Cub Cadet CC 46ES Operator's Manual

Cub Cadet CC 46ES Operator's Manual

Self propelled mower
Hide thumbs Also See for CC 46ES:
Table of Contents

Advertisement

Quick Links

Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
Self Propelled Mower — Model CC46 ES
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-07509
(November 28, 2011)

Advertisement

Table of Contents
loading

Related Manuals for Cub Cadet CC 46ES

Summary of Contents for Cub Cadet CC 46ES

  • Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No. 769-07509...

  • Page 2: Table Of Contents

    See How-to Maintenance and Parts Installation Videos at www.cubcadet.com/tutorials ◊ Call a Customer Support Representative at (800) 965-4CUB ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write to Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019...

  • Page 3: Safe Operation Practices

    Important Safe Operation Practices WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
  • Page 4 A missing or damaged discharge cover can cause blade When starting engine, pull cord slowly until resistance contact or thrown object injuries. is felt, then pull rapidly. Rapid retraction of starter cord (kickback) will pull hand and arm toward engine faster than Many injuries occur as a result of the mower being pulled you can let go.
  • Page 5 Service Check the blade and engine mounting bolts at frequent intervals for proper tightness. Also, visually inspect blade Safe Handling Of Gasoline: for damage (e.g., bent, cracked, worn) Replace blade with the original equipment manufacture’s (O.E.M.) blade only, To avoid personal injury or property damage use extreme listed in this manual.

  • Page 6: Spark Arrestor

    Notice Regarding Emissions Spark Arrestor Engines which are certified to comply with California and federal WARNING: This machine is equipped with an EPA emission regulations for SORE (Small Off Road Equipment) internal combustion engine and should not be used are certified to operate on regular unleaded gasoline, and on or near any unimproved forest-covered, brush may include the following emission control systems: Engine covered or grass-covered land unless the engine’s...

  • Page 7: Safety Symbols

    Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate DANGER —...
  • Page 8 2 — i ection mportant peration racticeS...

  • Page 9: Assembly & Set-Up

    Assembly & Set-Up Contents of Carton • One Lawn Mower • One Side Discharge Chute • One Bottle of Oil • One Grass Catcher • One Lawn Mower Operator’s Manual • One Engine Operator’s Manual Assembly Insert a carriage bolt found in the manual bag into the upper hole on the handle mounting bracket.
  • Page 10 The rope guide is attached to the right side of the upper Slip plastic channel of grass bag over hooks on the handle. See Fig. 3-3. Loosen the wing nut which secures the frame. See Fig. 3-4. All the plastic channels except rope guide.
  • Page 11 Adjustments Side Discharge Chute Your mower is shipped as a mulcher. To convert to side discharge, Cutting Height make sure grass catcher is off of the unit and rear discharge door is closed. Each wheel has a height adjustment lever to change the cutting height of the mower.

  • Page 12: Controls & Features

    Controls and Features Blade Control Electric Start Ignition Switch Drive Control Recoil Starter Primer Side Discharge Chute Mulch Plug Cutting Height Adjustment Levers Figure 4-1 Mulch Plug Blade Control The mulch plug is used for mulching purposes. Instead of The blade control is attached to the upper handle of the mower. collecting the grass clippings in a grass catcher or using the Depress and squeeze it against the upper handle to operate the side discharge chute, some mower models have the option...

  • Page 13: Operation

    Operation Starting Engine WARNING: Be sure no one other than the operator is standing near the lawn mower while starting engine or operating mower. Never run engine indoors or in enclosed, poorly ventilated areas. Engine exhaust contains carbon monoxide, an odorless and deadly gas.

  • Page 14: Maintenance & Adjustment

    Maintenance & Adjustments Maintenance Lubricate the wheels at least once a season with light oil (or motor oil). If wheels are removed for any reason, lubricate General Recommendations surface of the pivot arm and inner surface of the wheel with light oil. See Fig. 6-1. •...
  • Page 15 Replacing Rear Flap Engine Care A list of key engine maintenance jobs required for good To remove rear flap, lift rear door, and press flap in on performance by the mower is given below. Follow the either side to remove from hole. See Fig. 6-2. accompanying engine manual for a detailed list and instructions.

  • Page 16: Service

    Service Blade Care Lubricate the engine crankshaft and the inner surface of the blade adapter with light oil. Slide the blade adapter WARNING: onto the engine crankshaft. Place the blade on the adapter When removing the cutting blade for sharpening or replacement, protect your hands with such that the side of the blade marked “Bottom”...

  • Page 17: Replacing Battery

    Press inward on tab on the engine baffle to release it from Replace with new belt, making sure belt is firmly seated on the baffle bracket. See Fig. 7-3. engine pulley while pulling from the other side and sliding it around the transmission pulley. Reattach engine baffle and reassemble blade as described in the previous section.

  • Page 18: Charging Battery

    Charging Battery NOTE: The battery you have may differ slightly from the one shown in Fig. 7-6. Refer to the Parts List. WARNING: The battery contains corrosive fluid and toxic material; handle with care and keep away from children. Do not puncture, disassemble, mutilate or incinerate the battery.
  • Page 19 Replacing Fuse Off-Season Storage The electric starter circuit and battery are protected by a 40 The following steps should be taken to prepare your lawn mower ampere fuse. If the fuse burns out, the electric starter will not for storage. operate.

  • Page 20: Troubleshooting

    Troubleshooting Problem Cause Remedy Engine Fails to start 1. Blade control disengaged. 1. Engage blade control. 2. Spark plug boot disconnected. 2. Connect wire to spark boot. 3. Fuel tank empty or stale fuel. 3. Fill tank with clean, fresh gasoline. 4.
  • Page 21 Problem Cause Remedy Uneven cut 1. Wheels not positioned correctly. 1. Place all four wheels in same height position (if equipped with individual height adjusters). 2. Dull blade. 2. Sharpen or replace blade. Mower will not self propel 1. Belt not installed properly. 1.

  • Page 22: Replacement Parts & Accessories

    Xtreme Mulching Blade Phone (800) 965-4CUB or 877-282-8684 for your nearest Cub Cadet Dealer to order replacement parts or a complete Parts Manual (have your full model number and serial number ready). Parts Manual downloads are also available free of charge at www.cubcadet.
  • Page 23 Oil Siphon Phone (800) 965-4CUB or 877-282-8684 for your nearest Cub Cadet Dealer to order replacement parts or a complete Parts Manual (have your full model number and serial number ready). Parts Manual downloads are also available free of charge at www.cubcadet.

  • Page 24: Warranty

    The limited warranty set forth below is given by Cub Cadet LLC with adjustments, and normal deterioration of the exterior finish due to respect to new merchandise purchased or leased and used in the United use or exposure.
