Summary of Contents for Oki ML5590/91

  • Page 1 ML5590/91 user’s guide...

  • Page 2: Preface

    Europe website: Copyright © 2003. All rights reserved. Oki and Microline are registered trademarks of Oki Electric Industry Company, Ltd. Hewlett-Packard, HP, and LaserJet are registered trademarks of Hewlett-Packard Company. Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corporation.

  • Page 3: Table Of Contents

    Printer Drivers ........9...
  • Page 4 Parts and Accessories ....... . 70 Printer Control Codes....... . . 72 Epson LQ Commands .

  • Page 5: Notes, Cautions, And Warnings

    NOTES, CAUTIONS AND WARNINGS NOTE A note appears in this manual like this. A note provides additional information to supplement the main text which may help you to use and understand the product. CAUTION! A caution appears in this manual like this. A caution provides additional information which, if ignored, may result in equipment malfunction or damage.

  • Page 6: Introduction

    Then, the paper moves back down for printing. This feature has to be enabled. Paper Park Your printer’s Paper Park feature allows you to print a single sheet (cut-sheet) page without removing continuous feed paper from the printer. For more information, see “Paper Park” in “Using your Printer”.
  • Page 7 “Top of Form (TOF) and Forms Tear-Off” in “Using your Printer”. Turning the Platen Knob Always turn the printer off before turning the platen knob! If you turn the platen knob when the printer is on, the Top of Form will misalign. NOTE INTRODUCTION > 7...
  • Page 8 Controlling Access to the Printer > You can control access to the printer by changing the setting for the Operator Panel Function in the Menu from Full Operation (the factory default) to Limited Operation. > When Limited Operation is selected, the PRINT QUALITY and CHARACTER PITCH keys don’t work.

  • Page 9: Printer Drivers

    If you wish to change to one of the IBM emulations, see “Using your Printer”. PRINTER DRIVERS The Oki driver for your printer is provided on the CD included with the printer. You can either load the Oki driver or select one of the compatible drivers listed below in your software application.

  • Page 10: Using A Compatible Driver

    After files have finished copying, click [Finish]. Switch your printer ON. USING A COMPATIBLE DRIVER The drivers below are listed by decreasing compatibility with your printer. Use one as close to the top of the list as possible. Epson LQ Epson LQ680 Epson LQ1170/570...

  • Page 11: Connecting The Usb Cable

    Using an inferior cable can cause printing problems and special cables are needed for longer runs than five metres The operation of a printer is not assured if a USB compatible device is connected concurrently with other USB compatible machines.
  • Page 12 If the printer had formerly been used as a parallel or serial device and there is no output from the printer once a USB cable has been connected, check to see that the correct port has been selected.

  • Page 13: Using Your Printer

    USING YOUR PRINTER COMPONENTS: REAR FEED (CONTINUOUS FORMS) The serial number of your printer is on a label fixed to the back of the printer. Sheet Guide Paper Lever ON-OFF Switch Platen Knob COMPONENTS: TOP FEED (SINGLE SHEETS) Paper Guides...

  • Page 14: Top Of Form (Tof)

    The first line prints at the red line of the plastic paper shield (1) on the printhead. If you turn the platen knob when the printer is not at Top of Form, the TOF will misalign. Always feed the paper to TOF before turning the platen knob! >...

  • Page 15: Forms Tear-Off

    To use the TEAR key: Make sure paper is loaded, and wait 2 seconds. Press TEAR (3). If the paper moves up, Forms Tear-Off is OFF. If the paper moves down, Forms Tear-Off is ON. USING YOUR PRINTER > 15...

  • Page 16: Setting Top Of Form (Tof)

    SETTING TOP OF FORM (TOF) If you turn the platen knob when the printer is not at Top of Form, the TOF will misalign. Always feed the paper to TOF before turning the platen knob! The first line prints at the red line (1) of the plastic paper shield on the printhead.
  • Page 17 (When you begin pressing the Micro Feed key, the printhead will move to the right). Press SEL | MENU (1) to save the setting and place the printer back on line. To reset the Top of Form to the factory default, see the next page.

  • Page 18: Temporarily Changing The Top Of Form

    TEMPORARILY CHANGING THE TOP OF FORM If you turn the platen knob when the printer is not at Top of Form, the TOF will misalign. Always feed the paper to TOF before turning the platen knob. To move the Top of Form position lower for one page only: Press SEL to deselect the printer.

