- Page 1 PC-2001 Pace Clock System Display Manual Rev 3 – 23 September 2010 ED-13737 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4700 Web: www.daktronics.com Email: helpdesk@daktronics.com...
- Page 3 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ® All Sport and OmniSport are trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.
-
Page 5: Table Of Contents
Mode #8: 12 Hour Time of Day ................... 16 Mode #9: 24 Hour Time of Day ................... 16 Mode #10: Start Reaction, Normally Open (Daktronics) .......... 16 Mode #11: Relay Reaction, Normally Open (Daktronics) ........16 Team Manager ........................17 Section 5: Display Maintenance .................... -
Page 7: Introduction
Figure 1: Daktronics Drawing Label Reference Drawing: System Riser Diagram ................Drawing C-325405 Daktronics identifies manuals by the DD or ED number located on the cover page of each manual. For example, this manual would be referred to as ED-13737. Introduction... -
Page 8: Daktronics Nomenclature
Return Program. Refer to these instructions if replacing or repairing any display component. Product Safety Approval Both models of the PC-2001 are ETL-listed, tested to CSA standards and CE-labeled for indoor use. The outdoor model has been tested and certified for outdoor use. Contact Daktronics with any questions regarding the testing procedures. -
Page 9: Display Overview
The timing display is powered by 12 V batteries. Detachable power cord/transformer assemblies also permit operation of the PC-2001 with 120 or 230 V AC. The unit draws 1 A of power. The enclosed batteries (two in the outdoor model and one in the indoor display) are rechargeable and have a built-in charger. -
Page 11: Mechanical Installation
This section describes the mounting details of the PC-2001. Use this section when mounting a display to a wall or on the tripod kit. Other mounting methods can be used, but Daktronics engineers do not recommend those not documented here. Daktronics is not responsible for mounting the display. -
Page 12: Tripod Mounting
Tripod Mounting Mounting the display to a tripod requires the optional tripod mounting kit (Daktronics part number 0A-1153-0325). A camera tripod is not sturdy enough to safely support the display and will not attach to the display or adapter plate. An appropriate “speaker stand” tripod is available from Daktronics (part number A-1580). -
Page 13: Electrical Installation
Figure 8). Auto Off The PC-2001 features an Auto Off function, which will automatically turn the unit off in response to two conditions: Idle Timeout – If the display is not plugged into a transformer, and not in program 8... -
Page 14: Signal
To turn the PC-2001 on after an Auto Off has occurred, turn the power switch off, wait a few minutes, and then turn it back on. In the case of a low battery, be sure to plug the display into a charger before continuing use. -
Page 15: Controls & Timing Functions
System setup information for each of the programs is shown in Figure 7. This chart is also printed on a vinyl quick reference decal on the rear of the display case. Figure 7: PC-2001 Programs and System Connections Controls & Timing Functions... -
Page 16: Program Selection
The Model PC-2001 display is programmable for 11 different timing programs. The operator selects each program and makes settings for the functions using the switches on the right side of the display. Figure 8 shows the PC-2001 control panel and programming connections. To select a program:... -
Page 17: Program Operations
If a touchpad is not plugged into the PC-2001 but a platform is, the <STOP> button can emulate a touchpad being touched and starts timing from to the time the next swimmer leaves the platform. -
Page 18: Jc-100 Console Operation
PC-2001. The keypad insert number needed for operation is LL-2584 (Drawing A-191855 in Appendix A). When the PC-2001 is turned on and the JC-100 is connected, press <MENU> on the control console to view the available options. Use the up and down arrows to scroll through these options, or press the number located next to the option. -
Page 19: Time
The settings will need to be changed to fit the user‟s specific needs, but once the program has the desired settings, the console will remember those settings for next use. The available settings and menu numbers will vary by the current mode. Time The Time setting lets users enter desired timing options for the MENU-SETTINGS... -
Page 20: Mode #2: Start Reaction, Normally Closed (Omega)
A negative number indicates an early leave. Press the <RESET> key to start the program over. Mode #4: Relay Reaction, Normally Closed (Omega) When the PC-2001 is plugged into both a touchpad and a relay MENU-CHANGE MODE take-off platform and the platform is closed, the JC-100 will 4-RLY RCT N.C. -
Page 21: Mode #6: Game Clock
REST – This step allows users to enter the amount of time to have the swimmer(s) rest within one step. PACE – This step allows users to enter a pace step that will override the rest of the workout (or circuit if a pace step is entered within one) and continue to count up to the entered time, return to 0:00 and start counting again. -
Page 22: Mode #7: Shot Clock
Mode #11: Relay Reaction, Normally Open (Daktronics) MENU-CHANGE MODE When the PC-2001 is plugged into both a touchpad and a relay 11-RLY RCT N.0. take-off platform and the platform is closed, the JC-100 will automatically start the timing from when the touchpad is... -
Page 23: Team Manager
"Transfer completed for lanes 1." Click OK. The PC-2001 should read “donE”. If this does not happen, the download did not work properly. Start the PC-2001 workout by pressing the <START> button on the side of the display or the <START> key on the JC-100. -
Page 25: Display Maintenance
3. Disconnect power when not using the scoreboard. Digit/Driver Printed Circuit Board The PC-2001 uses a single printed circuit board (PCB) that contains all of the electronics needed to make this system work: digit LEDs, control processors, power input connectors, horn, and other components. -
Page 26: Replacing The Digit/Driver Printed Circuit Board
Replacing the Digit/Driver Printed Circuit Board To access the digit/driver PCB, remove the 10 outer screws to separate the front and back panels of the display. Disconnect all power and signal connections from the PCB by squeezing together the locking tabs and pulling the connector free. Remove the 8 nuts securing the PCB to the front panel of the display. -
Page 27: Schematics
For advanced scoreboard troubleshooting and repair, it may be necessary to consult the schematic drawing. Drawing A-177466 in Appendix A shows detailed power and signal wiring diagrams of internal display components. Replacement Parts List Refer to the following table for Daktronics replacement parts: Description Daktronics Part # Indoor PCB... -
Page 28: Daktronics Exchange And Repair & Return Programs
In most circumstances, the replacement part will be invoiced at the time it is shipped. If the failed part or replacement part is not returned to Daktronics within 3 weeks of the ship date, Daktronics will assume that the customer is purchasing the replacement part and will send an invoice for the value of the new sale part. -
Page 29: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market number in the chart listed on the previous page. -
Page 31: Appendix A: Reference Drawings
Schematic, PC-2001 and TI-2022 ................Drawing A-177466 Insert, LL-2584, JC-100 Pace Clock ................. Drawing A-191855 Riser Diagram; PC-2001 Portable Install ..............Drawing B-192024 Riser Diagram; PC-2001 & PC-2002 ................. Drawing A-195172 Reference Drawings... - Page 34 SWIM REST STOP CIRCUIT JC-100 PACE CLOCK LL-2584, REV 01...
- Page 37 Daktronics Warranty and Limitation of Liability...
- Page 39 Equipment from operating for its intended use. With respect to LEDs, “Defects” are defined as LED pixels that cease to emit light. The limited warranty provided by Daktronics does not impose any duty or liability upon Daktronics for partial LED pixel degradation.
- Page 40 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
