Page 1: User Guide
User Guide VoIP Telephone with PoE Model No.: SP5102 World Wide Web: www.micronet.com.tw ; www.micronet.info... -
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ............. 5 Packet Content....................5 Key Features ....................5 Telephone Appearance .................. 7 Key Definition....................9 Keys with “123” number mode ..............11 Keys with “ABC” character mode .............. 12 Keys with “abc” character mode..............13 Menu Keys .................... - Page 3 3.1.1 Received ......................24 3.1.2 Dialed Calls .......................25 3.1.3 Missed .......................25 3.1.4 Delete All ......................26 Phone Book ....................27 3.2.1 New Entry ......................27 3.2.2 View Entry ......................28 3.2.3 Search Entry......................29 3.2.4 Memory Check ....................29 Networking Setting ..................30 3.3.1 IP Mode ......................30 3.3.2 IP Address ......................30 3.3.3...
- Page 4 Power on and Initialization................42 Making Calls ....................42 4.2.1 OFF-HOOK Dialing....................42 4.2.2 Redial (OFF-HOOK Dialing) ................42 4.2.3 Pre-Dial ......................42 4.2.4 Redial (ON-HOOK Dialing) ................43 4.2.5 Dial during connected ..................43 4.2.6 Memory Dial ......................43 Answer Calls ....................44 4.3.1 Answer the call in the ringing state ..............44 4.3.2 Answer the call in the connect state...............44 Hold and Retrieve Calls ................
- Page 5 [quit] command .................... 79 [debug] command ..................80 [reboot] command ..................81 [pbook] command ..................82 [commit] command ..................83 [ping] command ................... 84 [time] command ................... 85 [ifaddr] command..................86 6.10 [pppoe] command ..................88 6.11 [flash] command ..................89 6.12 [sysconf] command ..................
-
Page 6: Introduction
Micronet SP5102 VoIP desktop telephone integrates DSP/codec system-on-chip solutions to provide the industry’s highest voice quality. For ease-of-use functionality, SP5102 provides well compatibility with many well-known IP-PBX, rich telephony features, and many user-friendly function buttons of conference, call pickup, transfer, redial, Hold …etc. Moreover, Power-over-Ethernet technology (IEEE 802.3af) is incorporated in SP5102. - Page 7 ● Support QoS to ensure voice quality ● Cost-effective, suitable for pure VoIP environment...
-
Page 8: Telephone Appearance
1.3 Telephone Appearance Front View Bottom shell... -
Page 10: Key Definition
1.4 Key Definition KEYPAD FUNCTION 1. Press this key to confirm a menu selection, a setting, or a phone entry. 2. When in menu mode, pressing this key will select the menu selection highlighted. 3. When entering phone setting or menu selection entry, pressing this key will confirm the entry. - Page 11 KEYPAD FUNCTION Missed calls Missed Voice Mail Blind transfer Blind Tran Mute Mute Headset mode switch Headset Conference Conf Call Pickup Pick Transfer Trans Redial Redial Call hold / Call retrieve Hold This phone could support three methods for the text input, such like this: “123”, “ABC”, “abc”.