  • Page 19: Potential Issues With Software Packages

    POTENTIAL ISSUES WITH SOFTWARE PACKAGES If Forms Tear-Off is set to ON and the software package you are using “pauses” for a long enough interval while sending data to the printer, Forms Tear-Off may be activated. No data is lost, but this causes uneven print registration due to the paper movement.

  • Page 20: Changing The Forms Tear-Off Setting

    If you don’t wish to engage the Forms Tear-Off feature, you can advance: rear-feed continuous forms loaded on the built-in tractor bottom-feed continuous forms loaded on the optional push tractor up to the tear-off position manually, by pressing TEAR (5). Form Tear-Off Form Tear-Off USING YOUR PRINTER > 20 1 Sec...

  • Page 21: Paper Park

    Never park labels. Paper park allows you to switch to single sheet printing without removing continuous feed paper from the printer. When you wish to print single sheets, simply press PARK (6) to retract the continuous form paper from the paper path, then lift the sheet guide, load the sheet and send the print job.

  • Page 22: Single Sheets To Continuous Forms

    Adjust the paper guides (1) for the size of paper you are using, then place a sheet of paper in the sheet guide. SINGLE SHEETS TO CONTINUOUS FORMS Press FF/LOAD to remove the single sheet paper. Lower the sheet guide into the continuous forms position. USING YOUR PRINTER > 22...
  • Page 23 Swing the wire feed guide over onto the pull-up roller. Move the paper lever to the appropriate position. Rear feed: Bottom feed: If necessary, load continuous form paper. Press FF/LOAD. USING YOUR PRINTER > 23...

  • Page 24: Printhead Gap

    To adjust the gap, open the access cover and move the coloured lever (1) to the recommended setting from the table. Setting When the head gap is set to 2, 3, 4 or 5, the printer automatically slows down for better print quality with multipart forms. CAUTION!

  • Page 25: Print Quality

    Courier Gothic Orator Prestige Roman Swiss Swiss Bold NOTE Lights on LQ and COURIER LQ and GOTHIC LQ and ORATOR LQ and PRESTIGE LQ, COURIER and GOTHIC LQ, PRESTIGE and GOTHIC LQ, COURIER and PRESTIGE USING YOUR PRINTER > 25...

  • Page 26: Character Pitch

    To select Proportional, press the CHARACTER PITCH key until both the cpi value and PROP lights are illuminated. To select non-proportional, press the CHARACTER PITCH key until the light for the cpi value you wish to use is illuminated. USING YOUR PRINTER > 26...

  • Page 27: Printer Reset

    PITCH key (5). Pressing SHIFT and RESET reinitialises the printer, but does not affect any menu settings and does not reset the printer to the factory defaults. For information on resetting the printer to the factory defaults, see “Resetting the Menu to the Factory Defaults” later in this chapter.
  • Page 28 Press and hold SHIFT (2), then press SEL (1) to save your setting and exit the Menu Mode. USING YOUR PRINTER > 28...

  • Page 29: Menu Mode

    MENU MODE In Menu Mode, use the front panel keys to change the defaults for the printer parameters. The changes made in the Menu Mode are automatically saved when you exit the Menu Mode and are retained, even when the printer is turned off.

  • Page 30: Entering And Exiting Menu Mode

    Hold down the SHIFT key while pressing SEL. RESETTING THE MENU TO THE FACTORY DEFAULTS Turn the printer OFF. Press SEL and LF while turning the printer ON. PRINTING THE MENU SETTINGS Make sure paper is loaded in the printer.

  • Page 31: Menu Settings

    Press and hold SHIFT, then press SEL to exit the Menu Mode and save your settings. If you turn off the printer without first exiting the Menu Mode, the changes you have made will be lost. MENU SETTINGS For a complete explanation of each menu item, see “Explanations of Menu Items”...
  • Page 32 Group Item Symbol Sets Character Set Language Set Zero Character Code Page Rear Feed Line Spacing Form Tear-Off Skip Over Perforation Page Width (wide model) Page Length Bottom Feed Line Spacing Form Tear-Off Skip Over Perforation Page Width (wide model) Page Length Settings Set I, Set II...
  • Page 33 Group Item Top Feed Line Spacing Form Tear-Off* Bottom Margin Page Width (wide model) Page Length Wait Time Page Length Control * With RollPaper Stand fitted Set-Up Graphics Receive Buffer Size Paper Out Override Print Registration 1 Print Registration 2 Operator Panel Function Reset Inhibit Print Suppress Effective...
  • Page 34 Group Item Parallel I/F I-Prime Pin 18 Auto Feed XT* Bi-Direction *When Epson LQ emulation selected. Serial I/F* Parity Serial Data 7/8 bits Protocol Diagnostic Test Busy Line Baud Rate DSR Signal DTR Signal Busy Time * When Serial I/F installed. CSF Bin 1** Line Spacing Bottom Margin...

