MAL615 Instructs.qxd
IMPORTANT: Be careful of electrical shock. Always remember that the lights may not switch on
during daylight or the lights may be in the automatic off mode. never touch live areas unless fuse
is removed or circuit breaker is in off position at the switchboard main.

Specifications

Detection Range
Time Adjustment
Detection Circuitry
Power Required
Maximum Load
Weatherproof Rating

Maintenance

To avoid dust build-up and ensure proper functioning of the Arlec Floodlight wipe the sensor lens lightly
with a damp cloth every 3 months. Do not use solvents or abrasive cleaners on any part of your
Floodlight.
Reducing Detection Area
To reduce the 120° wide-angle detection area, stick PVC electrical tape on the left, right or both
sides of sensor lens. This will reduce 120° detection in extremities of area to be scanned. After
adding PVC tape, further adjustment to sensor direction may be necessary.
Arlec Guarantee
Arlec guarantees this product against defects of materials and workmanship for a period of 1 year from the date of purchase
provided that the product is used in accordance with Arlec's recommendations and within such voltage and current limits as
are specified by Arlec in relation to the product. Arlec will at its own option make good, replace with the same or similar
product, or provide credit for any product manufactured or supplied by it, which proves to be defective within the limits set
out above provided that no repairs, alterations or modifications to the product have been undertaken or attempted, other than
by the company or its authorised agents. Should the purchaser wish to make a claim under the guarantee, the product should
be returned pre-paid to the place of purchase. This guarantee is in addition to and does not take away from any rights
available to the consumer under the Trade Practices Act and the State consumer protection legislation.
Proof of Purchase
Please retain your purchase receipt for all warranty claims.
For all Sales enquiries
Phone (03) 9727 8860 Fax 1300 350 650
© This instruction leaflet is subject to copyright and must not be reproduced,
copied or otherwise used in any way or for any purpose without the consent
in writing of the owner, Arlec Australia limited (A.C.N. 003 118 787).
1/9/05
12:18 PM
Page 2
15 metres at 120° scan
5 seconds to 8 minutes (approx.)
Passive controlled infra red motion
sensor
230-240 volt, 50Hz, 4 watt consumption
(sensor head only)
2 x 150 watt PAR38
IP43
6
CPIN628
