Daktronics bb-3140 Specifications

Two-sided transparent basketball game clock/ shot timer

Advertisement

Quick Links

bb-3140 two-sided transparent basketball game clock/
shot timer speciFications
compatible with colorsmart
This two-sided LED timer displays game time to 99:59 and shot times up to a value of 99 seconds. It can count down from any
preset shot time between 0 and 99 seconds. When period time is less than one minute, the game time is displayed to 1/10 of a
second. Around the perimeter of both sides of the display are light strips that illuminate red when the game clock displays zero.
digit size(s)
13" (330 mm)
7" (178 mm)
system
component
(height, width, depth)
2'-6" H x 2'-6" W x 3.5" D
Display
(756 mm, 756 mm, 89 mm)
Control
1'-2.25" H x 1'-2" W x 3.75" D
Enclosure
(362 mm, 356 mm, 95 mm)
5.5" H x 5.5" W x 3.5" D
Horn Enclosure
(140 mm, 140 mm, 89 mm)

prodUct saFetY

approVal:

constrUction:

digits/indicators:

displaY color:

operating
temperatUres:
dd2214812 020712 Page 1 of 2
201 Daktronics Drive, PO Box 5128, Brookings, SD 57006
Phone: 1-800-325-8766 or 605-697-4300 Fax: 605-697-4700
www.daktronics.com E-mail: sales@daktronics.com
®
digit type
power (120 Vac)
PanaView
1.6 Amps, 192 Watts
®
dimensions
UL listed, tested to CSA standards
Durable, lightweight aluminum and polycarbonate
Shot clock digits are 13" (330 mm) high red digits. Game clock digits are 7" (178 mm) high
amber digits. Seven bar segments per digit.
More than 150 colors (from Martin Senour
Display: -22 to 122 degrees Fahrenheit (-30 to 50 degrees Celsius)
Console: 32 to 130 degrees Fahrenheit (0 to 54 degrees Celsius)
Uncrated
weight
75 lb
(34 kg)
25 lb
(11 kg)
5 lb
(2.3 kg)
paint book) are available at no additional cost.
®
