Features Congratulations, on your purchase of the SIRIUS TTR1C Internet Radio! Your new SIRIUS TTR1C Internet Radio comes with everything you need to enjoy SIRIUS Internet Radio in your home . Use this manual to familiarize yourself with all of your SIRIUS TTR1C Internet Radio features and capabilities .
Safety and Care Information IMPORTANT! Always read and understand all the instructions to avoid injury to yourself and/or damage to your device . Sirius Canada Inc . disclaims all responsibility for damage from data loss due to breakdown, repair, or other causes . • Do not expose to extreme temperatures (above 140ºF or below -4ºF, or above 60ºC or below -20ºC) .
Page 8
Introduction stoves, or other apparatus (including amplifiers) that produce heat . • Do not defeat the safety purpose of the polarized or grounding type plug . A polarized plug has two blades with one wider than the other . A grounding type plug has two blades and a third grounding prong .
Introduction SIRIUS TTR1C Internet Radio Functions Power Button (page 26) TUNE Knob (Multifunction) (page 26) Turn radio On and Off . Turning the knob at the default display screen displays the category tune screen; pressing the knob at the default display screen displays the direct tune screen;...
Page 11
Snooze/Sleep Timer Button (page 27) Wireless Antenna Mutes the alarm, or sets the sleep timer, for 5, 10, 15, 30, 45, Headphone Connector or 60 minutes . Aux In Connector Rear Compartment Wired Ethernet Connector Line Out Connector...
Introduction Remote Control Power Button Turn radio On and Off . Arrow Buttons Press to scroll through lists; also highlight menu options . OK Button Press to select channel list and menu items . +/— Buttons Press to increase or BACK MUTE decrease the audio volume .
Display Screen When using the SIRIUS TTR1C Internet Radio, information about songs and artists, and radio functions are displayed . Category or Channel List Screen Menu Options Screen SIRIUS 017 5:23PM Main Display Screen Current Time Jam_ON Channel Number Channel Name...
Installation Introduction The SIRIUS TTR1C Internet Radio allows you to listen to all of the channels on your Premium SIRIUS Internet Radio subscription package using either a wireless Internet connection (Wi-Fi), or using a wired Ethernet connection . You must be subscribed to the SIRIUS Satellite Radio service to use the SIRIUS TTR1C Internet Radio .
Step 1: Connect to a Network The Network Wizard feature is the easiest way to connect to a wireless network . It searches for available wireless networks and displays a list of wireless networks found for you to select . However, if your wireless network name (SSID) is hidden, or if your network is DHCP disabled, you’ll have to manually enter the network settings rather than using the Network Wizard .
Page 18
. If you have just turned your SIRIUS TTR1C Internet Radio on for the first time, the SSID screen will already be displayed . Skip ahead to step e .
If you have entered the wrong key, the Incorrect key screen is displayed, and you will be prompted to enter the key again . If you are installing your SIRIUS TTR1C Internet Radio for the first time, continue with “Step 2: Enter Your SIRIUS Account...
Page 20
Installation If you have previously entered your SIRIUS user name and key into the radio, and had tuned to a channel, the screen will show Connecting . When successfully connected, the Buffering . . . screen will be displayed as the channel information is streamed to the radio . When complete, you are returned to the main display screen and you should hear the audio playing .
Page 21
Connect the other end of the Ethernet cable to your home’s wired network . If you have turned your SIRIUS TTR1C Internet Radio on for the first time, the SSID screen will already be displayed . Skip ahead to step g .
Page 22
Installation is displayed, check the Ethernet cable Network settings connections . If you are installing your SIRIUS TTR1C Waiting for Internet Radio for the first time, continue Ethernet with “Step 2: Enter Your SIRIUS Account Information” on page 23 .
Page 23
Step 2: Enter Your SIRIUS Account Information The SIRIUS TTR1C Internet Radio needs your account user name and password to connect to SIRIUS Internet Radio service . If are not yet subscribed to the SIRIUS Satellite Radio service, go to www .sirius . c a or call 1-888-539-7474 to subscribe, and get your user name and password .
Page 24
Installation When you have entered your user name, turn the TUNE knob to scroll to highlight OK and press the TUNE knob . You will then be prompted to enter your password . Enter your password in the same way as you entered your user name and then select OK .
Using Your SIRIUS TTR1C Radio Navigation Basics Power Button The Power button turns the SIRIUS TTR1C Internet Radio On or Off . Tune Knob TUNE The TUNE knob is multifunction— you can turn it clockwise or counter- clockwise, and press it .
