- Page 1 Installation instructions Refrigerator & Freezer User guide UK IE...
- Page 2 Declaration of Conformity The manufacturer of the product/s described herein, to which this description refers, declares on its sole responsibility that the product/s meet the relevant fundamental safety, health and protection requirements of the relevant EU guidelines and that the corresponding test reports are available for examination by the relevant authorities and can be requested from the seller of the appliance, especially with regard to CE Declaration of Conformity issued by the manufacturer or with the manufacturer’s approval.
-
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions Moving or storing your refrigerator Operating instructions Interior features Food care Storing food in your refrigerator Storing food in your freezer Cleaning care – interior/exterior Maintenance Problem solving checklist Manufacturer’s Warranty Customer Care Important! SAVE THESE INSTRUCTIONS The models shown in this User Guide may not be available in all markets and are subject to change at any time. -
Page 4: Safety And Warnings
Safety and warnings To reduce the risk of fire, electric shock, or injury to persons read the IMPORTANT SAFETY PRECAUTIONS before operating this appliance. Use this appliance only for its intended purpose as described in this User Guide. Important safety precautions Warning Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. - Page 5 Safety and warnings Repair or replace immediately all electric service cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion along its length or at either the plug or appliance end. If the power supply cord is damaged, it must only be replaced by your Fisher & Paykel Authorised Service Centre because special purpose tools are required.
-
Page 6: Installation Instructions
Installation instructions Please follow the steps for installation to ensure your appliance operates correctly. 1. Location Your refrigerator or freezer should not be located in direct sunlight or next to any heat- generating appliance such as a cooktop, oven or dishwasher. 2. -
Page 7: Energy Efficiency
Installation instructions 4. Ventilation and installation To ensure adequate ventilation for your refrigerator, allow a minimum of 20 mm of airspace on each side of Fig.2a Fixed threaded stud hole and the cabinet, 75 mm at the rear, and 50 mm at the top of handle attachment stud the cabinet. - Page 8 Installation instructions Energy saving tips There are many simple things that can be done to save energy. During installation Locate refrigerator in coolest part of room. Avoid areas of direct sunlight, or near heating ducts, registers, or other heat producing appliances. If this is not possible, isolate exterior by using a section of cabinet or an added layer of insulation.
-
Page 9: Moving Or Storing Your Refrigerator
Moving or storing your refrigerator If your refrigerator or freezer is turned off for any reason, wait 10 minutes before turning it back on. This will allow the refrigeration system pressures to equalise before restarting. Moving your refrigerator Turn off the appliance and unplug from the power point. Remove all food. Turn the adjustable feet to the right as far as they will turn. -
Page 10: Operating Instructions
Operating instructions Control panel Fridge storage Freezer storage compartment compartment temperature temperature A3 A4 A5 A6 A7 Fridge Comptmt On/Off ( This function enables the temperature to the fridge compartment to be turned off and the internal air duct closed, leaving just the freezer compartment operating normally. An internal fan for the compartment will continue to circulate the air to help hinder stale odours from forming. - Page 11 Operating instructions Max Cool function ( Having the door open for a long time, or loading the fridge compartment full of warm food (such as after a trip to the supermarket) will raise the temperature of the refrigerator. Activating the Max Cool function will quickly drop the fridge compartment to the required temperature setting and will deactivate once this setting has been achieved.
-
Page 12: Using Your Refrigerator
Operating instructions Power ( An internal control used to turn off the operating functions of both compartments. To turn the operating functions on or off to both compartments, press and hold the power button for 3 seconds. In the On position, the power button indicator light will be illuminated. Important! This power button is not equivalent to turning off the power at the wall. -
Page 13: Interior Features
Interior features Storage areas There are recommended storage areas for various foods. As cold air circulates inside the refrigerator, there is a temperature difference inside the fridge storage compartment. Different foods should be placed in different areas according to their properties. Eggs, butter, cheese, etc Drinks, canned food, etc Seasonings and pickled food... - Page 14 Interior features Shelves Your refrigerator is fitted with shelves specially designed to retain spills, making clean up easier. The shelves can be repositioned at different heights to accommodate different food storage container sizes and heights. To remove the shelf, use the front edge to lift the shelf and then pull shelf forward (fig.3).
