- Page 1 CD Receiver Installation & Owner's Manual 3 Band EQ HPF/LPF/Q-Factor/C-Freq. 2 USB Ports iPod®/iPhone®/Flash Drive SDHC Supported XDMA7600 MP3/WMA/AAC Playback HFP/A2DP/AVRCP/PBAP CD-R/RW Compatible 3.5mm Input...
- Page 2 XDMA7600 Preparation Please read entire manual before installation. Before You Start Getting Started KEYS MOUNTING KIT OR DASH OPENING HEAD UNIT MOUNTING SLEEVE TYPICAL FRONT-LOAD DIN MOUNTING METHOD...
-
Page 3: Wiring Diagram
XDMA7600 Wiring Diagram RCA Preamp Output BLACK Female USB Input Connections Rear USB Connection SUBWOOFER REAR FRONT FRONT REAR SUB/W L-CH R-CH REMOTE IN Antenna Optional USB Extension Cable Connector (Included) Steering Wheel Interface Input PAC SWI-PS connection (sold separately) 3.5mm... -
Page 4: Receiver Controls
XDMA7600 Receiver - Controls Control Function Description Color Mute... -
Page 5: Ir Remote - Controls
XDMA7600 IR Remote - Controls Volume Down Mute... -
Page 6: General Operation
XDMA7600 General Operation Faceplate Removal Press RELEASE Power On/Off Press turn unit off. Source Press SOURCE Note: Note: Steering Wheel Interface Input PAC (Pacific Accessory Corporation) SWI-PS PAC SWI-PS Auxiliary Input Volume Mute Press MUTE Press MUTE Reset RESET Display... -
Page 7: Setup Menu
XDMA7600 Setup Menu AUDIO/MENU AUDIO/MENU volume knob BACK submenu. Function Options Action Auto Station Press SELECT Store (Tuner mode only) (Tuner mode only) Local/Distance Tuning (Tuner mode only) Tuner (Tuner mode only) Frequency Spacing (Tuner mode only) Selectable iPod Control... -
Page 8: Audio Menu
XDMA7600 Audio Menu Press AUDIO/MENU BACK BASS MIDDLE TREBLE BALANCE FADER SUBWOOFER SOURCE LEVEL Bass Press AUDIO/MENU until BASS Middle Press AUDIO/MENU until MIDDLE Treble Press AUDIO/MENU until TREBLE Note: Press AUDIO/MENU until BALANCE Balance volume knob balance. Fader Press AUDIO/MENU until FADER... - Page 9 XDMA7600 Audio Menu - Advanced Control Center Frequency Quality ("Q") Factor Low Pass Filters Press AUDIO/MENU BASS MIDDLE TREBLE Press BAS FREQ MID FREQ TRE FREQ SELECT BAS Q MID Q Bass Center Frequency Press AUDIO/MENU until BASS SELECT until BAS FREQ...
-
Page 10: Am/Fm Tuner Operation
XDMA7600 LCD Icon Layout of iPod Random AM/FM Tuner Operation Seek Tuning Press TUNE or TUNE Manual Tuning Press TUNE or TUNE to move Scan Tuning Press SCAN SCAN to cancel. Band Press BAND band. Storing and Recalling Station Presets... - Page 11 XDMA7600 CD Player Operation - Audio CDs Insert CD Eject CD EJECT Track Select Press TRACK TRACK TRACK Fast Forward/Reverse TRACK or TRACK to fast / II Pause Press / II Press Intro Press INT INT function. Repeat Press RPT...
- Page 12 XDMA7600 CD Player Operation - MP3/WMA/AAC Playing an MP3/WMA/ AAC Disc Folder Access Press Press Repeat Press RPT volume knob Random Press RDM volume knob RDM function. Note: Intro Press INT volume knob INT function. Note: folder. Displaying Information Press DISP time.
-
Page 13: File/Folder Search
XDMA7600 CD Player Operation - MP3/WMA/AAC File/Folder Search Begin Searching Press SELECT current folder Search menu controls volume knob folders. SELECT selected file. BACK File and Folder names Note Root Press Press SELECT BACK Folder 1 Folder 2 File 1... - Page 14 XDMA7600 CD Player Operation - MP3/WMA/AAC File/Folder Compatibility and Support Compatible File Types Incompatible File Types MP3 Pro Recording Format Compatibility Multi session Sampling Frequency Rate Compatibility Transfer Bit Rate Compatibility Character Support ID3 Tag Support File/Folder Limit...
