- Page 1 User's Manual M Series Monitor www.altoproaudio.com Version 1.0 August 2003 English...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN "Electric discharge" This symbol, alert you to the presence of uninsulated dangerous voltage inside the product enclosure, which constitutes a risk of electric shock. "Exclamatory point" This symbol, alert the user to the presence of important operating and maintenance instructions the owner's manual included to the product. -
Page 3: Panel Controls
(2) NEAR or FAR field selection Via this switch, you can apply your M series monitor speakers in the near field or far field configuration. Generally, near field option is designed for the near distance monitor which is mainly used in the smaller sound system, and the speakers are placed relatively close to the listener, normally about 1~1.5m. -
Page 4: Power Indicator
(4) NEAR or FAR Field Selection Via this switch, you can apply your M series monitor speakers in the near field or far field configuration. Generally, near field option is designed for the near distance monitor which is mainly used in the smaller sound system, and the speakers are placed relatively close to the listener, normally about 1~1.5m. -
Page 5: Sensitivity Control
(5) SENSITIVITY Control Adjust this trim pot to get the proper input gain. (6) SIGNAL INPUT This combined connector is used to input the program sources either in balanced or unbalanced configuration. (7) OUT/LINK This balanced XLR connector is linked in parallel with the SIGNAL INPUT, and it can be used to output the input signal directly. -
Page 6: Unbalanced Connection
-. For M Series Active Monitor Speakers As to M series active monitor speakers, just like most of the traditional amplifiers in the market, we should consider its audio connections intended for the low level signal flow, either in the balanced or the unbalanced connection. Balanced connection Ring Ring... -
Page 7: Installation
3. Push the Solid Slide (12) into the specific Slot of the monitor speakers. The M series monitor speakers provide 3 slots for each unit, please choose the most reasonable one to install. 4. Use two screws (11, M3 10) to stop the Solid Slide at the proper position in the Slot. - Page 8 APPENDIX Exploded Diagram of The Accessory (YS-60) Part Description Item Ni Screw, M6 55 1.0PH Fixing Bracket - Left Spring Mounting Base Fixing bracket - Right Spring Washer Ni Nut Fixing Lever Zn Screw, M6 1.0PH 10 Connecting Lever Ni Screw, M3 10 Solid Slide...
-
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS System type 2 Way 2 Way 2 Way Power Handing AES 30W AES 70W AES 80W SPL 1W, 1m 87dB 92dB 95dB Frequency Response 50Hz-13kHz (-10dB) 40Hz-15kHz (-10dB) 40Hz-15kHz (-10dB) Impedance 4Ohm 4Ohm 4Ohm Crossover Frequency 2.3-3kHz (1m/W) 2.3-3kHz (1m/W) 2.3-3kHz (1m/W) Dimension HxWxD... - Page 10 Tel: 886-4-22313737 email: info@altomobile.com Fax: 886-4-22346757 All rights reserved to ALTO Mobile. Due to continued development in response to customer feedback, product features, specifications and/or internal/external design may be changed without prior notice. No photocopying, translation or reproduction of any part of this user manual is allowed without prior written permission.Copyright...