-
Page 12: Keys With "123" Number Mode
1.5 Keys with “123” number mode Users could only enter the digits in the “123” mode as following: Numbers in “123” input method ＊ Input method switch key... -
Page 13: Keys With "Abc" Character Mode
1.6 Keys with “ABC” character mode Users could enter the characters with the uppercase in this mode. The key could only input the special symbols and press more times to pick up the symbols you want. If users press two times on the key , the input character will be E. -
Page 14: Keys With "Abc" Character Mode
1.7 Keys with “abc” character mode Users could enter the characters with the uppercase in this mode. The key could only input the special symbols and press more times to pick up the symbols you want. If users press two times on the key , the input character will be e. -
Page 15: Menu Keys
1.8 Menu Keys There are four keys to help users enter, exit or pick up the configuration tables for changing. Please check out the following info: Functions descriptions Press the right arrow key in the IDLE mode to enter the main menu. -
Page 16: Start Up
2. Start Up 2.1 Installation Using Power over Ethernet (PoE), which uses standard twisted-pair cable to convey electricity to IP phones, wireless access points and other devices, is ideal. PoE isn’t a new idea. Utilities have been putting power and voice over the same lines for decades, but until recently it wasn’t widely used for data networks. -
Page 17: Lcd Display
2.2 LCD Display 2.2.1 LCD Display in initializing mode 1970/01/01 00:00 Status during the system initializing Initializing… 2.2.2 LCD Display in IDLE state Displaying in the IDLE mode while the network and 2006/05/10 10:10 registration were ok. (User can change display name SipPhone SP5101 from SIP configuration) 2006/05/10 10:10... -
Page 18: Lcd Display In Disconnected State
LCD Display in DISCONNECTED state 2006/05/10 10:10 After the remote side sends the BYE message, SipPhone LPSP5102 will automatically return IDLE state. SP5102 2.2.5 LCD Display for RINGING state Incoming call… Incoming call with the calling name or number 2.2.6 LCD Display for DIALING state Line 1 Dialing…... -
Page 19: Lcd Display In Call Waiting State
Mute… The timer will still go on while the mute function was 00:00:10 enabled during the conversation. Transfer… Transfer action during the call. Hold… Hold the established call. Parking… Parking the call. In Conference….. Enable the conference function and start the timer 00:10:10 from the beginning. -
Page 20: Lcd Display For Saving And Rebooting Mode
2.2.11 LCD Display for saving and rebooting mode Saving… Saving the configurations while users had be changed Rebooting… Users reboot this unit from the remote side Rebooting? Request for the keypad pressing to reboot Please Wait… Users reboot this unit by the keypad pressing 2.2.12 LCD Display for edit mode The characters and digits were entered from the left to the right side. -
Page 21: Editing Display
2.3 Editing Display a Cursor Under the characters or digits, the cursor will be displayed and the characters or digits will be blinking. It was shown as “_” with the LCD showing. Users could press the right or left arrow keys to make the cursor move to the right or left side. -
Page 22: Led Display
2.4 LED Display While users power on this phone set, all the LED will be lighted up before the system initializing procedure finished. The function LED will be light while users press the function keys; and will be blink while users press the function keys for twice. - Page 23 hook/speaker button. When having incoming call, press HEADSET button can pick up call and press again can hang up call. 3. When in communication, press HEADSET button can switch voice path to headset.
-
Page 24: Lcd Menu Operation
3. LCD Menu Operation During the menu operation, there is no cursor for the configuration tables selecting. The LCD will show just like this: >Call Records >Phone Book Users could press the up or down arrow keys to move on different item. This sign will guide you to choose the configuration tables. -
Page 25: Received
