General Specifications; Cooling System; Model Information - Fractal design Define R4 Product Sheet

Product Sheet

General Specifications

Motherboard compatibility
Front interface
Drive bay capacity
Expansion slots
PSU compatibility
Graphics card compatibility
Cooling / Ventilation
CPU cooler compatibility
Additional information
Colours available / SKU
Case dimensions (WxHxD)
(mm)
Net weight (kg)
Package contents

Cooling System

Front
Rear
Top
Bottom
Fan controller
Model
Define R4 Black Pearl - Window
Define R4 Titanium Grey - Window
Define R4 Arctic White - Window
Fractal Design brings you scandinavian design and quality
• ATX, Micro ATX, Mini ITX
• 2 - USB 3.0, 2 - USB 2.0
• Audio in/out
• Power button with LED (blue)
• Reset button
• Fan controller (behind door)
• 2 - 5.25" bays
• 8 - 3.5" HDD trays - all compatible with SSDs
• 2 - 2.5" extra SSD positions
• 7 + 1
• ATX PSUs up to 170 mm deep when using the bottom fan location; when not
using this fan location longer PSUs (up to 270 mm deep) can be used
• Graphics cards up to 295mm in length with the top HDD cage installed
• With the top cage removed, graphics cards up to 430mm in length may be
installed
• 2 - ModuVent™ plates – two in the top
• 6 - Fan positions (2 fans included)
• Filtered fan slots in front and bottom
• CPU coolers up to 170 mm tall
• 26 mm of space for cable routing behind the motherboard plate
• Thick rubber grommets on all holes on the motherboard plate
• Black Pearl / FD-CA-DEF-R4-BL-W
• Titanium Grey / FD-CA-DEF-R4-TI-W
• Arctic White / FD-CA-DEF-R4-WH-W
• 232 x 464 x 523
• 12,3
• Define R4 - Window computer case
• User manual
• Accessory box
• 1 - hydraulic bearing 140mm Silent Series R2 fan, 1000 RPM speed (included)
• 1 - 120/140mm fan
• 1 - hydraulic bearing 140mm Silent Series R2 fan, 1000 RPM speed (included)
• 2 - 120/140mm fans - positions also support 240mm radiators
• 1 - 120/140mm fan
• 1 - integrated fan controller for up to 3 fans (included)
Model SKU
FD-CA-DEF-R4-BL-W
FD-CA-DEF-R4-TI-W
FD-CA-DEF-R4-WH-W
www.fractal-design.com
EAN
7350041081012 817301011013
7350041081029 817301011020
7350041081036 817301011037
UPC
