i9010
Smoke Alarm User's Guide
Lithium (non-replaceable sealed in) Battery-Operated
Smoke Alarm with Alarm Memory and SMART HUSH
Control to temporarily silence nuisance alarms.
Thank you for purchasing this smoke alarm. It is an important
part of your family's home safety plan. You can trust this prod-
uct to provide the highest quality safety protection. We know
you expect nothing less when the lives of your family are at
stake.
For your convenience, write down the following
information. If you call our Consumer Hotline,
these are the first questions you will be asked.
Smoke Alarm Model Number
(located on back of alarm):
Date Code (located on back of alarm):
The National Fire Protection Association
(NFPA) and the manufacturer
recommend replacing this alarm
ten years from the date code.
Date of Purchase:
Where Purchased:
For model: i9010
Manual P/N 21008311-EN Rev. A
TM
0910-7225-00
Advertisement
Table of Contents
Related Manuals for Kidde i9010
Summary of Contents for Kidde i9010
- Page 1 For model: i9010 i9010 Smoke Alarm User’s Guide Lithium (non-replaceable sealed in) Battery-Operated Smoke Alarm with Alarm Memory and SMART HUSH Control to temporarily silence nuisance alarms. Thank you for purchasing this smoke alarm. It is an important part of your family’s home safety plan. You can trust this prod- uct to provide the highest quality safety protection.
-
Page 2: Recommended Locations For Alarms
This alarm detects products of combustion using the ionization technique. It contains 0.9 microcurie of Americium 241, a radioac- tive material (see Section 9). Distributed under U.S. NRC License No. 32-23858-01E. Manufactured in compliance with U.S. NRC safety criteria in 10 CFR 32.27. The purchaser is exempt from any regulatory requirements. - Page 3 The closed door may prevent an alarm not located in that room from waking the sleeper. • Smoke, heat, and combustion products rise to the ceiling and spread horizontally. Mounting the smoke alarm on the ceiling in the center of the room places it closest to all points in the room. Ceiling mounting is preferred in ordinary residential construction.
-
Page 4: Mobile Home Installation
• Install Smoke Alarms on sloped, peaked or cathedral ceilings at or within 3ft (0.9m) of the highest point (measured horizontally). NFPA 72 states: “Smoke alarms in rooms with ceiling slopes greater than 1 ft in 8 ft (.3m in 2.4 m) horizontally shall be located on the high side of the room.”... -
Page 5: Installation Instructions
• In insect-infested areas. • Smoke alarms should not be installed within 3 ft (.9m) of the fol- lowing: the door to a kitchen, the door to a bathroom containing a tub or shower, forced air supply ducts used for heating or cool- ing, ceiling or whole house ventilating fans, or other high air flow areas. -
Page 6: Activating The Alarm
2.After selecting the proper smoke alarm location as described in Section 1, attach the mounting bracket to the ceiling as shown in figure 3. For wall mounting see figure 4. Place the mounting plate on the wall; be sure the “A” line is horizontal (parallel to the floor). -
Page 7: Operation And Testing
7). When the posts are broken off, the tamper resist on the base is allowed to engage the mounting bracket. Rotate the alarm onto the mounting bracket until you hear the tamper resist tab snap into place, locking the alarm on the mounting bracket. Using the tamper resist feature will help deter children and others from removing the alarm from the bracket. -
Page 8: Nuisance Alarms
CAUTION: BEFORE USING THE ALARM SMART HUSH FEA- TURE, IDENTIFY THE SOURCE OF THE SMOKE AND BE CER- TAIN A SAFE CONDITION EXISTS. FLASHING LED LIGHT: This smoke alarm is equipped with a flash- ing red indicator light with four modes of operation: •... -
Page 9: Maintenance
(non-recirculating type) will also help remove these combustible products from the kitchen. This model i9010 has a SMART HUSH control that is extremely useful in a kitchen area or other areas prone to nuisance alarms. -
Page 10: Limitations Of Smoke Alarms
Break out the crosshatched area with a screwdriver or similar tool. Using a screwdriver or similar tool slide the exposed piece towards the center of the alarm. This will deactivate the alarm, stop the low battery “chirp” and render the alarm safe for disposal by draining the battery. -
Page 11: Good Safety Habits
For maximum protection, Kidde recom- mends that both Ionization and Photoelectric alarms be installed. • A battery powered alarm must have a battery of the specified type, in good condition and installed properly. • AC powered alarms (without battery backup) will not operate if the AC power has been cut off, such as by an electrical fire or an open fuse. -
Page 12: What To Do When The Alarm Sounds
• Familiarize everyone with the sound of the smoke alarm and train them to leave your home when they hear it. • Practice a fire drill at least every six months, including fire drills at night. Ensure that small children hear the alarm and wake when it sounds. -
Page 13: Nrc Information
9. NRC INFORMATION Ionization type smoke alarms use a very small amount of a radioactive element in the sensing chamber to enable detection of visible and invisible combustion products. The radioactive element is safely contained in the chamber and requires no adjustments or maintenance. This smoke alarm meets or exceeds all government standards. -
Page 14: Service And Warranty
If after reviewing this manual you feel that your smoke alarm is defective in any way, do not tamper with the unit. Return it for servicing to: KIDDE Safety, 1016 Corporate Park Dr., Mebane, NC 27302. 1-800-880-6788 (See Warranty for in-warranty returns). -
Page 15: Ten Year Limited Warranty
The obligation of KIDDE Safety under this warranty is limited to repairing or replacing the smoke alarm or any part which we find to be...
