General Specifications; Cooling System - Fractal design Define R4 Product Sheet

Product Sheet

General Specifications

Motherboard compatibility
Front interface
Drive bay capacity
Expansion slots
PSU compatibility
Graphics card compatibility
Cooling / Ventilation
CPU cooler compatibility
Additional information
Colours available / SKU
Case dimensions (WxHxD)
(mm)
Net weight (kg)
Package contents

Cooling System

Front
Rear
Top
Bottom
Side
Fan controller
Model
Define R4 Black Pearl
Define R4 Titanium Grey
Define R4 Arctic White
Fractal Design brings you scandinavian design and quality
• ATX, Micro ATX, Mini ITX
• 2 - USB 3.0, 2 - USB 2.0
• Audio in/out
• Power button with LED (blue)
• Reset button
• Fan controller (behind door)
• 2 - 5.25" bays
• 8 - 3.5" HDD trays - all compatible with SSDs
• 2 - 2.5" extra SSD positions
• 7 + 1
• ATX PSUs up to 170 mm deep when using the bottom fan location; when not
using this fan location longer PSUs (up to 270 mm deep) can be used
• Graphics cards up to 295mm in length with the top HDD cage installed
• With the top cage removed, graphics cards up to 430mm in length may be
installed
• 3 - ModuVent™ plates – two in the top and one in the side
• 7 - Fan positions (2 fans included)
• Filtered fan slots in front and bottom
• CPU coolers up to 170 mm tall (when no fan is installed in the side panel)
• 26 mm of space for cable routing behind the motherboard plate
• Thick rubber grommets on all holes on the motherboard plate
• Black Pearl / FD-CA-DEF-R4-BL
• Titanium Grey / FD-CA-DEF-R4-TI
• Arctic White / FD-CA-DEF-R4-WH
• 232 x 464 x 523
• 12,3
• Define R4 computer case
• User manual
• Accessory box
• 1 - hydraulic bearing 140mm Silent Series R2 fan, 1000 RPM speed (included)
• 1 - 120/140mm fan
• 1 - hydraulic bearing 140mm Silent Series R2 fan, 1000 RPM speed (included)
• 2 - 120/140mm fans - positions also support 240/280mm radiators
• 1 - 120/140mm fan
• 1 - 140mm fan
• 1 - integrated fan controller for up to 3 fans (included)
Model SKU
FD-CA-DEF-R4-BL
FD-CA-DEF-R4-TI
FD-CA-DEF-R4-WH
www.fractal-design.com
EAN
7350041080916 817301010917
7350041080923 817301010924
7350041080930 817301010931
UPC
