- Page 1 User’s Manual Business IP Phone Model No.: SP5103 World Wide Web: www.micronet.com.tw ; www.micronet.info...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction ............................1 Harware Overview......................1 Software Overview ......................2 2. Keypad Interface..........................2 Keypad Description ....................... 2 Recording........................3 Keypad Function and Setting List ................. 3 2.3.1 Phone Book ......................3 2.3.1.1 Creating a New Entry................... 3 2.3.1.2 Modifying Contact Information.............. - Page 3 3.4.4 Ringer Settings....................14 3.4.5 DND Settings......................14 3.4.6 Dial Plan Setting....................15 3.4.6.1 Symbol Explain ..................16 3.4.7 Call Waiting Settings ..................17 3.4.8 Soft-key Settings ....................17 3.4.9 Hot Line Settings ....................17 3.4.10 Alarm Settings ....................18 3.4.11 Daylight Settings ....................18 Network ........................19 3.5.1 Network Status ....................19 3.5.2 WAN Settings .....................19 3.5.3...
- Page 4 3.11 Update.........................33 3.11.1 Update Firmware....................33 3.11.2 Auto Update Settings ..................34 3.11.3 Restore Default Settings ..................34 3.12 Reboot.........................34 4. Auto Provision from Micronet IP PBX.....................36...
-
Page 5: Introduction
1. Introduction This administration guide is for SP5103. The administration guide explains the keypad instruction, web configuration and command line configuration for IP Phone. Before using IP Phone, some setup processes are required to make the IP Phone work properly. Please refer to the Setup Menu for further information. -
Page 6: Software Overview
Output via general adapter: 6V, 1A FCC Class B CE, 89/336/EEC LVD: 73/23/EEC RoHS compliant Warning: AC Input out of defined range will cause phone malfunction or damage! 1.2 Software Overview ․ Hotline ․ Dial plan setting Network Interface ․ Dial without waiting Phone Functions ․... - Page 7 ․ Static IP authentication for web ․ G.168 LEC (Line Echo ․ DHCP Canceller) setup ․ PPPoE ․ AEC (Acoustic Echo ․ MD5 for SIP ․ STUN for NAT traversal Canceller) authentication (RFC ․ MAC clone ․ VAD (Voice Activity 2069/RFC 2617) ․...
-
Page 8: Keypad Interface
2. Keypad Interface 2.1 Keypad Description Key Name Description “1”, “-“, “٫”, “!”, “?” “2”, “a”, “b”, “c”, “A”, “B”, “C” “3”, “d”, “e”, ”f”, “D”, “E”, “F” “4”, “g”, “h”, “I”, “G”, “H”, “I” “5”, “j”, “k”, “l”, “J”, “K”, “L” “6”, “m”, “n”, “o”, “M”, “N”, “O”... -
Page 9: Recording
M10 / REC Press to record the conversation, please refer to section 2.2 for further details. VOICE MSG Press to listen to voice mail messages. SPEAKER Press to activate the speakerphone to allow handsfree conversations. VOLUMN Control Press to increase or decrease the volume of the ringer tone, handset, or the volume of the current call using the speakerphone. -
Page 10: Modifying Contact Information
2.3.1.2 Modifying Contact Information To modify contact information, do the following: Press the Menu key and then select Phone Book -> Search, and press the Enter key to view the phone book entries. Scroll through the phone to select an entry, and press the Enter key to display the contact information. -
Page 11: Phone Setting
Erase Records Delete call history. All: Delete all call history. Incoming: Delete all incoming call. Dialed: Delete all dialed out call. 2.3.3 Phone Setting Name Description Call Forward All Fwd. Activation: To Enabled/Disabled this function. Number: Forward to a Speed Dial Number. Busy Fwd. -
Page 12: Network
hear. Handset Gain Set Handset Gain from 0~15 (max.) for the other site to hear. Speaker Gain Set Speaker phone Gain from 0~15 (max.) for the other site to hear. Ringer Ringer Volume Ringer volume setting from 1~15 (max.). General Ringer Ringer tone selection from 1~3 and default. -
Page 13: Sip Setting
Status Show WAN, LAN IP address and MAC address. 2.3.5 SIP Setting If you want to use keypad to set the SIP setting, you have to go to item 8 Sys. Authority to input the password or you can not change the SIP setting. Name Description Service Domain... -
Page 14: Nat Traversal
