Summary of Contents for Harris PT-150C

  • Page 2 Products equipment, please check the support area of our web site. You Harris Corporation shall not be liable for errors contained can also send e-mail to: support@intraplex.com herein or for incidental or consequential damage in connection with the furnishing, performance, or use of this material.

  • Page 3: Table Of Contents

    Table of Contents 1.0 About the PT-150C and PR-150C ....1-1 1.1 Introduction ........1-2 1.2 PT-150C at a Glance...
  • Page 4 5.3 Functional Description and Theory of Operation ..5-4 5.3.1 PT-150C Transmitter ......5-4 5.3.2 PR-150C Receiver...
  • Page 5 PT-150C at a Glance ........

  • Page 6: About The Pt-150C And Pr-150C

    Additional information about this system is contained in your Intraplex multiplexer operation manual. The PT-150C transmitter module and PR-150C receiver module are designed for use in Intraplex terminal and drop/insert multiplexers. The modules enable transport of professional quality audio signals over T1, E1 (2 Mbps), and other digital communications facilities.

  • Page 7: 150C At A Glance

    PT-150C at a Glance PT-150C at a Glance The PT-150C module contains several indicators and configuration switches, as shown in Figure 1-1 below and Figure 1-2 on page 1-4. These indicators and controls are described in Section 1.4 through Section 1.9.
  • Page 8 About the PT-150C and PR-150C PT-150C at a Glance Figure 1-2 PT-150C transmitter, top view PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 9: Pr-150C At A Glance

    About the PT-150C and PR-150C PR-150C at a Glance PR-150C at a Glance The PR-150C modules contain several indicators and configuration switches, as shown on Figure 1-3 below and Figure 1-4 on page 1-6. These indicators and controls are described in Section 1.4 through Section 1.9.
  • Page 10 About the PT-150C and PR-150C PR-150C at a Glance Figure 1-4 PR-150C receiver, top view PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 11: 150C And Pr-150C Indicators

    About the PT-150C and PR-150C PT-150C and PR-150C Indicators PT-150C and PR-150C Indicators Table 1-1 PT/PR-150C indicators Indicator Function Color When lit, indicates SRVC Service Indicator Green Service for the card is ON LEVEL Level Indicator 1 Green Signal strength -24 dBFS...
  • Page 12 About the PT-150C and PR-150C Time Slot Configuration Switches Note: Use Table 1-3 to set time slots only on a T1 (1.544 Mbps) multiplexer (ACS-160 Series) or a T1-based variable rate multiplexer (VRM-3850 Series). For E1 (2.048 Mbps) settings, see Table 1-4.
  • Page 13 About the PT-150C and PR-150C Time Slot Configuration Switches Note: Use this table to set time slots only on an T1 multiplexers (Intraplex ACS-160 Series). For E1 settings, see Table 1-4. Table 1-4 Time slot settings for E1 application on each channel (SW2 and SW4)

  • Page 14: Local Configuration Parameters

    Engages scrambler, maintaining the ones density in the audio data stream TERM Sets the card to transmit (PT-150C) or receive (PR-150C) through the DI/B port in a Drop/Insert multiplexer. Do not use this setting in a Terminal multiplexer. See Section 5.3.4, Drop and Insert...

  • Page 15: Audio In/Out Jacks

    Note: Be careful using the AUDIO IN jacks on a PT-150C for monitoring. A signal input at the jack is added to the program audio and may cause an output overload. Use a high impedance meter for testing.

  • Page 16: Input Impedance

    1-12 About the PT-150C and PR-150C Input Impedance Input Impedance Table 1-7 Audio input impedance jumpers (JMP1 and JMP2) — PT-150C only Jumper Setting Effect JMP1 In place Sets left channel input to 600 ohms impedance Removed Sets left input to greater than 10 kilohms impedance...
  • Page 17 About the PT-150C and PR-150C 1-13 Configuration Settings Table 1-8 Configuration setting (SW5) (continued) Position Label Setting Description Disabled Down E1 applications only. Sets for channel associated signaling. If time slot 16 is used, a configuration error will occur. Table 7-1 on page 7-3 and Table 7-2 on page 7-4 provide the time slot settings for 7.5 and 15...

