American Standard Enfield T373.730 Features & Dimensions

T373.730 Shown
242mm
(9-5/8)
R510
1/2 NPT
R530
3/4 NPT
1/2 NPT
3/4 NPT

GENERAL DESCRIPTION:

Cast brass valve body.
handle, which sets the desired temperature. The
temperature is maintained by a wax element moving a
shuttle valve between hot and cold. Includes Hot Limit
Safety Stop. Maximum temperature limit is 112°F.
Escutcheon plate is stamped brass. Available with 1/2"
or 3/4" NPT inlets and outlets. The valve has a high flow
rate, ideal for mutiple outlet installations.

SUGGESTED SPECIFICATION:

Central Thermostat shall feature a cast brass valve body. Thermostat shall be a wax element shuttle valve. Shall also feature 1/2"
or 3/4" NPT inlets and outlets. Fitting shall be American Standard Model # T373.73X.____ (Trim Kit) and R510 or R530 (Rough Valve).
© 2008 AS America Inc.
151mm
(5-7/8)
R510
R530
150mm
(5-7/8)
The single unit contains one

MODEL NUMBER:

TRIM KITS:

T373.732 Central Thermostat Trim Kit
Less volume control. With Cross handle. L ESS Valve.
T373.730 Central Thermostat Trim Kit
Less volume control. With Lever handle. L ESS Valve.

ROUGH VALVES:

R510 Rough Valve Body only
1/2" NPT inlets/outlets. L ESS Trim.
R530 Rough Valve Body only
3/4" NPT inlets/outlets. L ESS Trim.

NOTE:

• Requires separate on/off volume control.
• When used as a Bath/Shower:
EITHER
- a separate diverter valve (such as R420 or R430)
OR
- a diverter tub spout (requires twin ell - Model #8888.120)
IS REQUIRED
86mm
(3-3/8)
34mm
(1-3/8)
25mm
(1)

PRODUCT FEATURES:

Brass Casting:
& long life.
Wax Thermostatic Unit:
between the hot and cold seats to maintain the pre-selected
constant water temperature.
Back to Back Capable:
Spring-Loaded Check Valves:
water enters the fitting, both supplies pass through the
spring-loaded check valves to prevent cross flow of hot and
cold water.
Integrated Stop Valves:
Adjustable Hot Limit Safety Stop:
hot water allowed to mix with cold. Reduces the risk of
accidental scalding. Maximum water temperature limit may be
reduced to 104 or 109 degrees Fahrenheit.
F25
CENTRAL THERMOSTAT
LESS VOLUME CONTROL
193mm
(7-5/8)
48mm to 68mm
(2 to 2-5/8)
Highest quality faucet material for durability
Permits shuttle valve to move
Hot and cold can be reversed.
When the hot and cold
Ensure easy cleaning and servicing.
Limits the amount of
ENFIELD