Page 27
BACK BACK Button The BACK button returns back to the previously displayed screen . MENU Button MENU Pressing the MENU button from the main display screen accesses the advanced features and configuration options menu, where you can browse the channel categories and channels, and change the radio settings . Pressing it when in the configuration options menu returns the radio to the main display screen .
Page 28
Using Your SIRIUS TTR1C Radio Listening to SIRIUS Internet Radio Tune a Channel: All channels Press MENU . 001-SIRIUS Hits 002-The Blend Press the TUNE knob to select Category 003-SIRIUS Love Tune . 004-40s on 4 Press the TUNE knob to select All...
Page 29
Press the TUNE knob to select Category Tune . Turn the TUNE knob to browse 001-SIRIUS Hits 1 through and highlight a category . 002-The Blend Press the TUNE knob to select the 003-SIRIUS Love category and view the channels in the 004-40s on 4 category .
Using Your SIRIUS TTR1C Radio Direct Tune A channel can be tuned directly by entering the channel number . From the main display screen, press the Direct Tune TUNE button . BKSP Use the 0-9 number buttons on the radio or Remote Control to enter the channel number .
Favourite Channels You can assign up to 10 of your favourite channels to a number button (0-9) so you can easily tune them . To assign a favourite channel to a number button: Tune to the channel you want as a favourite .
Using Your SIRIUS TTR1C Radio Alarm Clock Your SIRIUS TTR1C Internet Radio has two alarm 4:54 clocks which can be configured according to your liking . When the radio is off, and the alarm(s) are on, the times of each alarm are displayed on the screen .
Page 33
The Alarms screen summarizes each alarm clock setting . To configure an alarm, turn the TUNE knob to scroll to and highlight Alarm 1 or Alarm 2 . Press the TUNE knob . Each alarm has 5 configuration options which are summarized in the following table at the beginning of this section .
Using Your SIRIUS TTR1C Radio Snooze When the alarm sounds, pressing the Sleep/Snooze button will silence the alarm for a period of time . After the snooze time elapses, the alarm will sound again . To snooze: Press the Snooze/Sleep button on the top Set snooze time of the radio .
Sleep Timer The sleep timer turns the radio off after a period of time as you fall asleep . The time can be set to turn the radio off after 5, 10, 15, 30, 45, or 60 minutes . To turn the sleep timer On: Set sleep time Press the Snooze/Sleep button on the top of the radio .
Parental locked . To change the parental lock code: The SIRIUS TTR1C Internet Radio has a default lock code of 1111 . The first time you change the lock code, you’ll need to enter this code during the procedure .
Page 37
Turn the TUNE knob to highlight Change lock code . Press the TUNE knob . You will be prompted to enter the original lock code . If this is the first time you are changing the lock code, enter 1111, otherwise enter your existing lock code .
Page 38
Using Your SIRIUS TTR1C Radio Press MENU to exit . To turn Parental control Off: Press and hold the TUNE knob . Lock/Unlock will be highlighted . Press the TUNE knob . You will be prompted to enter your 4-digit lock code . Use the 0-9...
Page 39
To lock or unlock channels: Press and hold the TUNE knob . Turn the TUNE knob to scroll through the list and highlight Lock channels . Press the TUNE knob . If parental control is On (locked), you will be prompted to enter your 4-digit code, otherwise skip to step 4 .
Page 40
Using Your SIRIUS TTR1C Radio To unlock a channel, highlight a locked channel and press the TUNE knob . The L lock indicator will be removed Parental lock indicating that the channel is unlocked . Save parental Continue to lock or unlock channels until lock list? you are done .
Page 41
knob to erase the character . When you have selected all 4 digits of your code, turn the TUNE knob to highlight OK and press the TUNE knob . Category Tune If you have entered the correct lock code, the channel will begin playing . Parental lock is off Once you have unlocked one channel, all locked channels become unlocked and will remain...
Using Your SIRIUS TTR1C Radio Audio Settings In the Audio Settings menu option, you can adjust the equalization profile of the radio (EQ) to adjust for room acoustics and your listening pleasure . The profiles for equalization are Flat, Loudness, Bass Boost, Bright, Audio Settings and Vocal Boost .
Page 43
To turn spatialization on or off: Press MENU . Turn the TUNE knob to scroll to and Spatialization highlight Audio Settings . Press the TUNE knob . Spatialization Turn the TUNE knob to scroll to and highlight Spatialization . Press the TUNE knob .
