Hardware Installation Steps; Figure 2-2 Sample Xprintserver Mounting Options - Lantronix xPrintServer User Manual

Orange "X" LED
Code 8

Hardware Installation Steps

With all xPrintServer package contents and the requisite user-supplied items listed above, you
may begin installation.
1. Make sure of the following:
- Your devices (smartphone, tablet or PC) are on the same Wi-Fi® or wired network as
your xPrintServer unit.
- Printing from your Windows or Mac computer (from which the USB printer is directly
attached) is working before proceeding. If you are installing a new USB printer, this may
require downloading and installing printer drivers to your desktop from the printer
manufacturer.
2. Position the xPrintServer device. The xPrintServer can simply be placed as it is on a desk or
other secure flat surface. Here are additional options:
- To install the rubber feet on the xPrintServer (for added grip and stability on a flat
surface), peel to unveil the adhesive strip on each rubber foot and press one foot onto
each of all four bottom corners of the xPrintServer unit.
- To secure the xPrintServer into a server rack, utilize the included mounting bracket and
screws. There are a variety of ways to mount the bracket and then the xPrintServer unit,
including the two sample methods in
Lantronix® xPrintServer® User Guide
Description
A repeating pattern of eight flashes followed by two seconds of no
light indicates USB device (printer or flash drive) discovery is in
progress.

Figure 2-2 Sample xPrintServer Mounting Options

Figure 2-2.
or
2: Installation
described in the
grey cells to the
left.
12