2.3.6 NAT Traversal If you want to use keypad to set the NAT Traversal settings, you have to go to item 8 Sys. Authority to input the password, or you can not change the NAT Traversal settings. Name Description STUN Setting STUN Enable/Disable STUN. -
Page 15: Setup The Ip Phone By Web Browser
3. Setup the IP Phone by Web Browser By default, the IP Phone’s Bridge Mode is enabled and WAN port is in DHCP Client Mode. LAN port is the same as WAN. Connect the IP Phone to DHCP server, and the server assign an IP address to the phone. -
Page 16: Phone Book
Note: The information in this page is useful when you need technical support. You may screen capture this page and provide the information to technical support team so that they could easily track the issues you have. 3.3 Phone Book Phone Book contains Phone Book and Speed Dial Settings. -
Page 17: Speed Dial List
If you need to add a phone number into the phone book, you need to type the position, the name, and the phone number and ringer type for the number. When you finished a new phone list, just click Add Phone. -
Page 18: Phone Setting
3.4 Phone Setting Phone Setting contains Call Forward, SNTP Settings, Volume Settings, Ringer Settings, DND Settings, Dial Plan Settings, Call Waiting Settings, Soft-key Setting functions, Hot Line Settings, Alarm Settings and Daylight Settings. 3.4.1 Forward Settings You can setup the phone number you want to forward in this page. There are three type of Forward mode. -
Page 19: Sntp Settings
reflect the changes. 3.4.2 SNTP Settings You can setup the primary and second SNTP Server IP Address, to get the date/time information. Also you can base on your location to set the Time Zone, and how long need to synchronize again. When you have finished the settings, click Submit. -
Page 20: Ringer Settings
When finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.4.4 Ringer Settings You can select the melody for the incoming calls. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. Ring Tone by Caller ID Matching Digits: Enter a digit for the number of caller ID digits. -
Page 21: Dial Plan Setting
DND Always: All incoming call will be blocked until disable this feature. DND Period: Set a time period and the phone will be blocked during the time period. If the “From” time is large than the “To” time, the Block time will from Day 1 to Day 2. Blacklist Rule: Enter a rule to block calls that fit the rule. -
Page 22: Symbol Explain
3.4.6.1 Symbol Explain x or X 0,1,2,3,4,5,6,7,8,9 Drop Prefix: The default is No for adding the prefix to the dial plan in Replace Rule. Click Yes to delete the prefix of the dial plan in Replace Rule. Replace Rule 1~4: Type rule for matching. Example: Drop Prefix Replace Rule... -
Page 23: Call Waiting Settings
3.4.8 Soft-key Settings SP5103 supports soft-key settings for voice messages. You can press VOICE MSG on the IP Phone to dial out the entered number in order to get into the voice mail service. Voice mail key: Type a serial of number for listening to the voice messages. -
Page 24: Alarm Settings
Hot Line Number: Type a phone number as a special line. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.4.10 Alarm Settings Alarm Settings is to inform user at a certain time. Click On and then type the time for ringing. Alarm Time: Type a time for reminding. -
Page 25: Network
Click On, select Format 1 or Format 2, and configure the start/end time to enable daylight saving at the configured period of time. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. -
Page 26: Lan Settings
the ADSL Router, or Broadband Router. Also, you can use PPPoE to get the WAN IP address from your ISP. The default setting is Bridge mode. The WAN port default is DHCP Client mode. You can change the setting to Fixed IP mode, or PPPoE mode. -
Page 27: Ddns Settings
The LAN settings’ default does not effect as IP Phone’s Bridge mode is enabled. To configure LAN settings, go to Network -> WAN Settings, and click NAT under LAN Mode. You can connect your PC to the LAN port, set your PC as DHCP Client mode, and then you can get IP address from the IP Phone. -
Page 28: Vlan Settings
3.5.5 VLAN Settings You can set the VLAN setting in this page. There are two kind of destination packets coming from the IP Phone’s WAN port. One packet goes to the IP Phone, and the other goes through the LAN port to the PC. VLAN Packets: If you enable the first VLAN Packets and set the VID, User Priority, and CFI, all the incoming packets will be check with the IP Address and the VID. -