Configuring Your SIRIUS TTR1C Radio SIRIUS setup The SIRIUS setup menu option allows you to configure your user name and password for the SIRIUS Internet Radio service . You SIRIUS setup can also check the status of your connection .
Page 47
Turn the TUNE knob to scroll to and highlight SIRIUS setup . Press the TUNE knob . User name will be highlighted . Press the TUNE knob . Turn the TUNE knob to scroll through User name the list of characters and highlight each character for your user name .
Page 48
Configuring Your SIRIUS TTR1C Radio Turn the TUNE knob to scroll through the list of characters and highlight each character for your Password password . The password is case sensitive . Press the TUNE knob to select the 0123456789 abcd...
Page 49
Status The Status screen shows the current status of your Premium SIRIUS Internet Radio service, the user name you are using, and the bit rate of your connection . To display the status: Press MENU . Status Turn the TUNE knob to scroll to and Active highlight SIRIUS setup .
Configuring Your SIRIUS TTR1C Radio System Setup The System Setup menu option offers the following menu items: System Setup SIRIUS page 51 AUX in page 51 SIRIUS Alarms page 52 AUX in Alarms Alarm 1: page 52 Brightness Alarm 2:...
SIRIUS and AUX in These two menu options select what the radio will play— SIRIUS selects the SIRIUS Internet Radio service to be played, and AUX in selects the auxiliary input to be played . You can connect a CD or MP3 player to the AUX In connector, and listen to it .
Configuring Your SIRIUS TTR1C Radio Alarms Before setting any alarms, refer to “Clock Setup” on page 53 and ensure that the clock is set correctly, i .e ., the Time Zone and Daylight Savings Time are set correctly for your location . Then refer to “Alarm Clock” on page 32 for information about the alarm clocks .
Clock Setup Clock Setup allows you to change the clock settings: Clock Setup • Set Time/Date - Change the time and/ or date . Set Time/Date Auto Update • Auto Update - Synchronize the clock via Time Zone > the Internet Yes or No . Yes is the default Daylight savings and preferred setting .
Configuring Your SIRIUS TTR1C Radio To set Auto Update: Press MENU . Turn the TUNE knob to scroll to and highlight System Setup . Press the TUNE knob . Turn the TUNE knob to scroll to and highlight Clock Setup . Press the TUNE knob .
Turn the TUNE knob to scroll to and highlight the time zone you are in . Press the TUNE knob . Time Zone Eastern > Press MENU to exit . Central Mountain Pacific Alaska To set daylight savings time: Press MENU . Turn the TUNE knob to scroll to and highlight System Setup .
TUNE knob to highlight and select: System Setup Network View settings . The MAC address of the SIRIUS TTR1C Internet Radio will be displayed . Refer to one the following sections for detailed instructions on using the Network Wizard to connect to a network:...
• For connecting to a wireless network, refer to “To connect to a wireless network using the Network Wizard” on page 18 . • For connecting to a wired network, refer to “To connect to a wired network using the Network Wizard:” on page 21 . View settings: View Settings displays information about your network connection, including the type of connection, the status, the radio’s MAC address, and other...
Configuring Your SIRIUS TTR1C Radio Manual Settings: Refer to one the following sections for detailed instructions on using the Manual Settings to connect to a network: • For connecting to a wireless network, refer to “Connect to a Wireless Network Using Manual Settings” on page 66 .
Page 59
Turn the TUNE knob to scroll to and highlight Network . Press the TUNE knob . Turn the TUNE knob to scroll to and highlight Network profile . Press the TUNE knob . The saved wireless network names will be displayed . If you wish to delete a profile, turn the TUNE Confirm delete knob to scroll to and highlight a...
Configuring Your SIRIUS TTR1C Radio Factory reset Factory reset restores the SIRIUS TTR1C Internet Radio to the factory settings . It will erase all the stored network settings, account user name and password, favourite channels, alarm clock settings, lock code, and set all other options back to the factory settings .
. By default, the SIRIUS TTR1C Internet Radio is set to automatically check for updates . If it finds a software update, you’ll be prompted that a new software is available . You can change this setting so the radio will not automatically check for updates .
Configuring Your SIRIUS TTR1C Radio want the radio to check for software updates . Turn the TUNE knob to highlight YES or NO and press the TUNE knob . Press MENU to exit . To force the radio to check for a software update: Press MENU .