3.1.1 Received Showing the received calls; pressing the button to check out the other received calls. >Received Calls >John → → >Dialed Calls >12345678 The LCD will show as following while there is no any record for the received calls: No Records!! ●... -
Page 26: Dialed Calls
entry added, show all the entries in the phone book to verify by users. If users press the button, the flow will be just like the actions in the phone book >John >Dial Out → → → → >12345678 >Detail >Dial Out >Detail →... -
Page 27: Delete All
3.1.4 Delete All This will delete all the records of the received, dialed and missed calls. Delete it? Delete ok… → →... -
Page 28: Phone Book
3.2 Phone Book This phone set could support 90 entries of the phone book. Users could add, modify, delete, and dial out all the entries in the phone book. If the name and number had been added in the phone book, the LCD has to show the name if it is the incoming call. -
Page 29: View Entry
following and return to the New Entry table after a few seconds: Invalid Input… >New Entry >View Entry → B Input Number After users enter the valid name for the New Entry, the LCD will show as following and it only supports the number typing in this mode: Input Name Input Number →... -
Page 30: Search Entry
Press on specific phone book entry, phone will be off-hook and dial out automatically. Modify Entry Here user can modify name and number of existed phone book data. Delete Entry Delete it? Delete ok… → → Detail Press to see detail name and number of this phone book entry. 3.2.3 Search Entry This mode could support the numbers or characters typing. -
Page 31: Networking Setting
3.3 Networking Setting IP Mode Fixed DHCP PPPoE IP Address Net Mask Default GW DNS Setting Primary DNS Second DNS PPPoE Password Reconnect SNTP SNTP Server IP Time Zone Mode 3.3.1 IP Mode Press the button to select the IP mode. 3.3.2 IP Address Enter IP address for Fixed IP mode. -
Page 32: Default Gw
3.3.4 Default GW All the operation is just like the IP Address configuring. It will be shown as following from the LCD: Default GW: 10.1.1.254 If users input the invalid value for the IP address, Net Mask or Default Gateway, LCD will show as following and return to the original setting of this configuration table: Invalid Input…... -
Page 33: Sntp
Password For the protecting policy, LCD will use the asterisk to replace the info showing. Password: ***** For the password modify displaying, the LCD will clean all the asterisks and showing the cursor as following: Password: Password: → → → ***** Modify? Password:... -
Page 34: Time Zone
Time Zone Pressing the for decreasing and for increasing the zone value. button will save the changed. Zone: +8:00... -
Page 35: Sip Setting
3.4 SIP Setting All the menu operations are as same as the Networking setting. Proxy Setting Proxy IP Proxy Port OutPx IP OutPx Port User Setting Password Phone Num Local Port 3.4.1 Proxy Setting 3.4.1.1. Proxy IP It could support the number and character typing for the IP or domain. Proxy IP: Proxy IP: 10.1.1.2... -
Page 36: User Setting
3.4.2 User Setting 3.4.2.1. ID It could support the number or character typing for the ID. RegID: 3.4.2.2. Password It could support the number or character typing for the ID. LCD will show the asterisks to replace the password. RegPwd: For the modify displaying, the LCD will empty the all the asterisks and showing the cursor as following: Password:... -
Page 37: Phone Setting
3.5 Phone Setting Alarm Setting View All Del All Ring Setting Ringer Volume Volume 1 Volume 2 Volume 3 Volume 4 Ringer Melody Melody 1 Melody 2 Melody 3 3.5.1 Alarm Setting There are some definitions for the Alarm clock, please check out the detail as following: If the alarm clock had been set and the time is up: The phone will be ring in the IDLE and MENU state only. - Page 38 If users enter the incorrect month or date, please show the message as following and back to the original page: Invalid Input… >New Entry → → >View All Switch to the Time setting while users press the button in the Date setting: Set Date: Set Time:...
