Sanyo CDP-MT500 Service Manual page 5

Compact disc player with tuner and mp3 decoder
Hide thumbs Also See for CDP-MT500:

Advertisement

PARTS LIST
REF.NO.
PART NO.
12
645 065 6347 CD DOOR SPRING
13
645 069 5933 CABINET TOP,0370MT500010AA
14
645 069 5834 OPEN SWITCH ADAPTOR,
15
645 069 5865 CD DOOR HOOK,037PCD308890AA
16
645 069 5841 KNOB OPEN,
17
645 065 2981 OPEN KNOB SPRING
18
645 065 3179 CD MECHA CMS-M97DG6
19
645 069 5995 CUSHION RUBBER
20
645 069 6008 FIBRE WASHER
21
645 031 1604 FIBRE WASHER
23
645 065 2967 BATTERY CONTACT(+),PLATE
24
645 065 2998 BATTERY SPRING(-)
25
645 042 3116 TPP SCR 2X4,
26
645 065 2974 BATTERY PLATE +/-,SPRING
27
645 031 1567 RIBBON,
28
645 069 5940 CABINET BOTTOM,
29
645 069 5858 KNOB DBBS,HOLD,FUNCT,
30
645 069 5957 BATTERY DOOR,0370MT500080AA
31
645 031 3684 TAPPING SCR2X10,
32
645 042 1716 RUBBER FOOT,CAB BOTTOM
33
645 069 5810 ASSY CD DOOR
34
645 069 5797 ASSY CABINET BOTTOM
CD MAIN P.W.BOARD ASSY
REF.NO.
PART NO.
22
614 331 3335 ASSY,PWB,CD MAIN
CF701
645 065 6033 CER.FILTER SFU450B
CF702
645 065 6040 CER.FILTER SFE10.7MA
CF703
645 065 6088 CER.FILTER CDA10.7M
CN001
645 050 0473 HEADER 16P,TO PICK UP
CN002
645 042 1761 HEADER 6P,
CN401
645 065 4299 HEADER 9P,TO LCD DISPLAY
D0102
645 031 3646 DIODE 1N4001
D0103
645 042 1426 DIODE 1N5818
D0301
645 031 3653 DIODE 1N4148
D0401
645 031 3653 DIODE 1N4148
D0402
645 031 3653 DIODE 1N4148
D0701
645 031 3653 DIODE 1N4148
D0702
645 031 3653 DIODE 1N4148
D0703
645 045 4967 DIODE 1SV101
D0704
645 045 4967 DIODE 1SV101
D0705
645 045 4974 DIODE 1SV149 B
D0706
645 045 4974 DIODE 1SV149 B
D0707
645 031 3653 DIODE 1N4148
D0708
645 031 3653 DIODE 1N4148
D0901
645 037 0946 DIODE RB441Q-40
D0902
645 031 3653 DIODE 1N4148
IC101
645 065 2684 IC FAN8038,
IC201
645 065 2714 IC S1L9226X01-EORO,RF+SERVO
IC301
645 069 5896 IC S5L9279X01-TORO,DSP+ESP
IC302
645 069 5889 IC GM71C17403CJ,
IC401
645 069 5902 IC S3C825AX26-TWRA,
IC402
645 065 6132 IC S524A40X21,2K ESQ PROM
IC501
645 065 2691 IC FAN7000D,
IC551
645 065 6101 IC BU4066BCFV,
IC701
645 065 6118 IC TA2111F,3V AM,
IC702
645 065 6125 IC BU2614FS
J0101
645 065 2783 JACK DC POWER,DC-480
J0501
645 065 2806 JACK LINE OUT,EJS-3-0935B
J0502
645 065 2790 JACK HEADPHONE,EJS-4-3835-02
DESCRIPTION
037EH8329660AA
082MD6885570AA SLIDE SW
MAIN PCB TO BTM CAB
FOR BATT COMPARTMENT
0370MT500020AA
082MD6885750AA SLIDE SW
BTM CAB TO TOP CAB
DESCRIPTION
TO SLED SPINDLE MOTOR
4CH DRIVER +DC/DC CONVER
4X4 EDO DRAM 5V
MICROCONTROLLER MP3
STEREO HEADPHONE AMP.
QUAD ANALOG SWITCH
FM 1 CHIP TUNER
REF.NO.
