  • Page 1 INTEGRATED REFRIGERATION INTEGRATED RS6009V2RT1, RS6009V2R1, RS6009SBLT1, RS6009SBL1 INSTALLATION GUIDE AA BI HK SG...

  • Page 2: Tools Required

    TOOLS REQUIRED Supplied Spanner M4 ball allen key L key combi PH T25 Not supplied Powered driver Hacksaw Flathead screwdriver Hand truck Measuring tape Socket 8mm Phillips screwdriver Nut driver Cutter...

  • Page 3: Parts Required

    PARTS REQUIRED INSTALL KIT Install Kit A (bracket anti-tip assembly) Anti-tip bracket 5x Plug masonry SP630#10X30MM 5x Screw WS #10X35 T17 WFR PH ZP Install Kit B (hinge spacer & depth gauges) Assy hinge spacer A Cover hinge spacer A Assy hinge spacer B Cover hinge spacer B 2x Depth gauge non hinge...
  • Page 4 PARTS REQUIRED TRIM KIT MTG Plate toe kick RS60 Template Panel Door 60cm UC Trim Side DR 60cm Glass door trim Trim Side Hinge DR 60cm JOINER KIT To be ordered seperately for multiple installation. Joiner kit A (bracket joiner plinth) 9x Screw M5X12 PH MT STL ZN Bracket dual plinth FNT (2X) Joiner kit B (bracket joiner top)
  • Page 5 ACCESSING YOUR PRODUCT SPECIFICATIONS For full product, cabinetry and service specifications, refer to the Planning Guide. To access the Planning Guide, scan the QR code or visit fisherpaykel.com/specify. Search by appliance type, product name or model code.

  • Page 6: Prior To Installation

    PRIOR TO INSTALLATION 1. Measure alcove. Ensure all minimum specifications have been met. Refer to the planning guide for details. fisherpaykel.com/specify 3. Ensure alcove is square, secure and that a finished return has been created. 2. Ensure services are accessible and correctly installed.
  • Page 7 PRIOR TO INSTALLATION 4. Ensure all panels are set up to the correct specifications. Refer to the planning guide for details. 5. Ensure all bracket and handle holes have been pre-drilled. Refer to the planning guides for details.
  • Page 8 UNPACKING 1. Cut the straps, open the top and cut down the side of the carton to remove. Remove all pre-packaged parts. 2. Dispose of packaging responsibly. 3. Using a Phillips screwdriver, remove the transit bolts from one side of the product and set aside.
  • Page 9 UNPACKING 4. Check levelling feet have been raised before restraining to a handtruck. 5. Remove the two remaining transit brackets. 6. Tilt product onto handtruck and remove pallet. Move product to the installation location. Remove and discard corner posts.

