12. Dimensions and Available Models
12.1 Humidifi er dimensions
14" 14"
12.2 Available models
Model Model
Acu-5 Acu-5
Acu-10 Acu-10
Acu-15 Acu-15
Fig. 12a
11 5/8" 11 5/8"
! !
9" 9"
Fig. 12b
Capacity Capacity
Lbs/Hr Lbs/Hr Power Power
(Kg/Hr) (Kg/Hr) (Kw) (Kw)
4.8 4.8
(2.2) (2.2) 1.5 1.5
9.6 9.6
(4.4) (4.4)
12.8 12.8
(5.9) (5.9)
13" 13"
Voltage Voltage Current Current
(V) (V)
120 120 12.5 12.5
3 3 240/120 240/120 12.5 12.5
4 4 240/120 240/120 16.6 16.6
Page 14
(A) (A)