  • Page 35: Explanation Of Menu Items

    Auto CR, Default =No IBM emulation only. If you want the printer to automatically add a carriage return when a Line Feed is received at the end of a line, change the setting to Yes.
  • Page 36 Bottom Margin, Default = Valid Change to Invalid if you want the printer to ignore the bottom margin setting. Setting the Bottom Margin to Invalid can cause loss of data and damage the printhead by allowing printing without paper. Busy Line, Default = SSD- Appears only when the optional Serial Interface is installed.
  • Page 37 CSF Type, Default = Wide To avoid paper jams, change this setting to Narrow if you are using the optional Cut Sheet Feeder on the wide model ML421 printer. Diagnostic Test, Default = No Appears only when the optional Serial Interface is installed. Select YES to perform a diagnostic test of the serial interface.
  • Page 38 DTR Signal, Default = Ready On Power Up Appears only when the optional Serial Interface is installed. Change to Ready On Select if the DTR signal is required when the printer is selected (leave as Ready On Power Up if the DTR signal is required when the printer is turned ON).
  • Page 39 ON the printer. Page Length, Default = 12" Selects the length of the paper you are using. This enables the printer to keep track of the initial printing position (TOF) on each page. Page Length Control, Default = by Menu Setting If you wish to use the Paper End sensor to detect the actual paper end, use Actual Page Length setting.
  • Page 40 Choose the character width in characters per inch (cpi). Power Save Time, Default = 5 min. Sets the interval the printer waits for more data before it goes into the power save mode. Power Saving must be set to Enable (the factory default) for this to be effective.
  • Page 41 Reset Inhibit, Default = No Select Yes if you wish the printer to ignore the reset command sent by software. This prevents your software from changing the settings you make through the front panel controls or through printer commands.
  • Page 42 Change to Double for double width and height printing. Skip Over Perforation, Default = No Change to Yes if you want the printer to go to the next page when it comes within 1" (25 mm) of the bottom of the page. Keep it set to No if your software has its own page formatting controls.

  • Page 43: Maintenance

    REPLACING THE RIBBON CARTRIDGE Important! Make sure you have the correct replacement ribbon for your printer. The wrong ribbon will not print when installed in your printer. Look for the printer model number on the ribbon package. RIBBON CARTRIDGE HANDLING Leave unused ribbon cartridges in their packages until needed.
  • Page 44 Turn the take-up knob (1) in the direction of the arrow to take up any ribbon slack. Close the access cover and turn the printer back on. If ribbon should contact the eyes: Flush eyes with large quantities of water for 15 minutes, keeping eyelids open with fingers.

  • Page 45: Loading Paper

    Loading Rear Feed Paper from the Back of the Printer These instructions assume you have ready access to the back of the printer. If you do not, go to “Loading Rear Feed Paper from the Front of the Printer.” Make sure the paper lever is forward (position marked “REAR”).
  • Page 46 Open the access cover (1). Grasp the sheet guide. Lift it slightly, then slide it back. Pivot the sheet guide forward and gently rest it against the roller assembly. Careful! If you push the sheet guide too hard against the roller assembly, it may dislodge it.
  • Page 47 From the back of the printer, locate the tractors (1). Open the lock levers (1) and move the right tractor (as viewed from the back of the printer) to the reference mark (2) matching the width of the paper you are loading. Then close...
  • Page 48 Place continuous forms paper on the first two pins of either tractor. Important! You must keep the number of paper holes engaged on either pin the same. If you don’t the paper will skew and jam. Close the right tractor cover. MAINTENANCE >...
  • Page 49 If the paper is too loose, or too tight, it can cause jams. Lower the sheet guide and slide it towards the front of the printer until the marks align. NOTE MAINTENANCE > 49...
  • Page 50 Loading Rear Feed Paper from the Front of the Printer These instructions assume you do not have ready access to the back of the printer. If you do, go back to “Loading Rear Feed Paper from the Rear of the Printer” earlier in this chapter.
  • Page 51 Make sure the paper lever is forward (position marked “REAR”). Open the access cover (1). Grasp the tabs and lift off the sheet guide. MAINTENANCE > 51...
  • Page 52 Pull up on the lock levers to release them. The movement of the left tractor (as viewed from the front of the printer) is restricted to ensure that the paper covers the paper out sensor. Move the left tractor to the position to match your paper size and push back on the lever to lock it in place, then move the right tractor to fit the width of the paper.
  • Page 53 Open the tractor covers and place continuous forms paper on the first two pins of either tractor, then close the left tractor cover. You must keep the number of paper holes engaged on either pin the same. If you don’t the paper will skew and jam. Adjust the position of the right tractor to center the holes in the paper on the pins.
  • Page 54 Reinstall the sheet feeder. MAINTENANCE > 54...
  • Page 55 Place the wire guide (1) in the sheet guide on the pull-up roller assembly. Press FF/LOAD. The factory default setting for the Top of Form (where the printing should begin) is 1" down from the top of the page. To change the setting, see “Top of Form (TOF)”...