  • Page 10: Install Anti-Tip Bracket

    INSTALL ANTI-TIP BRACKET 1. Ensure wall stud or solid surface is present. 2. If alcove depth is greater than 600mm A spacer will be required to be installed alongside the anti-tip bracket to bring depth to 600mm. 3. Measure the height from the floor to the front overhang and mark on the rear wall.
  • Page 11 INSTALL ANTI-TIP BRACKET 4. Solid wall installations Using the bracket as a guide, pre-drill four holes into the wall or spacer. Secure using four Phillips screws. Install kit A 5. Masonry wall installations Using the bracket as a guide, pre-drill four holes into the wall.
  • Page 12 REMOVE GRILLE 1. Push the grille flap to open. 2. Unscrew the two Phillips screws from behind the flap and the five screws from the grille front. Set aside. 3. Pull the grille outwards from the product to remove.
  • Page 13 HINGE SWAP (OPTIONAL) 1. Open the door. 2. Loosen the hinge screws using the supplied Torx T25 driver. Slide door off and place on a protected surface. 3. Carefully remove hinges from door and set aside.
  • Page 14 HINGE SWAP (OPTIONAL) 4. Remove top cover and set aside. 5. Push on the edge of the outside plates. Lift out and swap to other side. 6. Use a flathead screwdriver to remove the inside plates. Move to the other side ensuring the rounded corners face the inside.
  • Page 15 HINGE SWAP (OPTIONAL) 7. Check plates are positioned correctly. 8. Swap hinges as illustrated. Ensure base of hinge is parallel and tightened securely. Refit top cover. 9. Swap alcove bracket with the hinge bracket. Secure each using three screws.
  • Page 16 HINGE SWAP (OPTIONAL) 10. Slot the door back onto the screws and tighten using the supplied Torx key.
  • Page 17 JOIN PRODUCTS (MULTIPLE INSTALLS ONLY) 1. Ensure doors are closed before rolling products into position. 2. Secure the lower front bracket using four screws. Joiner kit A 3. Secure the upper front bracket using four screws. Joiner kit B...
  • Page 18 JOIN PRODUCTS (MULTIPLE INSTALLS ONLY) 4. Secure the lower rear bracket using four screws Joiner kit A 5. Secure the upper rear bracket using four screws. Joiner kit C 6. Repeat for additional products.
  • Page 19 INSTALL DEPTH GAUGES AND SPACERS 1. Clip both hinge spacers onto the product. For right-hand hinge installations, ensure spacer A is fitted to the top hinge and spacer B is fitted to the bottom hinge, and vice-versa for left- hand hinge installations. Install kit B 2.
  • Page 20 INSERT HINGE LIMITING PIN (OPTIONAL) 4. To limit the door opening to 90°, lower the hinge limiting pin into the upper and lower hinges. Install kit H...

  • Page 21: Connect Power

    CONNECT POWER 1. If required, wrap a thread around the power cord to bring any slack inside the plinth to reduce the risk of it tangling behind the product. 2. Connect to outlet and turn power on.
  • Page 22 PUSH INTO CAVITY 1. Push product in until the depth gauges touch the front of the alcove. Ensure power cord is not trapped.

