Eusso UGL2430-U2H2 User Manual

Ieee 802.11b/g/n wireless-n usb adapter

Advertisement

Quick Links

IEEE 802.11b/g/n
UGL2430-U2H2
Wireless-N USB Adapter
USER'S GUIDE
VERSION 1.0
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
This manual may not be copied in any media or form without the written consent of original maker.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UGL2430-U2H2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eusso UGL2430-U2H2

  • Page 1 IEEE 802.11b/g/n UGL2430-U2H2 Wireless-N USB Adapter USER’S GUIDE VERSION 1.0 © All rights reserved. All trade names are registered trademarks of respective manufacturers listed. This manual may not be copied in any media or form without the written consent of original maker.
  • Page 2 Information To User ..........…….. 1. Introduction ............…… 1 2. Wireless LAN Basics ..........……. 3 3. IP ADDRESS ............……. 4 4. Install Driver/Utility ..........……. 5 4.1 Windows XP/Vista..........5 5. Wireless Network Configuration ........7 5.1 Utility Icon ............7 5.2 Client Mode (Default Setting)........7 6.
  • Page 3: Information To User

    INFORMATION TO USER Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 Europe- R&TTE Compliance Statement Hereby, the company who declares that this equipment complies with the essential requirements and other relevant provisions of DIRECTIVE 1999/5/CE OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment telecommunication terminal Equipment mutual recognition of their conformity (R&TTE).
  • Page 5 The channel identifiers, channel center frequencies, and regulatory domains of each 22-MHz-wide channel are shown in following Table. Regulatory Domains Frequency Channel Identifier (MHZ) France North Japan ETSI Israel Mexico Outdoor America 2412 ˇ ˇ ˇ ˇ 2417 ˇ ˇ ˇ...
  • Page 6: System Requirements

    Thank you for your purchase of the Wireless-N USB Adapter. Featuring wireless technology, this wireless networking solution has been designed for both large and small businesses, and it is scalable so that you can easily add more users and new network features depending on your business scale. FEATURES Support Microsoft XP(32bit/64bit) / Vista(32bit/64bit).
  • Page 7 Wireless LAN network defined by IEEE 802.11b/g standard committee could be configured as : Ad Hoc wireless LAN. Infrastructure wireless LAN. Ad Hoc network is a group of PCs installed with wireless LAN cards, this group of PCs is called a BSS (Basic Service Set). PCs in this group can use their wireless LAN cards to communicate with each other, but can not connect to the Internet.
  • Page 8: Properties Dialog Box

    To use the Wireless-N USB Adapter with a computing device, the Wireless-N USB Adapter must be equipped with a proper Interface. All drivers and supporting software for the Wireless-N USB Adapter must be installed and configured first. Ask your system administrator for the following information, which you may need to provide during driver installation : Your Wireless Client Name, Your Wireless SSID.
  • Page 9 The installation & driver CD will automatically activate the autorun installation program after you insert the disk into your CD drive. Step 1 Insert the installation CD into your CD-ROM. Choose the Setup Language and click Next button. Step 2 : Installation descriptions shown.
  • Page 10 Installing & configuring WLAN utility Installing Drivers. Step 3 : Click Finish to complete installation...
  • Page 11 Wireless-N USB Adapter uses its own management software. All functions controlled by users are provided by this application. When you insert the WLAN Adapter into your laptop or desktop, a icon should appear in the Windows System Tray automatically. 5.1 Utility Icon ▓...
  • Page 12: General Setting

    5.2.1 GENERAL SETTING Once device is set, double click on that icon and the configuration window will pop up as shown. It shows the current connected network. The signal strength and link quality are displayed also. The bar graph displays the quality and strength of the link between the node and its Access Point.
  • Page 13 5.2.3 AVAILABLE NETWOEK SETTING Click Available Network tab and it will show all available networks that radio can reaches. Select proper SSID & BSSID you want to connect. Click Refresh button to force and rescan available networks currently. Select one of SSIDs, and click Add to Profile to create profile that can be...
  • Page 14 5.2.5 Statistics Statistics page tab will show real-time TX/RX relative counters to check or evaluate the wireless performance. Click Reset button to set counter to zero. 5.2.6 Wi-Fi Protected Setup An easy and secure setup solution for Wi-Fi network. you can choose PIN Code or Push Button method to connect to an AP.
  • Page 15 Step 2 : Select a specific AP Step 3 : Enter the PIN code into your AP. Step 4 : Select AP that you want to configure. Step 5 : Wait for configuring your wireless AP to be the security setting.
  • Page 16 ▓ PBC method: Step 1 : Push the PBC button. Step 2 : Push the physical button on your AP or visual button on the WPS config page.
  • Page 17 Product Name Wireless-N USB Adapter (1T2R) Standard 802.11b/g/n, 802.3, 802.3u Data Transfer Rate 1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,90,120,180,240,270 and maximum of 300Mbps Modulation Method BPSK/ QPSK/ 16-QAM/ 64-QAM/ DBPSK/ DQPSK/ CCK Frequency Band 2.4GHz ISM Band Spread Spectrum IEEE 802.11b: DSSS (Direct Sequence Spread Spectrum) IEEE 802.11g/n:OFDM (Orthogonal Frequency Division Multiplexing) RF Output Power...
  • Page 18 Symptom The LED is off. Remedy Make sure the PC Card is inserted properly. Otherwise contact your vendor. Symptom : The LED is always on not blinking. Remedy Make sure that you have installed the driver from attached CD. Otherwise contact your vendor.
  • Page 19 IEEE 802.11 Standard IEEE 802.11 Wireless standards subcommittee, which formulating a standard for the industry. Access Point An internetworking device that seamlessly connects wired and wireless networks together. Ad Hoc An Ad Hoc wireless LAN is a group of computers, each with a Wireless-N USB Adapter, connected as an independent wireless LAN.
  • Page 20: Temporal Key Integrity Protocol (Tkip)

    IEEE Institute of Electrical and Electronics Engineers Infrastructure An integrated wireless wired called Infrastructure configuration. Infrastructure is applicable to enterprise scale for wireless access to central database, or wireless application for mobile workers. ISM Band The FCC and their counterparts outside of the U.S. have set aside bandwidth for unlicensed use in the so-called ISM (Industrial, Scientific and Medical) band.
  • Page 21: Transmit / Receive

    Transmit / Receive The wireless throughput in Bytes per second averaged over two seconds. Wi-Fi Alliance The Wi-Fi Alliance is a nonprofit international association formed in 1999 to certify interoperability of wireless Local Area Network products based on IEEE 802.11 specification. The goal of the Wi-Fi Alliance’s members is to enhance user experience...
  • Page 22: Fragment Threshold

    Fragment Threshold The proposed protocol uses the frame fragmentation mechanism defined in IEEE 802.11 to achieve parallel transmissions. A large data frame is fragmented into several fragments each of size equal to fragment threshold. By tuning the fragment threshold value, we can get varying fragment sizes. The determination of an efficient fragment threshold is an important issue in this scheme.
  • Page 23 WPA2 It is the second generation of WPA. WPA2 is based on the final IEEE 802.11i amendment to the 802.11 standard. Temporal Key Integrity Protocol (TKIP) The Temporal Key Integrity Protocol, pronounced tee-kip, is part of the IEEE 802.11i encryption standard for wireless LANs. TKIP is the next generation of WEP, the Wired Equivalency Protocol, which is used to secure 802.11 wireless LANs.
