What's in the box
a Main unit and front panel (with a sleeve)
c ISO standard connector
e 1 x Screw
g User manual
Connect wires
1
Check the car's wiring carefully, and then connect them to the supplied ISO wires.
Connector Connect to
1 Yellow wire The +12V car battery which is live at all times
2 Blue/White wire The electric antenna control lead or power supply lead of the antenna booster. If
there is no electric antenna or antenna booster, or it is manually operated telescopic
antenna, it is unnecessary to connect this lead.
3 Black wire A metal surface of the car. Connect the black ground (earth) lead before connecting
the yellow and red power supply leads.
4 Red wire The +12V power terminal which is live in the accessory (ACC) position of the ignition
switch. If there is no accessory position, connect to the +12V car battery terminal that
is always live. Make sure that the black ground (earth) lead is connected to a metal
VXUIDFH RI WKH FDU ÀUVW
5 Green and Left speaker (rear)
green/black wires
6 White and white/ Left speaker (front)
black wires
7 Gray and gray/ Right speaker (front)
black wires
8 Purple and Right speaker (rear)
purple/black
wires
2
Connect the other end of the supplied standard connector to the car audio system.
Connector
1 ANTENNA
2 External Mic
3 SUBWOOFER (Socket)
4 REAR LINE OUT L (Socket)
Á
Quick start guide
5 REAR LINE OUT R (Socket)
6 OE REMOTE (Brown)
7 FRONT LINE OUT L
b Trim plate
8 FRONT LINE OUT R
d Rubber cushion
f 2 x Disassembly tools
Mount into the dashboard
h Quick start guide
If the car does not have an on-board drive or navigation computer, disconnect the negative terminal of the car
battery.
‡ If you disconnect the car battery in a car that has an on-board drive or navigation computer, the
computer may lose its memory.
‡ If the car battery is not disconnected, to avoid short-circuit, make sure that the bare wires do not
touch each other.
1
Make sure that car dashboard opening is within these measurements:
2
,QVWDOO WKH VOHHYH LQWR WKH GDVKERDUG DQG EHQG WKH WDEV RXWZDUG WR À[ WKH VOHHYH
Note
‡ ,I WKH V\VWHP LV QRW À[HG E\ VOHHYH EXW E\ WKH VXSSOLHG VFUHZV VNLS WKLV VWHS
3
Place the supplied rubber cushion over the end of the mounting bolt.
4
Slide the system into the dashboard until you hear a "click".
5
Attach the trim plate.
6
Reconnect the negative terminal of the car battery.
Turn on
Press .
» [WELCOME] scrolls.
‡ To turn off the system, press and hold
Set the clock
1
Press and hold to access the system menu.
2
Press repeatedly until [CLOCK] and the current time is displayed.
» If the clock is not set before, [00:00] is displayed.
3
Connect to
Rotate to set the hour.
4
Antenna for radio
Press WR FRQÀUP
5
An external microphone for phone call
Rotate to set the minute.
Subwoofer 6
Press WR FRQÀUP
Rear left speaker
MP3-LINK
Rear right speaker
OE remote
Front left speaker
Front right speaker
until [GOODBYE] is displayed.
