Owners Guide
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING
Do not store or use gasoline or other
flammable liquids or vapors within 25 feet
(8m) of this appliance.
WARNING: Follow all leak-check
procedures carefully in this manual prior to
barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting"
Instructions section of this manual
®
®
Y
OU MUST READ THIS
BEFORE OPERATING YOUR GAS GRILL
A101.c
B067.e
C052.c
D001.e
Natural Gas
O
G
WNERS
UIDE
55051 05/24/01
Advertisement
Table of Contents
Related Manuals for Weber Genesis Silver B NG 050401
Summary of Contents for Weber Genesis Silver B NG 050401
- Page 1 Owners Guide DANGER If you smell gas: 1. Shut off gas to the appliance. Natural Gas 2. Extinguish any open flames. 3. Open lid 4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. Leaking gas may cause a fire or explosion which can cause serious bodily injury or ®...
-
Page 2: Warranty
Improper assembly may be dangerous. Please carefully follow the assembly instructions in this manual. After a period of storage, and/or nonuse, the Weber Gas Barbecue should be checked for gas leaks and burner obstructions before use. See instructions in this manual for correct procedures. - Page 3 If you are required to return defective parts, transportation charges must be prepaid. Weber will return parts to the purchaser, freight or postage prepaid. This Limited Warranty does not cover any failures or...
-
Page 4: Table Of Contents
Contents Danger & Warnings ........ A-2 Warranty ..........A-3 General Instructions ....... A-5 Exploded View ........A-6 Parts List ..........A-9 Assembly Instructions ......B-1 Installing Features ........C-1 Operating ..........D-1 Lighting ........... D-1 Manual Lighting ........D-2 Cooking ..........D-3 Storage ........... -
Page 5: General Instructions
• The gas must be turned OFF at the natural gas Your Weber Gas Barbecue is a portable outdoor supply when the Weber Gas Barbecue is not in cooking appliance. With the Weber Gas Barbecue you use. can grill, barbecue, roast and bake with results that are •... - Page 6 Genesis Silver-B Prem. NG 050401...
- Page 7 Hinge Pin Hair Pin Cotter Left Endcap Thermometer Shroud Right Endcap Handle Burner Control Knob Warm-Up Basket Control Panel Warming Rack Ignitor Button Cooking Grate Control Panel Hardware Flavorizer Bar Crossover tube Cooking Box Front and Back Burners 1/4-20 keps nut Center Burner Slide Out Bottom Tray Manifold Hardware...
- Page 8 ® of Weber-Stephen Products Co., 200 East Daniels Road, Palatine, IL, 60067-6266, U.S.A. This product is covered by one or more United States patents and patents in other nations globally. Printed in the U.S.A.
- Page 9 Screwdriver Left Frame - 1 Phillips screwdriver Hammer Right Frame -1 7/16 open-end or an adjustable wrench Wheel Frame - 1 Pliers Caster Frame - 1 Block of wood Lid -1 Frame Connectors - 2 Left Trim Piece - 1 Right Trim Piece - 1 Cooking Box - 1 Work Surface - 1...
-
Page 10: Hinge Pin
Warming Rack - 1 Burner Control Knobs - 3 Warm-Up Basket - 1 Hinge Pins (1/4-20 x 1 1/2 inch clevis pin) - 2 2 inch bolts (1/4-20 x 2 inch bolts) - 5 Flavorizer Bars - 5 1/2 inch bolts (1/4-20 x 1/2 inch bolts) - 9 Bottom tray - 1 Keps Nut (1/4-20 Keps Nut) - 1 Catch Pan Holder - 1... -
Page 11: Assembly Instructions
Tap one hubcap onto the end Note - Work on carpeted area (on grass or one of the of the axle rod. Slide one wheel onto the axle, WEBER boxes) to protect the finish during frame assembly. - Page 12 Continue frame assembly Complete frame assembly You will need: caster frame, wheel frame, four 1/2 inch You will need: partial frame assembly, two frame bolts, four nylon washers and a 7/16 inch or adjustable connectors, four 2 inch bolts, four nylon wrench.
- Page 13 Insert casters Add cooking box (assembly) You will need: frame assembly and two casters. You will need: frame assembly, cooking box Push the casters firmly into the inserts in the ends of (assembly), 2 inch bolt, nylon washer, keps nut, pliers the caster frame.
- Page 14 Your Weber Gas Grill Manifold assembly consisting of Install manifold brackets The manifold brackets(2) are already in place on the gas manifold, valves and gas burners has been factory assembled, pressure- and flame- tested. As a safety manifold between the valves.
- Page 15 Install igniter The wire holder (1) is to keep ignition wires from Note - The igniter wires are already attached to the interfering with the swing-up table’s bracket. If the wire Gas Catcher Ignition Chamber and the igniter. This holder becomes loose, reinstall or replace it was done to factory test the ignition system.