-
Page 39: Ring Setting
>View All >Delete All 3.5.2 Ring Setting 3.5.2.1. Ringer Volume There are four levels for the volume adjustment and the default is level 2. The symbol “>” will point out the current level for this phone set. Pressing the button to select the volume level for the ring. >Volume 1 >Volume 2 →... -
Page 40: Mail Box
3.6 Mail Box Information MailBox No. MailBox Key Voice Mail Dial 3.6.1 Information If VNS LED lights up, you can view voice mail information from this item. Below: Information: 2 new, 1 old 3.6.2 MailBox No. 3.6.3 MailBox Key 3.6.4 Voice Mail Dial... -
Page 41: Function Keys
3.7 Function Keys New Entry Input Number Press the key… From PhoneBook Phone Book List Press the key… View Entry Function Key list Users could configure the Function Keys for the speed dial or special IP-PBX function. For the function keys configuration, users could input the new number or select the entries from the Phone Book. -
Page 42: Reboot
3.8 Reboot Reboot? Please Wait… → →... -
Page 43: Basic Function
4. Basic Function 4.1 Power on and Initialization During the initialization procedure: All the LED will light on till the initialization procedure was finished. All the LED will light on if there is error during the procedure. On LCD will show “Initializing”. 4.2 Making Calls There are some ways to make outgoing calls: OFF HOOK Dialing... -
Page 44: Redial (On-Hook Dialing)
mode. During the Pre-dial function: This is permitted to enter and dial out the digits “*” and “#”. If the dialed number could be matched with the list in the phone book, LCD will display the name of this record. 4.2.4 Redial (ON-HOOK Dialing) This will show all the records of the dialed list. -
Page 45: Answer Calls
4.3 Answer Calls The LCD will show up the name if the incoming calls could be matched with the records from the phone book; or show the phone number if couldn’t find out the records. 4.3.1 Answer the call in the ringing state User can press Speaker button, Line button, or pick up handset to answer the incoming call. -
Page 46: Hold And Retrieve Calls
4.4 Hold and Retrieve Calls There are two ways to hold the current calls and retrieve them back: Press another idle line button to hold the current line and switch to another IDLE line. Press the Hold function keys to hold the current calls. During the hold status, the LED of Line will flash. -
Page 47: Transfer
4.5 Transfer SP5102 could support the call transfer with two types, one is the Consultant, and another is the Blind transfer. The transfer could be initialized only for the state as above. Dial another call during the connect state Answer another call during the connect state 4.5.1... -
Page 48: Conference
4.6 Conference User needs to specify conference function to be local conference or server-based conference. Conference Scenario: A. Local Conference: (1) A communicate with B→Conf or Line hear dial tone+ C’s number→C pick up → press Conf again to build conference (2) A communicate with B→Conf or Line hear dial tone+ C’s number→C refuse to join conference →... -
Page 49: Web Administration
5. Web Administration 5.1 Factory Default DESCRIPTION DEFAULT VALUE 10.1.1.3 Net Mask: 255.255.0.0 Default Gateway: 192.168.1.254 SIP Proxy: 10.1.1.2 SIP account 1001 SIP Port: 5060 Proxy Port: 5060 RTP Port: 16384 Digit Timeout: Call waiting: Call transfer... -
Page 50: Configuring The Sip Phone Through Web
5.2 Configuring the SIP Phone through Web Pages The HTTPD web management interface provides user an easier way to configure rather than command line method through TELNET. The configuration function and steps are similar with the way through command line. Please refer to the chapter 4-Configuring the SIP Phone through Telnet command lines for more detail information. - Page 51 Step 2. Input the login name and password Login name: root / user Note: Login with “user” only has authority as below: 1. Modify network configuration 2. Modify Phone Book 3. Change login password of “user” 4. Reboot Password (The same with TELNET): Null (just press confirm, no need to key in password in default value) Note: User can set password later via web interface.
- Page 52 Step 3. Enter the web interface main screen After enter login name and password, user can see web interface main screen as below. Step 4. Start to configure After enter web management interface, user can see four main items. 1. Installation Wizard: User can follow steps in wizard to make first-time initial configuration.
-
Page 53: Installation Wizard
5.3 Installation Wizard Installation Wizard includes three steps: (A) Network Connection Mode: User has to select SIP Phone network mode as Static IP, DHCP or PPPoE. - Page 54 (B) Network Configuration: After selecting network connection mode, user has to input related network parameters. (1) Static IP: User has to input IP, subnet mask, default gateway, and DNS server address. (2) PPPoE: User has to input PPPoE connection user name and password.
- Page 55 (C) Protocol Configuration: After setting network, user has to set SIP related parameters. Primary Proxy Address and port: If user select Proxy mode in item A, please input Primary Proxy address and signaling port of Proxy. Secondary Proxy Address and port: User can also input secondary Proxy server and port for backup.
