SMA SUNNY BOY 1300TL User Manual

CONTACT
If you have technical problems, first contact your installer. The following information is required in
order to provide you with the necessary assistance:
• Inverter device type
• Inverter serial number
• Type and number of PV modules connected
• Blink code or display message of the inverter
• Optional equipment (e.g. communication devices)
SMA Solar Technology AG
Sonnenallee 1
34266 Niestetal, Germany
www.SMA.de
SMA Serviceline
Inverters: +49 561 9522 1499
Communication: +49 561 9522 2499
Fax: +49 561 9522 4699
E-Mail: Serviceline@SMA.de
Installer contact

ExPLANATION Of SYMBOLS

Symbols on the Inverter
Operation Display.
Ground fault or varistor defective.
Please inform your installer.
An error has occurred. Please inform your installer immediately.
Tap to switch on the display light and switch to the next message.
Symbols on the Type Label
Beware of dangerous electrical voltage.
The inverter operates at high voltages. All electrical work on the inverter may be
carried out by qualified personnel only.
Beware of hot surface.
The inverter can become hot during operation. Avoid contact during operation.
Observe enclosed documentation.
The inverter must not be disposed of with household waste.
Further disposal information can be found in the enclosed installation guide.
CE mark. The inverter complies with the requirements of the applicable EC
guidelines.
RAL quality mark for solar products. The inverter complies with the requirements of
the German Institute for Quality Assurance and Labeling.
Direct Current (DC)
Alternating Current (AC)
The inverter is protected against penetration by dust particles and water jets from
any angle.
The inverter is transformerless.
ES
PV Inverter
SUNNY BOY 1300TL/1600TL/2100TL
User Manual
SB13_21TL-BA-BEN121021 | IME-SB21TL | Version 2.1
VISUAL INSPECTION, MAINTENANCE AND CLEANING
Visual inspection
Check the inverters and the cables for visible external damage. Contact your installer if you find any
defects. Do not perform any repair work yourself.
Maintenance and Cleaning
Ask your installer to check for correct inverter operation at regular intervals.
GLOSSArY
AC
Abbreviation for "alternating current".
DC
Abbreviation for "direct current".
Derating
A controlled reduction in performance, usually dependent on component temperatures.
OPTIONAL: Electronic Solar Switch (ESS)
The Electronic Solar Switch is an optional part of the inverter's DC disconnection unit. If the inverter
is equipped with an Electronic Solar Switch, the ESS must be securely inserted into the bottom of the
inverter. The Electronic Solar Switch may only be removed by qualified personnel.
Grid impedance
The grid impedance is a characteristic grid specification, which is determined both by the grid
infrastructure, and by the number of power suppliers and power consumers. If the supply for the
grid section should drop due to a grid shutdown of the preceding energy suppliers (medium-voltage
transformers), the grid impedance will change abruptly. In order to detect this and to prevent the
formation of an unwanted off-grid system, SMA Grid Guard monitors the grid impedance and
disconnects the inverter from the grid in the event of a sudden impedance variation.
MPP (Maximum Power Point)
Operational point of the inverter, dependent on current/voltage of the PV generator. The actual
position of the MPP changes constantly, depending on the level of solar irradiation and the cell
temperature.
PV
Abbreviation for photovoltaics.
Varistor
The varistors protect the electronics in the inverter from atmospherically coupled energy peaks, such as
those that can occur when lightning strikes nearby.
EN