  • Page 18: Remote Control Module Address

    Remote Control Module Address 1.10 Remote Control Module Address SW7 sets the SCB Address for the PT-150C and PR-150C. The SCB Address is used when the module is to be remotely controlled through the multiplexers REMOTE port. For remote access, each channel module in an Intraplex multiplexer must have a unique card address.

  • Page 19: Installation Procedure

    Configuration..........2-2 Harris Corporation...

  • Page 20: Introduction

    Installation Procedure Introduction Introduction Refer to the figures and tables in Section 1, About the PT-150C and PR-150C as necessary during this procedure. Before changing the configuration of a PT/PR-150C module, please review Section 7, Application Considerations, for recommended settings.
  • Page 21 Installation Procedure Configuration 7. PT-150C only: Set the audio input impedance jumpers JMP1 and JMP2 in place for 600 ohms, or remove the jumpers for >10 kilohms. (See also Section 1.8, Input Impedance, on page 1-12.) 8. Set the SCB address for the card to the number of the physical slot it will occupy using SW7 (see Section 1.10, Remote Control Module Address, on...
  • Page 22 Installation Procedure Configuration Response Description Valid command received Card number 8 is a PT-150C CHANNEL CARD 8, TYPE 200 Remote control is on UNDER REMOTE CONTROL Service is off SRVC = OFF Left channel, time slot 1 set to 12...

  • Page 23: Remote Control Interface

    IntraGuide Software........3-9 Harris Corporation...

  • Page 24: Introduction

    See your multiplexer operating manual for details on using ISiCL remote control. The PT-150C reports itself as a TYPE 200 module, and the PR-150C reports itself as a TYPE 201 module. The remote control interface for this module involves two sets of codes: “P”...
  • Page 25 Selected slot = 5 bit switch code + 10 to 31 in a 2 MB multiplexer 0 0 0 0 0 Not used; set to 0 ↑ ↑ ↑ PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
  • Page 26 B 0 0 0 0 0 0 0 0 Mode 0=7.5 KHz ↑ 1=15 KHZ 0 0 0 0 0 0 Not used; set to 0 ↑ ↑ PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
  • Page 27 • To enable errored-sample detection. (When a PT-150C is in 15-bit mode, it always sets the 16th bit to 1; if the PR-150C is in 15-bit mode and detects a 0 in this bit position, it will indicate an error by flashing the SRVC indicator) b.

  • Page 28: S Codes

    S Codes S Codes S codes appear in response to an ISiCL “STATUS?” query. There are two S codes for these modules. A typical PT-150C or PR-150C response to a STATUS? query looks like this: * OK CHANNEL CARD 3, TYPE 200 (or 201) (If there is one in effect) >>>ALARM<<<...
  • Page 29 Channel 2 (right) audio input level ↑ ↑ ↑ ↑ 0 0 0 0 0 or 1 Channel 1 (left) audio input level ↑ ↑ ↑ ↑ PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 30: Configuration Errors

    TS1 or TS2 on either channel = time slot 16 (in E1 CAS mode) • PR-150C CH1 is set to 15-bit mode, but the PT-150C CH1 is not set to 15-bit mode. (There is no detection for CH2) PT/PR-150C Module Installation & Operation Manual...