-
Page 56: Advanced Configuration
5.4 Advanced Configuration 5.4.1 Network Configuration (1) Network Configuration Network Connection Mode: User has select network configuration mode first, then configuration page will display related items. (a) Static IP: If user selects Static IP mode, following items will be displayed. IP Address: Set IP Address of SIP Phone Subnet Mask:... - Page 57 address here. HTTP Port for WEB Management: Set port number for user to configure SIP Phone via WEB management. Default value is 80.
- Page 58 (c) PPPoE: If user selects PPPoE mode, following items will be displayed. DNS Server Obtained Mode: When SIP Phone is in DHCP or PPPoE mode, user can determine DNS address is obtained from server or set manually. Primary DNS Server: If user determines to set DNS address manually, please set Primary Domain Name Server IP address here.
- Page 59 (2) Behind NAT Behind IP Sharing: Select if enable SIP Phone behind IP Sharing router function. IP Sharing Public IP Address: Set Public IP Address of IP Sharing router for SIP Phone to work behind IP sharing. STUN Server address: If user wants to use STUN function, user must enable Behind NAT Device function then inputting STUN Server address.
- Page 60 (3) SNTP SNTP Mode: Enable / Disable the Simple Network Time Protocol function SNTP Server Address: Set SNTP Server Address. When SNTP server is available, enable SIP Phone SNTP function to point to SNTP server IP address so that SIP Phone can get correct current time.
-
Page 61: Sip Configuration
5.4.2 SIP Configuration (1) SIP Main Configuration Primary Proxy Address and port: If user select Proxy mode in item A, please input Primary Proxy address and signaling port of Proxy. Secondary Proxy Address and port: User can also input secondary Proxy server and port for backup. Outbound Proxy Address and port: User can input outbound Proxy and port if necessary. -
Page 62: System Configuration
5.4.3 System Configuration (1) Feature Configuration: Inter Digit Time: Set the DTMF inter digit time (second). To set the duration (in second) of two pressed digits in dial mode as timed out. If after the duration user hasn’t pressed next number, SIP Phone will dial out all number pressed. - Page 63 (2) Functional Key Configuration: Conference : Set the Conference mode. Default: Local Conference. But now it is not support Server Conference mode yet! Group Pick up: Set Group Pick up code, you might contact with your IP-PBX system administrator. Specific Pick up: Set Specific Pick up code, you might contact with your IP-PBX system administrator.
-
Page 64: Number Configuration
5.4.4 Number Configuration (1) Phone Book Add Data: User can specify 50 sets of phone book via web interface. Please input index, Name, E.164 number, IP Address, port of the destination device, drop prefix, and insert number. 1. name: Specify name for one pbook data 2. - Page 65 (2) Hotline If user set SIP Phone as hotline mode, once SIP Phone is off-hook, it will automatically dials phone number (Proxy Mode) set in hotline table.
- Page 66 (3) Digit Manipulation add: Add a rule to drop or insert prefix digits of incoming call. prefix: Set which prefix number to implement digit manipulation rule. drop: Enable or disable drop function. If this function is enabled, Phone will drop prefix number on incoming call. insert: Set which digit to insert.
-
Page 67: Media Configuration
5.4.5 Media Configuration (1) Codec Codec Priority: set codecs priority in order. Please notice that user can set from 1 to 5 codecs as their need. For example, user can only set first priority as G.723.1, and set the others as x, that means only G.723.1 is available. - Page 68 (2) Voice Volume: Adjust the volume of Ringer, Receive (Local side hearing), transmit (remote side hearing), DTMF. Echo Cancel: Enable / Disable (it is suggested to always Enable this function).
- Page 69 (3) Tone Configuration Ring Back Tone: Set ring back tone parameters. Busy Tone: Set busy tone parameters. Dial Tone: Set dial tone parameters. Dial Tone: Set 2 dial tone parameters. Ring Tone: Set ring tone parameters.
- Page 70 (4) Payload Type RFC2833 Payload Type: Change RFC2833 Payload type. This is for special request from the other site, if RFC2833 payload types of 2 sites are different, it may cause some problem of connection.
