Adjusting The Buckle Position - Britax Roundabout 55 User Manual

Adjusting the Buckle Position

IMPORTANT:
ALWAYS position the buckle in the
inner slot for rear-facing use when
using a vehicle seat belt installation.
The vehicle belt must pass in front of
the buckle strap for rear-facing use.
Position the buckle in the slot closest
to but not under the child for rear-facing use when using the LUAS
installation.
NEVER leave the buckle in the adjustment slot.
Use the outer buckle slot when installing the child seat forward-facing
with a child weighing 13.6 kg (30 lbs) and above or if the buckle is
under the child in the inner position.
1 Unbuckle the harness. Remove
the belly pad and push the
buckle through the cover.
2 Turn the buckle webbing
and slide it between buckle
positions.
3 Slide the buckle retainer into
the buckle slot, and ensure the
red release button faces out.
Child Seat Functions
ADJUSTMENT
SLOT
13