- Page 16 Install Gas Supply Gas Line Piping I If the length of the line required does not exceed 50 General Specifications for Piping Note - Contact your local municipality for building feet, use a 5/8" O.D. tube. One size larger should be codes regulating outdoor gas barbecue used for lengths greater than 50 feet.
- Page 17 Check that all burner valves are off Connect flexible hose to manifold You will need: burner control knobs. You will need: the 12 foot natural supply hose and a 3/ Valves are shipped in the OFF position, but you should 4 inch wrench.
- Page 18 Representative in your region using the contact you should recheck all fittings for leaks before using information sheet provided with your manual. your Weber Gas Barbecue. Shipping and handling may When leak checks are complete, turn gas supply OFF loosen or damage a gas fitting.
- Page 19 Install the slide out bottom tray Slide the bottom tray onto the mounting rails under the You will need: the slide out bottom tray(1), catch pan cooking box with finger grip toward you(1). holder(2), catch pan and one disposable drip pan. WARNING: Do not line bottom tray with aluminum foil.
-
Page 20: Installing Features
Installing Features Install the right end trim piece with tool holders 3.) Insert one end of the swing-up work surface rod and right swing-up work surface into the hole in the frame. You will need: Right trim piece with tool holders, right swing-up work surface, swing-up work surface rod, one 1/2 inch bolt, one nylon washer and a wrench 1.) Start the right end trim piece into the frame as... - Page 21 4.) While holding swing-up work surface in position, 5.) Add a washer to the bolt and insert it through the insert the other end of the swing-up work surface front hole in the frame and the hole in the trim rod into the right end trim piece (1).
- Page 22 To raise swing-up work surface: Lift table all the way Install the left end trim piece and swing-up work up and slide it to the left, then lower table until you feel surface it lock in the up position. You will need: End trim piece, swing-up work surface, swing-up work surface rod, two 1/2 inch bolts, two nylon washers and a wrench To lower swing-up work surface: Lift table up until it...
- Page 23 4.) While holding swing-up work surface in position, To raise swing-up work surface: Lift table all the way insert the other end of the swing-up work surface up and slide it to the right, then lower table until you rod into the left end trim piece. Push the trim piece feel it lock in the up position.
- Page 24 Install control panel and burner control knobs You will need: control panel, two Phillips screws/ washers, a Phillips screwdriver, and burner control knobs. 1) Set the control panel in place over both frame braces. Hold the Crossover Ignition button up while setting the control panel in place.
-
Page 25: Warm-Up Basket
You will need: Warm-Up Basket Set the bottom shelf in place between the two frame Insert one end of the Weber Warm-Up Basket into the connectors underneath the cooking box. hole at the right side of the inside of the lid, and the... -
Page 26: Operating
7) After the FRONT burner is lit you can turn on the the hose is found to be damaged in any way, do other burner or burners. not use the barbecue. Replace using only Weber Note - Always light the FRONT burner first. The other authorized replacement hose. Contact the burner or burners ignite from the FRONT burner. -
Page 27: Manual Lighting
WARNING: If the burner does not light, turn the Manual Lighting Front burner control knob to OFF and wait 5 DANGER minutes to let the gas clear before you try again or try to light with a match. Failure to open lid while igniting the 7) After the FRONT burner is lit you can turn on the barbecue’s burners, or not waiting 5 other burner or burners. -
Page 28: Cooking
CAUTION: Do not clean your Flavorizer® Bars or desired. The control settings: High (H), Medium (M), cooking grates in a self-cleaning oven. Low (L), or Off (O) are described in your Weber For availability of replacement cooking grates and cookbook. The cookbook uses these notations to... -
Page 29: Annual Maintenance
The burners have been flame tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber Gas Barbecue. Shipping and handling may have loosened or damaged a gas fitting. WARNING: Perform these leak checks even if your barbecue was dealer- or store-assembled. -
Page 30: General Maintenance
The Weber Gas Barbecue burners have been factory Weber Spider /Insect screens set for the correct air and gas mixture. The correct Your Weber Gas Barbecue, as well as any outdoor gas flame pattern is shown. appliance, is a target for spiders and other insects. -
Page 31: Replacing Main Burners
Replacing Main Burners CAUTION: The burner openings(1) must be positioned properly over the valve orifices(2). 1) Your Weber Gas Barbecue must be OFF and cool. Check proper assembly before fastening manifold in 2) Turn gas OFF at source. place. 3) To remove control panel: take off the burner control knobs. -
Page 32: Crossover Ignition System Operations
Crossover® Ignition System Operations If the Crossover Ignition System fails to ignite the Left burner, light the Left burner with a match. If the Left burner lights with a match, then check the Crossover Ignition System. Check that both the white(1) and black(2) ignition wires are attached properly. -
Page 33: Flavorizer Bar
Troubleshooting Problem Check Cure Clean Weber Spider/Insect Screens. Burners burn with a yellow or Inspect Weber Spider/Insect orange flame, in conjunction with Screens for possible obstructions. (See Section “Annual Maintenance”) the smell of gas. (Blockage of holes.) Straighten fuel hose.
