- Page 1 USERS GUIDE DXE-CAT-S1 HDMI HDBaseT CAT Extender 70m (230ft) Manual Number: 130305...
-
Page 2: Safety Instructions
User Guide SAFETY INSTRUCTIONS Please review the following safety precautions. If this is the first time using this model, then read this manual before installing or using the product. If the product is not functioning properly, please contact your local dealer or Aurora for further instructions. The lightning symbol in the triangle is used to alert you to the presence of dangerous voltage inside the product that may be sufficient to constitute a risk of electric shock to anyone opening the case. -
Page 3: Table Of Contents
User Guide TABLE OF CONTENTS PACKAGE CONTENTS ......................1 INTRODUCTION ........................2 About ..............................2 Features ..............................2 Front & Rear Panel DXE-CAT-TX1 ....................... 3 Front & Rear Panel DXE-CAT-RX1 ...................... 4 IR EXTENDERS ......................... 5 IR Connections ............................. 5 IR Jack Pinout ............................ -
Page 4: Package Contents
User Guide PACKAGE CONTENTS Please make sure the following items are included within your package. Contact your dealer if any items are missing or damaged. • DXE-CAT-RX1 x 1 • DXE-CAT-TX1 x 1 • DXE-CAT-E1 Wall / Desk Mount Ears x 4 •... -
Page 5: Introduction
INTRODUCTION About The DXE-CAT-S1 is part of the growing Digital Xtreme Series. This product is different than the typical CAT extender found on the market today as it not only breaks the price barrier but the feature and usability aspects as well. All connectors are on one side to make wiring cleaner and rack mounting easier. -
Page 6: Front & Rear Panel Dxe-Cat-Tx1
User Guide Front & Rear Panel DXE-CAT-TX1 Front LED Indicators • IR Out – Blinks when emitting IR to device from IR Port. It is normal to be lit if nothing is plug into IR port. • IR In – Blinks when receiving IR from IR port. It is normal to be lit if nothing is plug into IR port. •... -
Page 7: Front & Rear Panel Dxe-Cat-Rx1
User Guide Front & Rear Panel DXE-CAT-RX1 Front LED Indicators • IR Out – Blinks when emitting IR to device from IR Port. It is normal to be lit if nothing is plug into IR port. • IR In – Blinks when receiving IR from IR port. It is normal to be lit if nothing is plug into IR port. •... -
Page 8: Ir Extenders
User Guide IR EXTENDERS IR Blaster IR Receiver IR Connections The DXE-CAT Series has the ability to auto detect on the IR port if a receiver or a blaster / emitter is connected. IR Blaster / Emitter: Plug in an IR blaster to emit all IR command signals received from the IR receiver to control the associated devices with built-in IR sensor IR Receiver: Plug in an IR receiver to receive all IR command signals from the IR remote controls of the associated devices. -
Page 9: Connector Pin Definition
User Guide CONNECTOR PIN DEFINITION HDMI Pin 1 TMDS Data2+ Pin 8 TMDS Data0 Shield Pin 15 Pin 2 TMDS Data2 Shield Pin 9 TMDS Data0– Pin 16 Pin 3 TMDS Data2– Pin 10 TMDS Clock+ Pin 17 DDC/CEC Ground Pin 4 TMDS Data1+ Pin 11 TMDS Clock Shield... -
Page 10: Appendix 1
User Guide APPENDIX 1 Troubleshooting Problem Solution a. Check that the power plug is properly inserted into a functioning power outlet. 1. No Video Signal. b. Make certain source is on. c. Verify pin-out of connector at each end. a. Check 24v power supply is plugged in. 2. -
Page 11: Appendix 2
User Guide APPENDIX 2 Technical Specifications Model Name DXE-CAT Technical DXE-CAT-S1 Distance 230ft 1080p 60Hz Max Resolution 1920 x 1200 4k x 2k Color Depth 36bit RS-232 Max 115kbps IR without LXC 38kHz HDMI 3D, HDCP Compliant Power, Status, HDMI, HDBaseT,... -
Page 12: Appendix 3 Warranty
Limited 3 Year Warranty Aurora Multimedia Corp. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year of 2009 and after. - Page 13 User Guide This product warranty extends to the original purchaser only and will be null and void upon any assignment or Aurora Multimedia Corp. 205 Commercial Court Morganville, NJ 07751 Phone: 732-591-5800 Fax: 732-591-6801...
