Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
* Model CC98H Shown
Self Propelled Mower — Model CC 98H/CC 98
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-07524
(December 21, 2011)
Advertisement
Table of Contents
Related Manuals for Cub Cadet CC 98H
Summary of Contents for Cub Cadet CC 98H
- Page 1 ’ peratOr anual * Model CC98H Shown Self Propelled Mower — Model CC 98H/CC 98 WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
-
Page 2: Table Of Contents
See How-to Maintenance and Parts Installation Videos at www.cubcadet.com/tutorials ◊ Call a Customer Support Representative at (800) 965-4CUB ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write to Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019... -
Page 3: Safe Operation Practices
Important Safe Operation Practices WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. - Page 4 A missing or damaged discharge cover can cause blade When starting engine, pull cord slowly until resistance contact or thrown object injuries. is felt, then pull rapidly. Rapid retraction of starter cord (kickback) will pull hand and arm toward engine faster than Many injuries occur as a result of the mower being pulled you can let go.
- Page 5 Service Check the blade and engine mounting bolts at frequent intervals for proper tightness. Also, visually inspect blade Safe Handling Of Gasoline: for damage (e.g., bent, cracked, worn) Replace blade with the original equipment manufacture’s (O.E.M.) blade only, To avoid personal injury or property damage use extreme listed in this manual.
-
Page 6: Spark Arrestor
Notice Regarding Emissions Spark Arrestor Engines which are certified to comply with California and federal WARNING: This machine is equipped with an EPA emission regulations for SORE (Small Off Road Equipment) internal combustion engine and should not be used are certified to operate on regular unleaded gasoline, and on or near any unimproved forest-covered, brush may include the following emission control systems: Engine covered or grass-covered land unless the engine’s... -
Page 7: Safety Symbols
Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate DANGER —... - Page 8 2 — i ection mportant peration racticeS...
-
Page 9: Assembly & Set-Up
Assembly & Set-Up Contents of Carton • One Lawn Mower • One Grass Catcher • One Grass Catcher Adapter • One Side Discharge Chute • One Engine Operator’s Manual • One Bottle of Oil • One Lawn Mower Operator’s Manual Assembly Locate the hairpin clip on the weld pin on each side of lower handle. - Page 10 The rope guide, which is connected to the support rod, is Replace with grass bag adapter, while making sure the located on the right side of the lower handle. See Fig. 3-3. front lip of adapter goes under the edge of the deck. Refer to Fig.
- Page 11 Adjustments Lift chute door on the grass bag adapter and slide grass bag onto the adapter. See Fig. 3-6. Cutting Height The cutting height adjustment lever is located above the rear left wheel. See Fig. 3-8A insert. Figure 3-6 Side Discharge Chute Figure 3-8 Follow steps below to install the side discharge chute: Pull lever out and away from mower.
- Page 12 Set-Up Drive Control The adjustment wheel is located in the drive control handle Gas and Oil Fill-Up housing and is used to tighten or loosen the drive belt. You will have to adjust the drive control if any of the following happens: Refer to the separate engine owner’s manual for additional engine information.
-
Page 13: Controls & Features
Controls and Features Blade Control Drive Control Cutting Height Adjustment Lever Recoil Starter Side Discharge Chute Figure 4-1 Side Discharge Chute Blade Control Your mower is shipped as a mulcher. To discharge the grass The blade control is attached to the upper handle of the mower. clippings to the side instead, follow the instructions in the Depress and squeeze it against the upper handle to operate the Assembly &... -
Page 14: Operation
Operation Starting & Stopping Engine Using Grass Catcher Refer to the Engine Operator’s manual packed with your lawn You can use the grass catcher bag to collect clippings while you mower for instructions on starting and stopping the engine. are operating the mower. Attach grass catcher following instructions in “Setup and Using Your Lawn Mower Adjustment”. -
Page 15: Maintenance & Adjustment
Maintenance & Adjustments Maintenance Lubricate the wheels and casters at least once a season with light oil (or motor oil). If wheels are removed for any General Recommendations reason, lubricate the axle bolt and inner surface of the wheel with light oil. See Fig. 6-1. •... - Page 16 Engine Care Replacing Rear Flap A list of key engine maintenance jobs required for good To replace rear flap, proceed as follows: performance by the mower is given below. Follow the To remove rear flap, lift rear door, remove screw, and press accompanying engine manual for a detailed list and instructions.
-
Page 17: Service
Service Blade Care Lubricate the engine crankshaft and the inner surface of the blade adapter with light oil. Slide the blade adapter WARNING: onto the engine crankshaft. Place the blade on the adapter When removing the cutting blade for sharpening or replacement, protect your hands with such that the side of the blade marked “Bottom”... -
Page 18: Troubleshooting
Troubleshooting Problem Cause Remedy Engine Fails to start 1. Blade control disengaged. 1. Engage blade control. 2. Spark plug boot disconnected. 2. Connect wire to spark boot. 3. Fuel tank empty or stale fuel. 3. Fill tank with clean, fresh gasoline. 4. - Page 19 Problem Cause Remedy Uneven cut 1. Wheels not positioned correctly. 1. Place all four wheels in same height position (if equipped with individual height adjusters). 2. Dull blade. 2. Sharpen or replace blade. Mower will not self propel 1. Belt not installed properly. 1.
-
Page 20: Replacement Parts & Accessories
Xtreme Mulching Blade 954-0460 V-Belt Phone 877-282-8684 for your nearest Cub Cadet Dealer to order replacement parts or a complete Parts Manual (have your full model number and serial number ready). Parts Manual downloads are also available free of charge at www.cubcadet.com... - Page 21 490-850-0008 Oil Siphon Phone 877-282-8684 for your nearest Cub Cadet Dealer to order replacement parts or a complete Parts Manual (have your full model number and serial number ready). Parts Manual downloads are also available free of charge at www.cubcadet.com 9 —...
- Page 22 Notes...
- Page 23 otes...
-
Page 24: Warranty
Refer to applicable manufactur- The limited warranty set forth below is given by Cub Cadet LLC with er’s warranty for terms and conditions. respect to new merchandise purchased or leased and used in the b.