  • Page 31: Intraguide Software

    "alphabetic card index" in the index (or under "operations, system cards" in the table of contents) of the IntraGuide online help. PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 32: Computer Requirements

    There is an adapter available for connecting the module adapter to a 9-pin serial port of a computer. Order part number 9557-2129, CM-10 Term Adapter DB-9/RJ11. PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 33: Serial Protocols

    The current condition of the CM-5 can be displayed in the status display shown in Figure 3-4. This display generates the same report as the manually entered ISiCL commands discussed previously in this section. PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
  • Page 34 Remote Control Interface IntraGuide Software Figure 3-4 CM-5 status display IntraGuide provides support for numerous Intraplex channel modules. For example, Figure 3-5 shows the configuration controls for a PT-150C channel module. Figure 3-5 PT-150C configuration display PT/PR-150C Module Installation & Operation Manual...
  • Page 35 Remote Control Interface 3-13 IntraGuide Software Figure 3-6 shows another example of IntraGuide’s status screen for the PT-150C channel module. Note that there are several status display selections available. Figure 3-6 PT-150C status display Explanations for each field in the IntraGuide display are available from the context-sensative Help function of IntraGuide.
  • Page 36 3-14 Remote Control Interface IntraGuide Software PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 37: Testing

    Test Procedure ..........4-2 Harris Corporation...

  • Page 38: Introduction

    There are two ways you can do the testing: • If you have both a PT-150C and a PR-150C in the same shelf, you can perform this test with the system out of service, by looping back the multiplexer’s high-speed output port (T1, E1, or variable rate).
  • Page 39 Problems may occur at the common equipment or facility level which affect the operation of this card. Refer to the Troubleshooting section in your multiplexer operation manual for system analysis procedures. PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
  • Page 40 Testing Test Procedure PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 41: Specifications

    Compatibility With Previous PT/PR-150 Versions....5-3 Functional Description and Theory of Operation ....5-4 Harris Corporation Intraplex Products...

  • Page 42: General Specification

    Monaural — 64 kbps (one time slot) Stereo — 128 kbps (two time slots) Temperature: 0 to 50°C Operating Environmental Humidity: 0% - 90% Non-condensing 4.0 Watts nominal per PT-150C Power 6.0 Watts nominal per PR-150C PT/PR-150C Module Installation & Operation Manual Harris Corporation...

  • Page 43: Compatibility With Previous Pt/Pr-150 Versions

    PT-150A/PR-150A (PR-150S) • PT-460/PR-460 • PT-150B/PR-150B • PT-150C/PR-150C (current) When using any combination of these modules, certain compatibility problems will exist. Table 5-1 provides the compatibility limitations between all existing versions of the Intraplex PT/PR-150 module. Table 5-1 7.5Khz 7.5Khz 7.5Khz...

  • Page 44: Functional Description And Theory Of Operation

    1, so that it can be checked at the receive end to detect errored samples. A green SRVC indicator stays on when the PT-150C is powered and operating. The SRVC indicator will blink when a configuration error is present. The red FAIL indicator on the front of the PT-150C shows failure of the corresponding channel’s DSP.
  • Page 45 Specifications Functional Description and Theory of Operation Figure 5-1 PT-150C transmitter, block diagram PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 46: Pr-150C Receiver

    The analog audio goes through an output level control and then goes to the output amplifier. The RX LEVELS and red OVERLOAD indicators, which are calibrated the same as those on the PT-150C, monitor the digital signal sent to the digital-audio converter (DAC).
  • Page 47 Specifications Functional Description and Theory of Operation Figure 5-2 PR-150C receiver, block diagram PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 48: Alerts/Alarms

    DI-B port is connected to the transmission line to Site 3. Individual payload channels may connect Sites 1 and 2, 1 and 3, or 2 and 3. Also, a PT-150C transmitter may be installed at Site 1 or Site 3 and be received simultaneously by PR-150C modules at both of the other sites, without the need for tandem decoding and re-encoding.

  • Page 49: Module Adapters For The Pt/Pr-150C

    MA-301 Module Adapter ........6-4 MA-504 and MA-505 Module Adapters ......6-7 Harris Corporation Intraplex Products...