  • Page 56: Top Feed (Single Sheets)

    If you have continuous form paper in the path, press PARK to remove it before loading single sheets. Make sure the printer is on and deselected (SEL light off). Move the paper lever (1) to the center position (marked “TOP”).
  • Page 57 Adjust the paper feed guides (1) for the width of the paper, then place a sheet of paper in the separator. The paper will feed into the printer. > If the paper does not feed in, remove it. Check the paper lever position.

  • Page 58: Clearing Paper Jams

    Use the platen knob to back the paper all the way out of the printer. Make sure the printer is turned OFF before you open the access cover. Open the access cover (1) and remove the pull-up roller assembly (2). Remove any torn paper.

  • Page 59: Rear Feed, Repeating Paper Jams

    Use the platen knob to back the paper all the way out of the printer. Tear off a couple of sheets of paper, leaving a new, clean, square-cut edge. Reload the paper and turn the printer back on. Fragments of Paper in the Paper Path Turn off the printer. MAINTENANCE > 59...
  • Page 60 Use the platen knob to back the paper all the way out of the printer. Make sure the printer is turned OFF before you open the access cover. Open the access cover (1) and remove the pull-up roller assembly (2). Then grasp the tabs (3) on the sheet guide (4) and lift it off the printer.
  • Page 61 Remove the paper pieces. Then, use the platen knob to back the paper out. Load standard paper, close and lock the tractor covers. Install the sheet guide, then install the pull-up roller assembly and close the access cover. Turn the printer on and press FF/LOAD. MAINTENANCE > 61...

  • Page 62: Single Sheet Paper Jams

    SINGLE SHEET PAPER JAMS Turn off the printer. Use the platen knob to back the paper out. Open the access cover (1) and remove the pull-up roller assembly (2). Remove any torn pieces from around the carriage. Reinstall the pull-up roller assembly and close the access cover.

  • Page 63: Cleaning The Housing

    Turn off the printer. Use the platen knob to back the paper out of the printer. Make sure the printer is turned off before you open the access cover. Open the access cover (1) and remove the pull-up roller assembly (2).
  • Page 64 Reinstall the pull-up roller assembly and close the access cover. MAINTENANCE > 64...

  • Page 65: Troubleshooting

    Is the ribbon properly installed? Is an Oki ribbon being used? Is the printhead gap correctly set? Are the correct printer drivers being used for the printer? > Settings in your software application will normally override any settings in your printer driver.
  • Page 66 Nothing happens when I turn ON the printer. Solution Check the power cord connection to the outlet and to the printer. If you are using a power strip, make sure it is turned ON, and that the fuse hasn’t blown or that the circuit breaker hasn’t tripped.
  • Page 67 I'm getting strange symbols, incorrect fonts, etc., when I try to print a document. Solutions Check to be sure that the printer driver you have selected in your software matches the printer emulation. Press SHIFT and SEL keys, then press GROUP key.

  • Page 68: Character Pitch Key

    Problem The ALARM light is flashing. Solution Try turning the printer OFF and then back ON again. If the light still blinks, call for service. Problem The ALARM light is ON and the Character Pitch 10 light is flashing.
  • Page 69 (Limited Function). If the printer is part of a customized system or if it is used by a number of people, the system manager may have used this option to make sure the printer is always set properly.