-
Page 15: Door Shelves
Interior features Cool storage drawer The Cool storage bin (fig.5) is colder than the rest of the fridge compartment and provides an environment perfect for storing a range of items, including meat products and other highly perishable foods. Door shelves Fig.5 Cool storage drawer Door shelves can be moved to meet individual storage needs. -
Page 16: Storing Food In Your Refrigerator
Storing food in your refrigerator Storing fresh, perishable foods in your refrigerator helps to extend storage times. The cold temperatures slow down the major causes of food spoilage – namely, the growth of bacteria, moulds and yeasts, and chemical and physical reactions. Fresh food care The quality of food before it is placed in the refrigerator is critical to successful storage. - Page 17 Storing food in your refrigerator Red meat Place fresh red meat on a plate and loosely cover with waxed paper or plastic wrap or foil. Store cooked and raw meat on separate plates. This will prevent any juices lost from the raw meat from contaminating the cooked product. Delicatessen meats should be used within the recommended storage time.
-
Page 18: Storing Food In Your Freezer
Storing food in your freezer The use of temperatures of -18˚C or colder to store food means that the food can be kept for longer periods than when refrigeration temperatures are used. This is because the growth of bacteria, moulds and yeasts are stopped, and chemical and physical reactions are severely restricted at very low temperatures. - Page 19 Storing food in your freezer Meat, poultry and game Do not try to freeze more than 1kg meat per 25L freezer capacity. Meat must be frozen quickly in order to maintain its texture. Do not stuff poultry before freezing. Red meat can be cooked from frozen, or from the partly or completely thawed states.
-
Page 20: Cleaning Care - Interior/Exterior
Cleaning care – interior/exterior Interior It is important to keep the interior of the refrigerator and freezer clean to help prevent food from becoming contaminated during storage. The amount and types of food stored determines how often cleaning should be carried out (ideally once every 1 to 2 weeks) in the refrigerator. -
Page 21: Maintenance
Maintenance Replacement of the interior light Your refrigerator uses LEDs as its light source, which is designed to offer you low energy consumption and long life service. Should the interior light fail to function properly, please contact your Fisher & Paykel Authorised Service Centre. -
Page 22: Problem Solving Checklist
Problem solving checklist If there is a problem with your appliance, please check the following points before contacting your local Fisher & Paykel Authorised Service Centre or Customer Care Centre. Problem Possible causes What to do Appliance does No electricity at power outlet. Check that the plug is correctly connected not operate. - Page 23 Problem solving checklist Problem Possible causes What to do Water in the Condensation is formed by the A small amount of condensation is vegetable bins. water produced by fruit and beneficial for fruit and vegetable storage. vegetables. If there is too much water, store fruit and vegetables loosely wrapped in plastic bags.
-
Page 24: Manufacturer's Warranty
Manufacturer’s Warranty You automatically receive a 2 year Manufacturer’s Warranty with the purchase of this Product covering parts and labour for servicing within the country of purchase. Fisher & Paykel undertakes to: Repair or, at its option, replace without cost to the owner either for material or labour any part of the Product, the serial number of which appears on the Product, which is found to be defective within TWO YEARS of the date of purchase. -
Page 25: Customer Care
Customer Care Before you call for service or assistance… Check the things you can do yourself. Refer to your User Guide and check: Your appliance is correctly installed. You are familiar with its normal operation. You have read the problem solving at the back of the book. If after checking these points you still need assistance, please refer to your nearest Fisher &... - Page 28 www.fisherpaykel.co.uk www.fisherpaykel.ie Copyright © Fisher & Paykel 2009. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
