LED Drivers .............................8 Replacing a Driver ����������������������������������������������������������������������������������������������������������������������������9 Setting the Driver Address ���������������������������������������������������������������������������������������������������������������9 Replacement Parts ..........................9 Daktronics Exchange and Repair & Return Programs ����������������������������������������������������11 Exchange Program ..........................11 Repair & Return Program ........................12 Daktronics Warranty & Limitation of Liability ...................12 A Reference Drawings �����������������������������������������������������������������������������������������������������������13 Daktronics Warranty &...
This manual explains the installation and maintenance of Daktronics Transparent Shot Clocks. For additional information regarding safety, installation, operation, or service, refer to the telephone numbers listed in Section 5: Daktronics Exchange and Repair & Return Programs (p�11). This manual is not specific to a particular installation. Project- specific information takes precedence over general information found in this manual.
Specially ordered part PR-XXXXX-X Control Console Daktronics transparent shot clocks are typically controlled by the same All Sport 5000 control console as the scoreboard(s) in the facility. Refer to the following manual for operation: All Sport 5000 Series Control Console Operation Manual (ED-11976) •...
Assy; Camera Cable Holder................DWG-249064 If a camera is to be added (BB-2140 and BB-2150 only), camera mounts accepting 2" (51 mm) pipe are available; only one may be used at a time. A cable tray can be used to route camera wiring down either side of the shot clock.
– must be electrically grounded. Only qualified individuals may perform electrical work, including verification of ground resistance. Daktronics is not responsible for improper grounding or damage incurred as a result of improper grounding. Grounding methods must meet the provisions of all applicable local and national codes.
J7 jack in the control enclosure and mounted internally to the front panel of the enclosure. Note: A 5-pin to 6-pin adaptor (Daktronics part # W-2913) is required to connect newer radio units to the shot clock driver. For additional information about this option, contact a Daktronics representative. For complete instructions on setting up radio control, refer to the Gen VI Radio Installation Manual (DD2362277), available online at www.daktronics.com/manuals.
Troubleshooting Disconnect power before doing any repair or maintenance work on the display� Permit only qualified service personnel to access internal display electronics. Disconnect power when not using the display� Troubleshooting Table This section lists potential problems with the device, indicates possible causes, and suggests corrective action.
Replace if necessary. Component Access & Digit Replacement Reference Drawings: Component Access; BB-2140 & BB-2141 ............DWG-236432 Component Access; BB-2150 & BB-2151 ............DWG-1060251 Refer to DWG-236432 and DWG-1060251 for instructions on how to open the shot clock cabinet and replace the digit panels.
Schematics Reference Drawings: Schematic: Control Enclosure- 120/240V AC ..........DWG-216653 For advanced display troubleshooting and repair, it may be necessary to consult the schematic drawings. DWG-216653 shows detailed power and signal wiring diagrams of internal display components such as drivers, transformers, and horns. The schematic drawing also shows the DIP switch settings that control when the horn sounds and when the LED light strips turn on.
Page 14
13" 7-Segment plus Tenths, Dual-Sided, Red (BB-2150) 0P-1322-0008 Transformer, 16 VAC T-1066 Transformer, 10 VAC T-1082 Cable; 4-pin to 4-pin, 30' W-1823 Refer to Section 5: Daktronics Exchange and Repair & Return Programs (p�11) for information on exchanging or returning parts. Troubleshooting...
Fill out and attach the enclosed UPS shipping document. c� Ship the part to Daktronics. 3� The defective or unused parts must be returned to Daktronics within 5 weeks of initial order shipment� If any part is not returned within five (5) weeks, a non-refundable invoice will be presented to the customer for the costs of replenishing the exchange parts inventory with a new part.
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: 1� Call or fax Daktronics Customer Service� Refer to the appropriate number in the chart on the previous page.
Refer to Resources (p�1) for information regarding how to read the drawing number. Any contract-specific drawings take precedence over the general drawings. Reference Drawings: Court View, BB-2140 and BB-2141 ..............DWG-184787 Connection Diagram: BB-2140 & BB-2141 ............DWG-184789 Schematic: Control Enclosure- 120/240V AC ..........DWG-216653 Mechanical Spec, BB-2140 ................
Page 22
PER EC-16838, INCREASED BASE WIDTH FROM 6" TO 8", DATE: INCREASED MTG HOLE SPACING FROM 4.875" TO 6.5" 19 AUG 15 DATE: DATE: DATE: DATE: DATE:...
Page 23
DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS PER EC-16838, INCREASED BASE WIDTH FROM 6" TO 8", WRITTEN CONSENT OF DAKTRONICS, INC. DATE: INCREASED MTG HOLE SPACING FROM 4.875" TO 6.5" COPYRIGHT 2015 DAKTRONICS, INC.
Page 26
HAZARDOUS VOLTAGE AT EXPOSED TERMINALS DISCONNECT POWER BEFORE SERVICING...
Page 29
PER EC-16838, INCREASED BASE WIDTH FROM 6" TO 8", DATE: INCREASED MTG HOLE SPACING FROM 4.875" TO 6.5" 19 AUG 15...
Page 30
PER EC-16838, INCREASED BASE WIDTH FROM 6" TO 8", DATE: INCREASED MTG HOLE SPACING FROM 4.875" TO 6.5" 19 AUG 15...
Daktronics Warranty & Limitation of Liability This section includes the Daktronics Warranty & Limitation of Liability statement (SL-02374)� Daktronics Warranty & Limitation of Liability...
Page 38
Limitation of Liability Daktronics shall be under no obligation to furnish continued service under this Warranty if alterations are made to the Equipment without the prior written approval of Daktronics. It is specifically agreed that the price of the Equipment is based upon the following limitation of liability. In no event shall Daktronics (including its subsidiaries, affiliates, officers, directors, employees, or agents) be liable for any claims asserting or based on (a) loss of use of the facility or equipment; lost business, revenues, or profits; loss of goodwill; failure or increased cost of operations; loss, damage or corruption of data; loss resulting from system or service failure, malfunction, incompatibility, or breaches in system security; or (b) any special, consequential, incidental or exemplary damages arising out of or in any way connected with the Equipment or otherwise, including but not limited to damages for lost profits, cost of substitute or replacement equipment, down time, injury to property or any damages or sums paid to third parties, even if Daktronics has been advised of the possibility of such damages. The foregoing limitation of liability shall apply whether any claim is based upon principles of contract, tort or statutory duty, principles of ...
