Smoke Alarm
User Guide
Model: i9030, i9040, i9040RV i9050, i9060,
ATTENTION: Please take a few minutes to thoroughly read this
User Guide which should be saved for future reference and
passed on to any subsequent owner.
P/N 0930-7206-02 EN
i9060RV and i9080
i9030
i9050
• 9 Volt Battery Operated
i9060
and
i9060RV
i9040
and
i9040RV
i9080
SIGNALING
U L
LISTED
Advertisement
Table of Contents
Related Manuals for Kidde i9040RV
Summary of Contents for Kidde i9040RV
- Page 1 SIGNALING LISTED Smoke Alarm User Guide Model: i9030, i9040, i9040RV i9050, i9060, i9060RV and i9080 i9040 i9040RV i9030 i9060 i9050 i9080 i9060RV • 9 Volt Battery Operated ATTENTION: Please take a few minutes to thoroughly read this User Guide which should be saved for future reference and passed on to any subsequent owner.
-
Page 2: What To Do When The Alarm Sounds
What to do When the Alarm Sounds! Smoke Alarm Procedure NEVER IGNORE THE SOUND OF THE ALARM! Smoke alarms are designed to minimize false alarms. Cigarette smoke will not normally set off the alarm, unless the smoke is blown directly into the alarm. Combustion particles from cook- ing may set off the alarm if it is located too close to the cook- ing area. - Page 3 Welcome i9030, i9040, i9040RV, i9050, i9060, i9060RV, - 9 Volt Battery Operated Smoke Alarm with “HUSH” Control to temporarily silence nuisance alarms. i9080 - 9 Volt Battery Operated Smoke Alarm with “HUSH” Control to temporarily silence nuisance alarms and with Battery Powered Safety Light.
-
Page 4: Product Specifications
Product Specifications This alarm detects products of combustion using the ionization tech- nique. It contains 0.9 microcurie of Americium 241, a radioactive materi- al (see section 9). Distributed under U.S. NRC License No. 32-23858-01E. Manufactured in compliance with U.S. NRC safety criteria in 10 CFR 32.27. -
Page 5: Recommended Locations For Smoke Alarms
1. Recommended Locations for Smoke Alarms • Locate the first alarm in the immediate area of the sleeping rooms. Try to monitor the exit path as the sleeping rooms are usually farthest from the exit. If more than one sleeping area exists, locate additional alarms in each sleeping area (See FIGURE •... - Page 6 1. Recommended Locations for Smoke Alarms • Put smoke alarms at both ends of a hallway or large room if the hall- way or room is more than 30 ft (9.1 m) long. For large rooms, one smoke alarm is recommended for every 500 square feet of floor space.
-
Page 7: Locations To Avoid
2. Locations To Avoid • In the garage. Products of combustion are present when you start your automobile. • Less than 4” (10cm) from the peak of an “A” frame type ceiling. • In an area where the temperature may fall below 40ºF or rise above 100ºF, such as garages and unfinished attics;... -
Page 8: Installation Instructions
3. Installation Instructions mounting i9030 mounting bracket for all bracket shown other models FIGURE 5 FIGURE 5A FIGURE 6 The “A” line should be hori- zontal and the “UP FOR WALL MOUNTING” arrow must be pointing up. 5º FIGURE 6A FIGURE 7 FIGURE 7A When wall mounting,... -
Page 9: Mounting Instructions
7. USING TAMPER RESIST LOCKING PIN (all models except i9040 and i9040RV): To make your smoke alarm tamper resistant, a locking pin has been provided in the bag with the screws and anchors. Using this pin will help deter children and others from removing the alarm from the mount- ing plate. -
Page 10: Operation And Testing
Models i9060, i9060RV and i9080 are desensitized by pushing the “HUSH” button on the smoke alarm cover. Models i9030, i9040, i9040RV and i9050 are desensitized by pushing the TEST/HUSH button on the cover. If the smoke is not too dense, the alarm will silence immediately and the Red LED will flash once every 10 seconds for approximately 8 minutes. -
Page 11: Nuisance Alarms
PANASONIC 6AM6, 6AM-6,6AM-6PI, 6AM6X, AND 6LR61(GA) Models i9040RV and i9060RV are powered by a 9V alkaline battery. A fresh battery should last for one year under normal operating conditions. This alarm has a low battery monitor circuit which will cause the alarm to “chirp”... - Page 12 6. Maintenance USE ONLY THE FOLLOWING 9 VOLT BATTERIES FOR i9040RV AND i9060RV SMOKE ALARM BATTERY REPLACEMENT: Alkaline type: ENERGIZER 522; PANASONIC 6AM6, 6AM-6, 6AM-6PI, 6AM6X, AND 6LR61(GA) NOTE: WEEKLY TESTING IS REQUIRED. WARNING! USE ONLY THE BATTERIES SPECIFIED. USE OF DIF- FERENT BATTERIES MAY HAVE A DETRIMENTAL EFFECT ON THE SMOKE ALARM.
-
Page 13: Limitations Of Smoke Alarms
7. Limitations of Smoke Alarms WARNING: PLEASE READ CAREFULLY AND THOROUGHLY • NFPA 72 states: Fire-warning equipment for residential occupancies are capable of protecting about half of the occupants in potentially fatal fires. Victims are often intimate with the fire, too old or too young, or physically or mentally impaired such that they cannot escape even when warned early enough that escape should be possi- ble. -
Page 14: Good Safety Habits
8. Good Safety Habits DEVELOP AND PRACTICE A PLAN OF ESCAPE • Make a floor plan indicating all doors and windows and at least two (2) escape routes from each room. Second story windows may need a rope or chain ladder. •... -
Page 15: Nfpa Required Protection
10. NFPA Required Protection The National Fire Protection Association’s Standard 72 provides the following information: Smoke Detection - Where required by applicable laws, codes, or standards for a specific type of occupancy, approved single- and multiple-station smoke alarms shall be installed as follows: (1) In all sleeping rooms and guest rooms (2) Outside of each separate dwelling unit sleeping area, within 6.4 m (21 ft) of any door to a sleeping room, the distance measured along a path of travel... - Page 16 11. CAUTION (AS REQUIRED BY THE CALIFORNIA STATE FIRE MARSHAL) Ionization type smoke alarms use a very small amount of a radioac- tive element in the sensing chamber to enable detection of visible and invisible combustion products. The radioactive element is safely contained in the chamber and requires no adjustments or mainte- nance.
-
Page 17: Service And Warranty
(10) years for the i9050, i9060, i9060RV, and i9080 smoke alarms from the date of purchase. The obli- gation of Kidde under this warranty is limited to repairing or replacing the smoke alarm or any part which we find to be defective in material, work-... - Page 18 QUESTIONS OR FOR MORE INFORMATION Call our Consumer Hotline at 1-800-880-6788 or contact us at our website at www.kidde.com Kidde, 1016 Corporate Park Drive, Mebane, NC 27302...