-
Page 71: Device Management
5.4.6 Device Management (1) Login Password Change password configuration: First select login name as root or user, then enter current password, new password and confirm new password again to set new password. - Page 72 (2) Software Upgrade Download Mode: Select download method as TFTP or FTP TFTP/FTP Server IP Address: Set TFTP server IP address FTP Login: Set FTP login name and password Target File name: Set file name prepared to upgrade Target File Type: Select which sector of SIP Phone to upgrade Note: After upgrade Application, please remember to execute Flash Clean, which will clean all configurations become factory values except Network settings.
- Page 73 (3) Provision Server Provision Server Address: set Provision server IP address. Provision Server Login User Name: set Provision Server login user ID. Provision Server Login User Password: set Provision Server login user password. Provision Server Cycle Time: set Provision Server update cycle time.
- Page 74 (4) Flash Clean Press CLEAN will clean all configurations except Network Configuration of SIP Phone and reset to factory default value. Note: User must re-configure all commands all over again (except Network Configuration).
-
Page 75: System Status
5.5 System Status 5.5.1 Network Status Display all current network status of SIP Phone. -
Page 76: Version Information
5.5.2 Version Information: Display software version. -
Page 77: Reboot
5.6 Reboot Press reboot will reset SIP Phone. Note: To execute reboot via web browser, SIP Phone will automatically save all data before reboot. To execute reboot via TELNET command, please remember to do Commit Data before Reboot System. -
Page 78: Telnet Command Lines
6. Telnet command lines After setting the IP Address of SIP Phone and reboot, (please refer to LCD Menu: 5-3.4.5), user can enter into Telnet command lines. Note: 1. After user enter SIP Phone configuration via telnet, please use login: ”root”, password: null, press enter to enter command lines. -
Page 79: Help] Command
1. After setting the IP Address of SIP Phone SP5102 and reboot, (please refer to LCD Menu), user can enter Telnet command lines. Note: 1. After user enter SIP Phone configuration via telnet, please use login: ”root”, password: null, press enter to enter command lines. -
Page 80: Quit] Command
6.2 [quit] command Type quit/exit/close will logout SIP Phone SP5102 and Telnet Program. -
Page 81: Debug] Command
6.3 [debug] command This command is for engineers to debug system of SIP Phone SP5102. User can add debug flag via command debug –add “debug flags”, and then start debug function via command debug –open. When SIP Phone SP5102 is working on screen will display related debug messages. -
Page 82: Reboot] Command
6.4 [reboot] command After typing commit command, type reboot to restart the SIP Phone SP5102. -
Page 83: Pbook] Command
6.5 [pbook] command SIP Phone SP5102 can support 90 phone book data. 1. -print: display phone book data. User can print all data in phone book by command (pbook –print). 2. -add: add a new record in phone book table by giving name and e.164 number of callee endpoint.(pbook –add name “X”... -
Page 84: Commit] Command
6.6 [commit] command Save any changes after configuring the SIP Phone SP5102. -
Page 85: Ping] Command
6.7 [ping] command Command ping can test which the IP address is reachable or not. Usage: ping “IP address” The message will display packets transmitting condition or no answer from the IP address. -
Page 86: Time] Command
6.8 [time] command When SIP Phone SP5102 enable SNTP function and be able to connect with SNTP server, type time command will show the current time retrieved from SNTP server. -
Page 87: Ifaddr] Command
8. –timeformat: Set time display format as 12 or 24 hours. (ifaddr –timeformat 0/1, 0 as 24 hours, 1 as 12 houts) 9. -ipsharing: If SIP Phone SP5102 is behind a IP-sharing , user must enable IP sharing function and specify public IP address.(ifaddr –ipsharing 0/1 “public IP address of IP sharing”... - Page 88 “ipsharing” function. 15. –stunport: Input port of STUN server. Note: Some Proxy servers support endpoint behind NAT function, in this case SIP Phone doesn’t have to enable IP sharing function, please contact with your Proxy Server vendor for detail information.