  • Page 70: Parts And Accessories

    Purchasing Parts & Accessories Before you purchase parts and accessories, make a note of your printer model number (see the front of the unit) and have the correct part number and description of the item you wish to purchase. Item descriptions and part numbers are provided in this section.
  • Page 71 Option Pull Tractor, Top-Mount (1) Push Tractor, Bottom-Mount (2) Roll Paper Stand (3) Cut Sheet Feeder (4) Single Bin Dual Bin Serial Interface RS232C (5) PARTS AND ACCESSORIES > 71 Part number Part number ML5590 ML5591 09002365 09002369 09002366 09002370 09002332 09000691 09000695...

  • Page 72: Printer Control Codes

    PRINTER CONTROL CODES This section lists the most commonly used printer control codes. You will find a comprehensive listing of the control codes (English only) on your Printer CD. To access it: Place the CD in your CD-ROM drive and wait for it to AutoPlay.
  • Page 73 ESC s 1 ESC s 0 ESC P 1 ESC P 0 ESC N n ESC O ESC } NUL PRINTER CONTROL CODES > 73 Decimal 27 67 0 n 27 67 n 27 52 27 53 27 64 27 97 48...
  • Page 74 ESC - 1 ESC - 0 ESC U 1 ESC U 0 ESC < ESC 6 ESC 7 PRINTER CONTROL CODES > 74 Decimal 27 83 49 27 83 48 27 84 27 45 49 27 45 48 27 85 49...

  • Page 75: Ibm Commands

    ESC ^ n ESC J n ESC J n ESC % 4 n ESC ] ESC 5 1 ESC 5 0 PRINTER CONTROL CODES > 75 Decimal 27 58 27 103 27 113 48 27 113 49 27 113 50...
  • Page 76 ESC S 0 ESC T ESC 4 ESC - 1 ESC - 0 ESC U 1 ESC U 0 PRINTER CONTROL CODES > 76 Decimal 27 48 27 49 n 27 65 n 27 65 n 27 50 27 51 n...

  • Page 77: Specifications

    SPECIFICATIONS Item Print Method Printhead Interfaces: Standard: Optional: Receive Buffer Size Reliability Ribbon Life Printhead Life Mean Time Between Failures (MTBF) Mean Time to Repair (MTTR) Emulations (co-resident) Print Speed High Speed Draft (HSD) Utility Letter Quality (LQ) Specification Impact dot matrix 24 pins, 0.20 mm (0.0079") diameter, with thermal protection Centronics parallel, IEEE-1284 compliant...
  • Page 78 Item Characters per Line (cpl) Setting 10 cpi 12 cpi 15 cpi 17.1 cpi 20 cpi Graphics Resolution Resident Fonts Letter Quality Utility Bar Codes Paper Thickness: Tractor Feed Rear Feed: Bottom Feed*: *requires optional push or pull tractor. Resident Typefaces: LQ Courier LQ Letter Gothic LQ Prestige...

  • Page 79: Paper Specifications

    Item Paper Specifications: Single (Cut) Sheets Feed: Weight: Width Range: Single-part, continuous forms Feed: Weight: Width Range: Carbonless continuous forms (orig. + 4 copies) Feed: Weight: Width Range: Interleaf continuous forms (orig. + 4 copies) Feed: Weight: Width Range: Labels Feed: Weight: Width Range:...
  • Page 80 Item Environmental Requirements Temperature Operating: Storage: Humidity Operating: Storage: Electrical Requirements Physical Specifications ML5590 Size: (WxDxH*): Weight: ML5591 Size (WxDxH*): Weight: Specification 41 to 95°F (5 to 36°C) 14 to 122°F (-10 to 50°C) 20 to 80% RH 5 to 95% RH 230 ac, (+15%, -14%) 50 or 60 Hz (±2%) 58W - typical, 10W - idle...

  • Page 81: Setting Up Your Printer

    SETTING UP YOUR PRINTER LOCATION Place your printer on a firm, solid surface. Allow enough space around the printer to easily access the platen knob and the various paper feed paths. Make sure a suitable grounded power outlet is available nearby.
  • Page 82 Remove any packing tape, then grasp the tabs (1) at either end of the access cover and pivot it towards the front of the printer as far as it will go. Remove the printhead shipping restraint. Remove the shipping restraint from the pull-up roller assembly (1).
  • Page 83 Use the tabs (1) to lift and remove the sheet guide, then remove the shipping restraint. Reinstall the sheet guide: insert the clips on either side of the separator into the notches marked with a triangle, then press down to secure the separator in place. SETTING UP YOUR PRINTER > 83...

