Harris RF-5800H-MP Specifications

®
assuredcommunications ™
RF-5800H-MP
ADVANCED HF/VHF
TACTICAL RADIO
SYSTEM
a fully integrated, compact The RF-5800H-MP is a member of the FALCON II family of multiband tactical
®
radio systems. It is an advanced HF-SSB/VHF-FM manpack radio that provides
reliable tactical communications through enhanced secure voice and data
communications system,
performance, networking, and extended battery life. The transceiver's extended
frequency range (to 60 MHz) provides secure FSK 16 kbps CVSD voice and data
offering the security and
in the VHF band in addition to the HF capability. It is like having two radios in
one compact package.
performance features your
High speed data rates, up to 9600 bps (HF), and selectable ARQ modes reduce
on-the-air transmission time and enhance secure data transmissions for
missions demand
improved communications reliability and throughput. The combined robust
digital voice (MELP, LPC-10) and serial tone data modem operate over poor
communication channels. The RF-5800H-MP includes a last ditch voice mode
that transmits digital voice using ultra robust 3G waveforms for operation in
channels where no other waveforms will work.
A serial-tone ECCM waveform with DSP-based excision filtering and a 600 bps
vocoder are combined to provide reliable, secure HF communications in the
presence of jamming. Secure digital voice, 75 to 2400 bps data, and ARQ mode
are supported in the ECCM mode.
The latest third generation HF Link Automation, STANAG 4538, is included and
provides high performance ALE and data link protocols, providing superior
linking and error free data transfer.
The Harris Citadel ® ASIC provides high speed data and digital voice encryption
using either a Harris-standard or a customer-unique algorithm.
An internal Global Positioning System (GPS) receiver option provides local
position information and Automatic Position Reporting (APR). This feature
allows the radio to be used in situational awareness systems without PCs
attached to the outstation radios.The accurate GPS timing data can be used
for ECCM and advanced ALE synchronization.
Integrated telephony capability allows the radio operator to place and
receive telephone calls using the radio keypad when used with the RF-
6010 Tactical Network Access Hub.
The data capability and network management features of the
RF-5800H-MP utilize industry standard IP-based protocols
to provide fast, simple, and direct communications, and
permit easy setup and maintenance of tactical
networks.
The removable Keypad/Display Unit provides
easy access to controls for on-the-move
operation.