  • Page 23: Adjust Height

    ADJUST HEIGHT 1. Adjust the front of the product by turning the left- hand screw anti-clockwise to lower the feet. We recommend marking a drill and counting the number of turns required to fully engage the feet. 2. Adjust the rear of the product by turning the right- hand screw anti-clockwise to lower the feet.
  • Page 24 ADJUST HEIGHT 4. Ensure all depth gauges are flush to the front of the alcove and front of door is level. We recommened using a spirit level for accuracy. 5. Open the door and use the supplied hex key to expand the upper spacer to create an even gap between product and alcove.
  • Page 25 SECURE 1. Using two supplied long Phillips screws, secure the lower hinge to the cavity Install kits B 2. Using one supplied short Phillips screw, secure the lower right side of the product to the cavity. Install kits E 3. Using one supplied short Phillips screws, secure the lower left side of the product to the cavity.
  • Page 26 SECURE 4. Using two supplied long Phillips screws, secure the upper hinge to the cavity. Install kits B 5. Snap the ends off both spacers. 6. Clip covers onto spacers. 7. Ensure cover A is fitted to spacer A and Cover B to spacer B.
  • Page 27 SECURE 8. Unscrew the Phillips screws to remove the depth gauges.
  • Page 28 DOOR PANEL PREP (CUSTOM PANEL) 1. Recheck the door panel specifications. Ensure all bracket locations have been marked. Refer to the Planning Guide for details. fisherpaykel.com/specify 2. Unscrew the two Phillips screws to remove the top cover. 3. Remove both washers and nuts and set aside.
  • Page 29 DOOR PANEL PREP (CUSTOM PANEL) 4. Align the door panel bracket to the panel. Secure using the supplied screws. Install kit G 5. Align the side brackets to the panel. Secure using the supplied screws. Ensure brackets are fitted tightly and the fasteners are secured straight.
  • Page 30 DOOR PANEL PREP (CUSTOM PANEL) 7. Fit the handle to the panels using four M5x25 hex screws. Ensure handle fixings do not interfere with side brackets.
  • Page 31 DOOR PANEL PREP (PRE-FINISHED PANEL) 1. Unscrew the two Phillips screws to remove the top cover. 2. Remove both washers and nuts and set aside. Lift the panel bracket outwards to remove. 3. Remove all blue tape from the panel. Align the door panel bracket to the panel.
  • Page 32 DOOR PANEL PREP (PRE-FINISHED PANEL) 4. Align the side brackets to the panel. Secure using the supplied screws. Ensure brackets are fitted tightly and the fasteners are secured straight. Install kit G 5. Fit the handle to the panels using four M5x25 hex screws.
  • Page 33 ALIGN DOOR PANEL 1. Ensure top mounting screws have been loosened and sit at their lowest position Install kit D 2. Lower the door panel onto the mounting screws 3. Fit a tab to the door to assist with opening.
  • Page 34 ALIGN DOOR PANEL 4. Ensure side brackets are disengaged and top mounting screws have been loosened. Rotate the mounting studs clockwise to lower the panel and anti-clockwise to raise it. 5. Loosely tighten the side screws and the top M8 washers using the spanner and L key provided in the install kit.
  • Page 35 ALIGN DOOR PANEL 7. Fit side screws to panel using the short Phillips tool provided. 90° door opening installations Use the supplied Phillips key to fit the side screws on the hinge-side. Install kit D 8. Tighten the M8 washers using the supplied spanner and hex key.
  • Page 36 SECURE DOOR PANEL 1. With the door open, loosen the lower bracket screw. Adjust bracket to rest against the door panel. Re-tighten the bracket screw. 2. Fit an additional screw through the bracket to lock panel into position. Install kit E 3.
  • Page 37 FIT TRIMS 1. Fit the top cover using two supplied Phillips screws. Ensure the flat side faces away from the panel. 2. Locate the shorter door trim to the hinge-side of the product and slide down to clip into place. Trim kit 3.
  • Page 38 FIT TRIMS 4. Fit the trim onto the top cover. Trim kit 5. Insert the upper hinge cover tab into the display panel until it audibly clicks into place. Gently push the trim until it is flush with the display. Install kit H 6.
  • Page 39 FIT TRIMS 7. Hinge swap installations: Swap the lower hinge covers. Avoid swapping hinge covers between models as covers differ between beverage and wine models.
  • Page 40 INSTALL CENTRE TRIM (MULTIPLE PRODUCT INSTALLATIONS) 1. Locate the centre trim between products and push into position. Ensure the lower part of the trim clears the grille. 2. Slide trim up to slot into the upper bracket. 3. Ensure the top of the trim touches the alcove before securing using the supplied fastener.
  • Page 41 REFIT GRILLE 1. Open the cover and align the grille to the product. Slot into place starting with the base of the grille. 2. Hand tighten the top left screw, followed by the top right screw. Fit the remaining five screws on the grille to secure.
  • Page 42 PREPARE TOE KICK 1. Recheck toe kick panel specifications. Refer to the Planning Guide for details. fisherpaykel.com/specify 2. Measure the distance from the floor to the bottom of the grille to determine the position of the toe kick mounting plate. 3.
  • Page 43 SECURE TOE KICK 1. Loosen the screws on both toe kick brackets and slide brackets forward. Re-tighten screws slightly. 2. Locate the toe kick to the magnetic brackets to secure. Adjust the toe kick to the desired depth. 3. Remove the toe kick and hand-tighten the bracket screws.
  • Page 44 SECURE TOE KICK 4. If toe kick depth is less than 90mm Attach the supplied foam block to the centre of the panel. 5. Refit the toe kick.
  • Page 45 SECURE FLOW DIVIDER 1. With the door open, align flow divider to base of door. Using either a hacksaw or side cutters, cut divider to ensure it doesn't extend below the door panel. Install kit D 2. Slot flow divider onto the screw at the base of the door.
  • Page 46 EXIT INSTALL MODE 1. Press and hold to exit install mode...

  • Page 47: Installer Checklist

    INSTALLER CHECKLIST Ensure Installer Mode has been exited. All levelling feet have been adjusted and engaged. Panel gaps and any potential clashing points have been checked. All trims have been secured at all attachment points. Covers are in place. Product is robustly attached to cabinetry. If required, hinge limiting pins have been fitted.
