Cub Cadet CC 94M Operator's Manual page 10

3. The rope guide, which is connected to the support rod, is
located on the right side of the lower handle. See Fig. 3-3.
C
a. Hold blade control against upper handle.
b. Pull starter rope out of the engine. Release blade
control.
c. Slip starter rope into rope guide.
4. Attach cables to the lower handle with the cable ties
already on the lower handle. Insert pegs on cable ties into
the holes on the lower handle. Pull cable ties tight and cut
off the extra.
Grass Catcher
The mower was shipped with the mulching baffle installed on
the unit. For bagging purposes, you will have to attach the grass
bag and its adapter in place of the mulching baffle.
10 s 3 — a
ectiOn sseMbly
A
B
Figure 3-3
& s -u
et p
1. Remove three wing nuts holding the mulching baffle in
place and remove from unit.
2. Replace with grass bag adapter, while making sure the
front lip of adapter goes under the edge of the deck. Refer
to Fig. 3-4. Secure with wing nuts previously removed.
Figure 3-4
3. Lift chute door on the grass bag adapter and slide grass
bag onto the adapter. See Fig. 3-5.
3
Figure 3-5