Page 63
Updating the software: Software update If you manually force the radio to check for a New version available. software update, or the radio automatically finds Update Software? a software update, and you want to update the software, follow these steps . The Software update screen is Software update displayed .
Configuring Your SIRIUS TTR1C Radio The radio will start with the new software . Software update Update Completed Press OK/Select Info Info displays the software version number, and the Radio ID number . To display the information: Press MENU .
Appendix: Manual Network Configuration Connecting to a network using the Manual settings requires some knowledge of your network . You’ll need to manually configure your network connection using the Manual Settings or [Manual config] option if your wireless network name (SSID) is hidden, or if your network is DHCP disabled .
Page 67
If you have just turned your SIRIUS TTR1C Internet Radio on for the first time, the SSID screen will already be displayed . Skip ahead to step d . Press MENU and turn the TUNE knob to highlight System Setup .
Page 68
Appendix: Manual Network Configuration IP settings iii . Enter the Gateway IP address for the IP address network . . 0 . 0 . 0 iv . Enter the Primary DNS IP address for Subnet mask the network . 255 255 . 255 . 0 v .
Page 69
disabled . Turn the TUNE Knob to highlight your selection and press the TUNE knob . ii . Enter your key (password) . Turn the TUNE knob to scroll through the list of characters and highlight each character . Press the TUNE knob to select the highlighted character and move to the next character .
Page 70
. If not, the Failed to connect screen is displayed . This means that one or more of the settings you entered is incorrect . If you are installing your SIRIUS TTR1C Internet Radio for the first time, continue with “Step 2: Enter Your SIRIUS Account Information” on page 23 .
Page 71
Connect the other end of the Ethernet cable to your home’s wired network . If you have just turned your SIRIUS TTR1C Internet Radio on for the first time, the SSID screen will already be displayed . Skip ahead to step f .
Page 72
Appendix: Manual Network Configuration Connection type Turn the TUNE Knob to highlight Wired . Press the TUNE Knob . Wired > Wireless > Will you be using DHCP? Turn the TUNE Knob to highlight DHCP enable or DHCP disable and press the TUNE Knob . If you have selected DHCP disable, enter the following information .
Page 73
. If Waiting for Ethernet is displayed, check the Ethernet cable Connected connections . If you are installing your SIRIUS TTR1C Internet Radio for the first time, continue with “Step 2: Enter Your Network settings SIRIUS Account Information” on page 23 .
Troubleshooting Your SIRIUS TTR1C Internet Radio has been designed and built to be trouble-free but if you experience a problem, here’s some troubleshooting hints . You can also call SIRIUS Customer Care at 1-888-539-7474 . If you see this on the screen:...
Page 77
If you see this on the screen: Try this: Waiting for Ethernet • The radio is expecting a wired Ethernet connection . Plug an Ethernet wire into your home network, then plug the other end into the Ethernet connection inside the compartment at the rear of the radio .
Page 78
Troubleshooting If you see this on the screen: Try this: Failed to connect • The network information you entered is incorrect . Verify and re-enter the information . (Refer to page 17 for a wireless network, or page 21 for a wired network .) • You have entered an incorrect password for a secure wireless network .
Page 79
If this happens: Try this: The Network Wizard fails before • Your network has DHCP disabled . You’ll have to the radio connects to your manually configure your network connection . network (Refer to page 66 for a wireless network, or page 71 for a wired network .) The Network Wizard does not find • Your wireless network has a hidden name (SSID) .
Product Specifications Dimensions SIRIUS TTR1C Internet Radio 283 mm (W) x 185 mm (H) x 95 mm (D) 11 in (W) X 7 .25 in (H) X 3 . 7 5 in (D) Remote 52 mm (W) x 85 mm (H) x 5 mm (D) 2 in (W) x 3 .3 in (H) x .25 in (D)
Patent and Environmental Information Patent Information It is prohibited to, and you agree that you will not, copy, decompile, disassemble, reverse engineer, hack, manipulate, or otherwise access and/ or make available any technology incorporated in this product . Furthermore, the AMBE voice compression software included in this product is protected ®...
FCC Statement The user is cautioned that changes or modifications not expressly approved by Sirius Canada Inc . can void the user’s authority to operate this device . This device complies with Part 15 of the FCC Rules: 1 . This device may not cause harmful interference . 2 .
Page 85
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device . To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for successful communication This device has been designed to operate with an antenna having a maximum gain of...