PART NO.
L0101
645 042 1372 CHOKE COIL 39UH,
L0102
645 036 5522 CHOKE COIL 95UH,CY68-836522
L0103
645 031 1024 FIXED COIL 10UH,AL0305-100K-S
L0104
645 065 2660 TOROID COIL 10UH,64-24034509
L0301
645 045 4738 FIXED INDUCTOR COIL,
L0501
645 065 5999 FIXED COIL 1.2UH,AL0305-1R2K-S
L0502
645 065 5999 FIXED COIL 1.2UH,AL0305-1R2K-S
L0503
645 065 5999 FIXED COIL 1.2UH,AL0305-1R2K-S
L0701
645 045 4752 FM COIL
L0702
645 045 4745 FM COIL
L0704
645 031 1024 FIXED COIL 10UH,AL0305-100K-S
L0705
645 031 1024 FIXED COIL 10UH,AL0305-100K-S
L0706
645 065 6019 INSDUCTOR 82NH
L0707
645 065 6002 INSDUCTOR 33NH
Q0101
645 036 5560 TR 2SA1585SR
Q0102
645 050 0183 TR 2SC4115SR
Q0103
645 050 0183 TR 2SC4115SR
Q0104
645 065 2752 TRANSISTOR KTA1271Y
Q0201
645 045 5070 TR KTA1266Y
Q0301
645 065 6194 TRANSISTOR DTA144TUA
Q0302
645 065 6200 TRANSISTOR DTC144TUA
Q0303
645 065 6200 TRANSISTOR DTC144TUA
Q0304
645 069 5919 TRANSISTOR KTC8050S
Q0401
645 065 6200 TRANSISTOR DTC144TUA
Q0402
645 065 6200 TRANSISTOR DTC144TUA
Q0501
645 065 6170 TRANSISTOR KRA105S
Q0502
645 065 6200 TRANSISTOR DTC144TUA
Q0503
645 065 6200 TRANSISTOR DTC144TUA
Q0504
645 065 6200 TRANSISTOR DTC144TUA
Q0551
645 065 6200 TRANSISTOR DTC144TUA
Q0701
645 065 6217 TRANSISTOR KTC4082Y
Q0702
645 065 6200 TRANSISTOR DTC144TUA
Q0703
645 065 6170 TRANSISTOR KRA105S
Q0704
645 065 6170 TRANSISTOR KRA105S
Q0705
645 065 6224 TRANSISTOR KTC3879Y
Q0706
645 065 6194 TRANSISTOR DTA144TUA
Q0707
645 065 6187 TRANSISTOR KTA1504GR
Q0708
645 065 6217 TRANSISTOR KTC4082Y
Q0709
645 065 6200 TRANSISTOR DTC144TUA
Q0710
645 065 6163 TRANSISTOR KTC3875GR
Q0711
645 065 6163 TRANSISTOR KTC3875GR
Q0713
645 045 5018 TR 2SK118
Q0714
645 065 6224 TRANSISTOR KTC3879Y
Q0715
645 065 6163 TRANSISTOR KTC3875GR
Q0716
645 065 6163 TRANSISTOR KTC3875GR
Q0717
645 065 6163 TRANSISTOR KTC3875GR
Q0718
645 065 6163 TRANSISTOR KTC3875GR
SW102
645 031 1192 SW SLIDE,FUNCTION
SW401
645 031 1192 SW SLIDE,HOLD
SW402
645 031 1208 SW PUSH,CD DOOR LEAF SW
SW501
645 031 1192 SW SLIDE,DBBS
T0701
645 065 6231 I.F.T.
T0702
645 045 5131 AM OSC COIL
T0703
645 065 6248 I.F.T.
TC101
645 065 6095 TRIMMER 20PF
TC701
645 045 4837 TRIMMER 10PF
TC702
645 045 4837 TRIMMER 10PF
VR501
645 031 1130 ROTARY VOL
X0401
645 069 5872 CERAMIC RESONATOR 8M
XT301
645 036 5539 CERAMIC RESONATOR
XT701
645 045 5216 CRYSTAL
ZD301
645 050 4815 ZENER DIODE 5V1
645 045 5414 SPONGE,FOR L701,L702
645 065 2967 BATTERY CONTACT(+),PLATE
645 065 2998 BATTERY SPRING(-)
645 069 5780 ASSY BAR ANT
- 4 -
DESCRIPTION
CW55-842660-390K
AL0305-101K-09-S