-
Page 89: Pppoe] Command
6.10 [pppoe] command 1. -print: display all current configurations and information. 2. –id: to set PPPoE authentication user name. 3. –pwd: to set PPPoE authentication password. 4. –reboot: Select enable or disable this function. If user enables this function, after PPPoE disconnected, SIP Phone will automatically reboot to re-connect, and after reboot, if SIP Phone still can’t connect with server, SIP Phone will keep trying to connect. -
Page 90: Flash] Command
SIP Phone SP5102. 2. To execute the command flash –clean, all configuration of SIP Phone SP5102 stored in flash will be cleaned. It is authorized for the user whose login name is “root” only. -
Page 91: Sysconf] Command
6.12 [sysconf] command 1. -print: display all current configurations. 2. -idtime: set the duration(in second) of two pressed digits in dial mode as timed out. If after the duration user hasn’t pressed next number, SIP Phone will dial out all number pressed. 3. -
Page 93: Sip] Command
Proxy”. This function is for special proxy server. 7. –line: identify one number for the SIP Phone SP5102 to register to the Proxy (SIP –line “line number”). Note: In proxy mode please remember to set user account information under security command. -
Page 95: Security] Command
[security] command 1. –print: display all current configurations. 2. -name: set user ID of SIP Phone SP5102 for registering. User can set user name and password for registering. If password is no need, please set user name the same as line number or SIP Phone won’t register successfully. -
Page 96: Line] Command
6.15 [line] command –print: display all current configurations. –fwd: set forward function. There are 3 selections in Forward type, user must select under which condition to forward calls. 6.15.1 Busy Forward When SIP-Phone is in busy status, the incoming call will be forwarded to the assigned phone number. -
Page 97: Voice] Command
6.16 [voice] command The voice command is associated with the voice codec setting information. 1. -print: display voice codec information and configuration. 2. -send: three voice packet size can be configured as 20 ms, 40 ms or 60 ms.(only 30 and 60 ms for G..723.1) 3. -
Page 98: Phone] Command
6.17 [phone] command -print: Print current call progress tone configurations (ring: ring tone, rbt: ring back tone, bt: busy tone, dt: dial tone). This parameter should be accompanied with tone type. -ring: To set RING tone value. The played tone type, when Phone ha incoming call. -
Page 99: Tos] Command
6.18 [tos] command TOS/DiffServ (DS) priority function can discriminate the Differentiated Service Code Point (DSCP) of the DS field in the IP packet header, and map each Code Point to a corresponding egress traffic priority. As per the definition in RFC2474, the DS field is Type-of-Service (TOS) octet in IPv4. -
Page 101: Prefix] Command
6.19 [prefix] command This command is for digit manipulation. 1. -add: Add a rule to drop or insert prefix digits of incoming call. prefix: Set which prefix number to implement prefix rule. drop: Enable or disable drop function. If this function is enabled, Gateway will drop prefix number on incoming call. -
Page 102: Rom] Command
For example: User prepares to upgrade the latest app rom file – lpsip.100, the TFTP server is 192.168.1.1, User has to input command as below: rom –app –s 192.168.1.1 –f lpsip.100 Command rom –print can show current version installed in SIP Phone SP5102. -
Page 103: Auth] Command
6.21 [auth] command For security concern, the “root” user can customize some configurable items for “administrator” user. 1. -“item name”: Assign the configurable item for “administrator” user. Example: auth -ifaddr 1 auth -sip 1 auth -voice 1 Now the Administrator can use these command which Root user assign to them. -
Page 104: Passwd] Command
6.22 [passwd] command For security protection, user has to input the password before entering application user/config mode. Two configurations of login name/password are supported by the system. –set: set password of “root” users or “administrator” users. (passwd –set root/administrator “password”) –clean: clean up password restored before, and user can login :”root/administrator”, password: ”press enter”.