  • Page 50: Channel Module Installation Procedure

    Channel Module Installation Procedure Channel Module Installation Procedure The PT-150C transmitter and PR-150C receiver modules must be installed with a module adapter that provides full connectivity to a communication circuit. The procedure for installing the channel module into a multiplexer with a module adapter follows.
  • Page 51 PT-150C or PR-150C. Connect the balanced line cable to the adapter as shown in Figure 6-2, and insert the adapter into the rear of the slot which will hold the PT-150C or PR-150C. Figure 6-2 MA-503 module adapter pin assignments PT/PR-150C Module Installation &...
  • Page 52 MA-301 Module Adapter MA-301 Module Adapter One MA-301 can be used to connect up to three PT-150C or PR-150C modules, for a total of up to six audio channels. If you will be using more than one module with an MA-301, they must be inserted into adjacent slots in the multiplexer.

  • Page 53: Ma-301 Module Adapter

    Module Adapters for the PT/PR-150C MA-301 Module Adapter Figure 6-4 Using an MA-301 with multiple modules in a 3RU multiplexer PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
  • Page 54 Module Adapters for the PT/PR-150C MA-301 Module Adapter Figure 6-5 Using an MA-301 with multiple modules in a 1RU multiplexer PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 55: Ma-504 And Ma-505 Module Adapters

    XLR female and male connectors respectively. Figure 6-6 describes the pin assignments for the adapters. Figure 6-6 MA-504 and MA-505 module adapter pin assignments PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
  • Page 56 Module Adapters for the PT/PR-150C MA-504 and MA-505 Module Adapters PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...

  • Page 57: Application Considerations

    Multi Frame Alignment ........7-5 Harris Corporation...

  • Page 58: Using Pt/Pr-150C Modules In A T1 Multiplexer

    Using PT/PR-150C Modules in a Variable Rate Multiplexer If a PT-150C or PR-150C module is assigned to the first one or two time slots in use, and you want to use in-band framing (such as “robbed bit” or Payload Plus 0 operation), select bit number three as the frame bit.

  • Page 59: Using Pt/Pr-150C Modules In An E1 Multiplexer

    Using PT/PR-150C Modules in an E1 Multiplexer Using PT/PR-150C Modules in an E1 Multiplexer 7.3.1 Recommended Settings When using a PT-150C or PR-150C in an E1 multiplexer, use the following settings whenever possible: • set coding to 16 bit •...

  • Page 60: Self-Framing Mode

    Time Slots Self-Framing Mode To operate the PT-150C and PR-150C modules normally at 7.5 kHz, the transmission system must maintain multiframe alignment of the aggregate signal (see Section 7.6 on page 7-5). If it does not have multiframe alignment, then the PR-150C receiver module requires a special configuration called self-framing mode.

  • Page 61: Multi Frame Alignment

    When operating in 7.5 kHz mode, (either 15- or 16-bit), with the auto sync mode disabled it is advisable to enable the multi frame alignment feature on the PR and PT-150C modules to assure the proper alignment of data. PT/PR-150C Module Installation & Operation Manual...
  • Page 62 Application Considerations Multi Frame Alignment PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
  • Page 63 CH2 BIT 1-10 features 3-10 CH2 ON 1-10 hardware 3-11 CM-5 protocols 3-12 online help 3-10 compatibility PT-150C configuration 3-13 previous versions 5-3 PT-150C status 3-14 context-sensitive help 3-10 sample configuration 3-12 controls and indicators 1-3, 1-5 setup 3-10 ISiCL 3-2...
  • Page 64 1-11 theory of operation 5-6 SW6 1-10 JMP1 1-12 top view 1-6 SW7 1-14 JMP2 1-12 PT/PR-150 5-3 switch locations jumpers (PT-150C) 1-12 PT/PR-150A 5-3 PR-150C 1-6 PT/PR-150B 5-3 PT-150C 1-4 PT/PR-150R 5-3 LEDs 1-7 PT/PR-460 5-3 left channel...

  • Page 65: Index

    Index PT/PR-150C Module Installation & Operation Manual Harris Corporation Issue 1, October 2000 Intraplex Products...
