS-DOS or Microsoft Windows keyboard conventions, navigating AlphaBIOS is simple. Table 7–1 shows the keys to use for navigating and selecting items in AlphaBIOS. Table 7–1 Action Keys Press... -
Page 45: Upgrading Alphabios
AlphaBIOS Figure 7–1 AlphaBIOS Boot Screen AlphaBIOS Version 5.11 Please select the operating system to start: Windows NT Workstation 4.00 Windows NT Workstation 3.51 to move the highlight to your choice. Press Enter to choose. Alpha Press <F2> to enter SETUP FM-05954.AI4 7.1.3 Upgrading AlphaBIOS As new versions of Windows NT are released, it might be necessary to upgrade... -
Page 46: Performing Cmos Setup Tasks
AlphaBIOS 7.1.4 Performing CMOS Setup Tasks CMOS Setup is divided into two modes, standard and advanced. Table 7–2 lists the tasks that you can perform in standard and advanced setup mode. Table 7–2 CMOS Setup Tasks Standard CMOS Setup Advanced CMOS Setup Autostart Memory test Date and time... -
Page 47: Displaying Your System Configuration
AlphaBIOS To perform express hard-disk setup: 1. Start AlphaBIOS Setup, select Hard Disk Setup, and press Enter. 2. Press F7 to enter express hard-disk setup. 3. Press F10 to continue with the setup. For information on manually managing hard disks, see the online documentation. 7.1.6 Displaying Your System Configuration You can use AlphaBIOS to display your system configuration in a clear, easy-to-read format, organized by categories: system board, memory, hard disk, PCI, SCSI, and... -
Page 48: Display System Configuration
AlphaBIOS Figure 7–2 Display System Configuration Display System Configuration Systemboard Configuration Use the Arrow or Tab keys to view Hard Disk Configuration different categories PCI Configuration of configuration EISA Configuration information. SCSI Configuration MC Bus Configuration Memory Configuration Server Management Features Integrated Peripherals System Type: AlphaServer 4100/500... -
Page 49: Running A Maintenance Program
AlphaBIOS 7.1.7 Running a Maintenance Program You can run maintenance programs such as RAID and other configuration utilities directly from the AlphaBIOS utility menu. To run a maintenance program: 1. Start AlphaBIOS Setup, select Utilities, select Run Maintenance Program from the submenu shown in Figure 7–3, and press Enter. -
Page 50: Installing The Windows Nt Operating System
7.2 Installing the Windows NT Operating System This section supplements the Microsoft Windows NT installation guide for installing the Windows NT operating system on an AlphaPC 164LX system. If you already have a previous version of Windows NT installed, see the Microsoft Windows NT installation guide for information about how to upgrade to a new ver- sion of the operating system. -
Page 51: Requirements
The AlphaPC 164LX AlphaBIOS Firmware diskette • The AlphaPC 164LX Windows NT 4.0 Installation diskette The AlphaPC 164LX Windows NT 4.0 Installation diskette is required Note: for the Windows NT 4.0 operating system. Future versions of Windows NT may not require this diskette. Contact your OEM or system vendor for details. -
Page 52: Starting Windows Nt Setup
During the Windows NT installation procedure, you may be prompted for the type of computer that you have. For the AlphaPC 164LX system, choose DIGITAL AlphaPC 164LX. If AlphaPC 164LX is not one of the choices, choose “other” after you have inserted the AlphaPC 164LX Windows NT 4.0 Installation diskette. The following procedure supersedes the Starting Setup on a RISC-based Computer sec- tion of the Microsoft Windows NT installation guide. -
Page 53: Troubleshooting
Troubleshooting This chapter contains information about troubleshooting hardware and software during AlphaPC 164LX startup. 8.1 Password Bypass AlphaBIOS provides password protection. However, Password Bypass is provided for system setup or startup when the AlphaBIOS password is unavailable. Password Bypass is enabled by inserting jumper CF3 in the J27 System Configuration Jumper Block (see Figure 3–1). -
Page 54: Beep Codes
Beep Codes 8. Reseat the DIMMs. 9. Replace the DIMMs. 8.3 Beep Codes The beep codes provide error information about the AlphaPC 164LX system. Table 8–1 lists and describes the beep codes. Table 8–1 Beep Codes Beep Code Description 1–2–3 This sequence represents the fail-safe booter startup. -
Page 55: Fail-Safe Booter
1-2-3; that is, one beep and a pause, followed by two beeps and a pause, followed by three beeps. After the diskette activity light flashes, insert the AlphaPC 164LX AlphaBIOS Firmware diskette. The fail-safe booter will load and run AlphaBIOS from this diskette. -
Page 56: Windows Nt Startup
1. Power off your system. 2. Add jumper CF7 as described in Section 3.4. 3. Power on your system. 4. Insert the AlphaPC 164LX AlphaBIOS Firmware diskette into the diskette drive. 5. Proceed to Section 7.1.3 and follow the procedures. -
Page 57: Battery Recycle/Disposal Information
Battery Recycle/Disposal Information NOTICE Recycle or dispose of batteries promptly in accordance with your organization’s environmental policies. If this is a LITHIUM battery, the following additional pre- cautions may apply: • Replace batteries correctly to prevent possible explosion. • Replace batteries with the same or equivalent type. •... -
Page 59: Supporting Products
Supporting Products This appendix lists sources for components and accessories that are not included with the AlphaPC 164LX. For the latest information, visit the Alpha website at URL: http://www.alpha.digital.com. Click on Motherboard Products. The hardware compatibility list (HCL) and the qualified-memory vendor list are also available at this location. - Page 60 Memory Kingston Technology Company 17600 Newhope Street Fountain Valley, CA 92708 Phone: 1-800-845-2545 Micron Semiconductor Products, Inc. 8000 South Federal Way Mail Stop 607 Boise, ID 83706 Phone: 208-368-3900 Fax: 208-368-5018 NEC Electronics, Inc. The Meadows Building, 4th Floor 161 Worcester Road Framingham, MA 01701 Phone: 508-935-2000 Fax: 508-935-2233...
-
Page 61: Thermal Products
2859 Bayview Drive Fremont, CA 94538 Phone: 510-770-1200, ext. 312 PN PP-253V (250 W) A.4 Enclosure An enclosure, suitable for housing the AlphaPC 164LX and its power supply, is available from: Axxion Group Corporation 7801 Trade Center Avenue El Paso, TX 79912... -
Page 63: Associated Documentation
Associated Documentation You can order the following associated documentation directly from the vendor. Title Vendor Alpha AXP Architecture Reference Manual Call your local distributor or call PN EY–T132E–DP Butterworth-Heinemann (DIGITAL Press) at 1-800-366-2665 Alpha Architecture Handbook See previous entry PN EC–QD2KB–TE DIGITAL Semiconductor 21164 Alpha Digital Equipment Corporation Microprocessor Hardware Reference Manual... - Page 64 Title Vendor 82420/82430 PCIset ISA and EISA Bridges Intel Corporation (includes 82378IB/ZB SIO) (PN 290483) Literature Sales P.O. Box 7641 Mt. Prospect, IL 60056 Phone: 1-800-628-8686 FaxBACK Service: 1-800-628-2283 BBS: 1-916-356-3600 Super I/O Combination Controller Standard Microsystems Corporation (FDC37C935) Data Sheet 80 Arkay Drive Hauppauge, NY 11788 Phone: 1-516-435-6000...