-
Page 15: Operation Of Ipod/Iphone
XDMA7600 Operation of iPod/iPhone Connecting an iPod/iPhone Device USB Connection Controlling a Device: Full Control When the control of iPod/iPhone feature is set to "FULL" in the Setup Menu, use the following functions to control the device: Song Select Press... -
Page 16: Displayed Information
XDMA7600 Operation of iPod/iPhone Controlling a Device: Full Control - Music Search The XDMA7600 features a powerful music search that simplifies the searching process. Follow the steps below to find the desired song: Begin Searching Press SELECT Select a Category volume knob to select between artist album song, playlist, podcast, audiobook and genre. -
Page 17: Device Compatibility
XDMA7600 Operation of iPod/iPhone Controlling a Device: Manual Control When the control of iPod/iPhone feature is set to "MANUAL" in the iPod Menu, use the following functions to control the device: Manual Control for iPod Basic Head Unit Control Song Select... -
Page 18: Usb/Sd Card Operation
XDMA7600 USB/SD Card Operation Connect a USB Device (sold separately) Connect an SD Card (sold separately) Playing Music Track Select Press TRACK Press TRACK TRACK Fast Forward and TRACK or TRACK to fast forward Reverse / II Pause Press / II... - Page 19 XDMA7600 USB/SD Card Operation File/Folder Search Begin Searching Press SELECT current folder Search menu controls volume knob folders. SELECT selected file. BACK File and Folder names Note Root Press Press SELECT BACK Folder 1 Folder 2 File 1 File 2...
- Page 20 XDMA7600 USB / SD Card Operation Displayed Information Press DISP (LINE 1) FILE NAME ELAPSED TIME TRACK NUMBER ARTIST (LINE 2) SONG TITLE FOLDER NAME CLOCK TOTAL TRACKS File/Folder Compatibility and Support Compatible File Types Incompatible File Types MP3 Pro...
-
Page 21: Bluetooth Operation
XDMA7600 Bluetooth Operation ® Pairing a Device Preparation Pairing a New Device The device name is "XDMA7600" The Bluetooth passcode "1234" Note Pairing Additional Devices Connecting a Paired Device SELECT SELECT or Note Auto Connect Disconnecting a Device... -
Page 22: Making A Phone Call
XDMA7600 Bluetooth Operation ® Making a Phone Call Manual Dialing Press Note Recent Calls List Press Redialing the last number Phonebook Menu* Note Press SELECT volume knob ll nn Press SELECT ll nn volume knob Press SELECT or... - Page 23 XDMA7600 Bluetooth Operation ® Receiving and Ending Phone Calls Receiving a Phone Call Note Note Auto Answer is set to ON Ending a Phone Call mode. During a Phone Call Volume volume knob Microphone Mute Press MUTE MUTE Audio Transfer...
-
Page 24: Bluetooth Reset
XDMA7600 Bluetooth Operation ® Streaming Audio Operation Notes: / II Note: Bluetooth Reset SOURCE MUTE Compatibility Note: Bluetooth Setup Menu Options Function Options Action button must... -
Page 25: Limited One Year Warranty
XDMA7600 Limited One Year Warranty What to do? from state to state. call. be free from defects in material and Who is covered? What is covered? -
Page 26: Troubleshooting - General
XDMA7600 Troubleshooting - General Problem Cause Yellow wire not connected or incorrect Unit will not turn on (no power) Unit has power (but no sound) Unit blows fuses Excessive Skipping ERROR-01 appears Disc read error Press EJECT or RESET on display... -
Page 27: Specifications
XDMA7600 Specifications FM Tuner 87.5MHz - 107.9MHz 8.5dBf 10dBf 40dB 30Hz - 13kHz AM Tuner 530kHz - 1710kHz 22uV 30Hz - 2.2kHz 4 to 8 ohms General 2 Volts RMS 7" x 7" x 2" (178 x 178 x 51 mm) -
Page 28: Fcc Compliance
XDMA7600 FCC Compliance Warning Note: receiver is connected. - Page 29 license.