Page 29: Dmz Setting
You can enable DMZ Setting of the IP Phone. Click On, and type an IP address of the PC in DMZ Host When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.5.7 Virtual Server SP5103 provides configuring as a virtual server function. -
Page 30: Pptp Settings
If you need to add a virtual server into the Virtual Server list, you need to type the num, server IP, internal/external port, and select a protocol. When you finished a new phone list, just click Add Server. If you want to enable a virtual server, you can select the virtual server you want to enable, and then click Enable Selected. -
Page 31: Sip Settings
Note: You need to configure LAN Mode as NAT in WAN Settings page to enable this function. 3.6 SIP Settings In SIP Settings, you can setup the Service Domain, Port Settings, Codec Settings, Codec ID Settings, RTP Setting, RPort Setting and Other Settings. If the VoIP service is provided by ISP, you need to setup the related information correctly then you can register to the SIP Proxy Server correctly. - Page 32 First you need click On in Active to enable the Service Domain, and you can input the following items: Display Name: You can input the name you want to display. User Name: You need to input the User Name get from your ISP. Register Name: You need to input the Register Name get from your ISP.
-
Page 33: Port Settings
Example: 192.168.1.100 (Assume Domain server SIP port = 5060) 192.168.1.100:5678 (change the SIP port to 5678) Proxy Server: You need to input the Proxy Server get from your ISP. Outbound Proxy: You need to input the Outbound Proxy get from your ISP. If your ISP does not provide the information, then you can skip this item. -
Page 34: Codec Id Settings
3.6.4 Codec ID Settings You can set the Codec ID to meet the other device’s requirement. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.6.5 DTMF Settings You can setup the RFC2833 Out-Band DTMF, Inband DTMF and Send DTMF SIP Info in this page. -
Page 35: Rport Function
3.6.6 RPort Function You can setup the RPort Enable/Disable in this page. To change this setting, please follow your ISP information. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.6.7 Other Settings You can setup the Hold by RFC, Voice/SIP QoS and SIP Expire Time in this page. -
Page 36: Nat Trans
3.7 NAT Trans In NAT Trans, you can setup STUN function. These functions can help your IP Phone working properly behind NAT. STUN Setting: You can setup the STUN Enable/Disable and STUN Server IP address in this page. This function can help your IP Phone working properly behind NAT. To change these settings please following your ISP information. -
Page 37: Tones Settings
MAC Address: When click Manual, type an MAC address for WAN port. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.8.2 Tones Settings Tones Settings function can let you to configure the tones of various sounds. Unlike traditional phones, IP Phones generate the tones for different state by itself. -
Page 38: System Auth
ICMP Not Echo: Setup the ICMP echo Enable/Disable. This function can disable echo when someone pings this device, it can avoid hacker try to attack the device. Send Anonymous CID: click Yes for not sending the phones caller ID out. Send Flash Event: click DTMF EVENT or SIP INFO for the flash event. -
Page 39: Update
3.11 Update In Update, you can update the IP Phone’s firmware to the new one or do the factory reset to let the IP Phone back to default setting. 3.11.1 Update Firmware In New Firmware function you can update new firmware via HTTP in this page. You can upgrade the firmware form your local PC or TFTP. -
Page 40: Auto Update Settings
3.11.2 Auto Update Settings The IP Phone provides automatic update function. Once enable the function, the phone will check the updates at the time in order to have the latest version of firmware. Note that the function must be in DHCP Client mode. -
Page 42: Auto Provision From Micronet Ip Pbx
4. Auto Provision from Micronet IP PBX Auto Provision function can be used to download the original configurations stored in the Micronet SP5325/SP5350 IP-PBX series. This is very useful for the administrator who needs to set large amount of IP Phones. The administrator can set a new user account in the IP PBX web page. Once the IP Phone is connected to the IP PBX, it automatically downloads a predefined configuration setting from Micronet IP-PBX.