  • Page 84: Installing The Ribbon Cartridge

    INSTALLING THE RIBBON CARTRIDGE Make sure you have the correct replacement ribbon for your printer. The wrong ribbon will not print when installed in your printer. RIBBON CARTRIDGE HANDLING Leave unused ribbon cartridges in their packages until needed. Careful; the ribbon ink may cause permanent stains.
  • Page 85 Do not remove the ribbon shield (1) from the ribbon. Turn the take-up knob (1) in the direction of the moulded arrow to take up any ribbon slack. Close the access cover and turn the printer ON. CAUTION! SETTING UP YOUR PRINTER > 85...

  • Page 86: Power Connection

    POWER CONNECTION Make sure both the printer and the computer are OFF. Plug the power cord into the back of the printer, then into a grounded outlet. Turn on the printer. SETTING UP YOUR PRINTER > 86...

  • Page 87: Computer Connections

    Make sure the printer and computer are both turned OFF. Attach a suitable bi-directional cable to the parallel connector on the back of the printer. Then attach and secure the cable to your computer. Turn the printer and computer back ON.

  • Page 88: Loading Paper

    Attach a suitable USB cable to the printer. Then attach the cable to your computer. Turn the computer and printer back on. LOADING PAPER For instructions on loading paper, see “Loading Paper” in the chapter on “Maintenance”. TESTING THE PRINTER...
  • Page 89 Make sure paper is loaded. Turn the printer OFF. Press and hold the LF key while turning the printer back ON. The printer will print a page of font samples and the test ends. CAUTION! SETTING UP YOUR PRINTER > 89...
  • Page 90 Wide carriage Model ML5591: If you are using 8.5 inch paper to run the tests, make sure the paper width selection in the printer menu is set to 8.5 inches. Otherwise, printing on the platen may damage the printer. See the chapter on “Menu Mode”...
  • Page 91 Hexadecimal Dump Mode When the printer is placed in the Hexadecimal Dump Mode, all data received, including text and printer commands, is printed in both hexadecimal and ASCII format. For example, the following line of BASIC code LPRINT CHR$ (27);”0”;CHR$ (30);”THIS IS AN EXAMPLE OF A HEXADECIMAL DUMP.”...

  • Page 92: Index

    Characters Per Second (CPS) ...6 Computer Connections...87 Electrical Requirements...80 Emulations ...27 Mode ...38 Envelopes...79 Environmental Requirements...80 Font Sample Test ...89 Fonts Embedded Printer Commands ..67 Resident...78 Selecting...40 Forms Tear-Off ...38 Top of Form ...19 Wait Time ...42 Graphics Printing ... 33 GROUP, Menu Mode...29 Height, Double Height Printing ...42...
  • Page 93 Reliability ...77 Ribbon Shield ... 44 Rolling ASCII Test...90 RS-232C Serial Interface ...77 Serial Interface Option ...66 Setting up your Printer ...81 Skip Over Perforation ...32 Software Embedded commands ...67 Matching drivers to emulations 67 Software vs. printer settings ...65 Symbol Sets ...39...
  • Page 94 Temperature Specifications...80 Testing the Printer ...88 Thickness, Paper...78 Time Out... 33 Top Feed...79 Bottom Margin ...33 Line Spacing ...33 Top of Form...35 Forms Tear-Off... 7 Paper Shield... 7 Typefaces Selecting...40 Uni-directional printing, graphics ...33 Unpacking ...81 USB, Specification 1.1 Compliant...87 Utility Front Panel Light...78...

  • Page 95: Oki Contact Details

    OKI CONTACT DETAILS Oki Systems (UK) Limited 550 Dundee Road Slough Trading Estate Slough, SL1 4LE Tel:44 (0) 1753 819819 Fax:44 (0) 1753 819899 http://www.oki.co.uk Oki Systems Ireland Limited The Square Industrial Complex Tallaght, Dublin 24, Ireland Tel:+353 1 4049590 Fax:+353 1 4049591 http://www.oki.ie OKI Systems (Ireland) Ltd...
  • Page 96 ML5590/91 Central House Balfour Road, Hounslow TW3 1HY United Kingdom tel +44 (0) 20 8219 2190 Fax +44 (0) 20 8219 2199 07044301 Iss.02...
