IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, electric shock or personal injury. SAFETY PRECAUTIONS Use this appliance only for its intended Turn the mode control to OFF and unplug purpose as described in this Owner’s your air conditioner before making any...
www.GEAppliances.com WARNING! USE OF EXTENSION CORDS – 115-Volt models only Because of potential safety hazards under certain CAUTION: conditions, we strongly recommend against the use of an extension cord. DO NOT use an extension cord with any of However, if you must use an extension cord, the 230/208 volt models.
About the controls on the air conditioner–models with touch pads. Features and appearance will vary. Air Conditioner Controls Remote Control Controls ON/OFF Pad TIMER Pad ON– When the air conditioner is off, it can be Turns air conditioner on and off. set to automatically come on in 1 to 12 hours Display at its previous setting.
Page 5
www.GEAppliances.com When the air conditioner is turned on, it will Lights next to the touch pads on the air conditioner automatically start in the last cool and fan control panel indicate the selected settings. settings used. COOL Mode Use the COOL mode with HIGH (F3), MED (F2) or Cooling Descriptions LOW (F1) fan for cooling.
About the controls on the air conditioner–models with control knobs. Features and appearance will vary. HIGH HIGH COOL COOL COOL COOL COOL MODE CONTROLS Your model will have one of the above type controls. TEMP CONTROLS Your model will have one of the above type controls. Controls Mode Controls Temp Controls...
Page 7
www.GEAppliances.com Additional controls and important information. Energy Saver (on some models) The energy saver switch controls the fan. OFF — The fan runs all the time, while the compressor cycles on and off. ON —The fan and compressor cycle on and off together.
The coils on the outdoor side of the air conditioner should be checked regularly. If they are clogged with dirt or soot they may be professionally steam cleaned, a service available through your GE service outlet. Air Filter The air filter behind the front grille should be checked and cleaned at least every 30 days or more often if necessary.
Preparing to install the air conditioner. Read these instructions completely and carefully. Before You Begin NOTE TO INSTALLER: Leave these instructions with CAUTION: the air conditioner after installation is completed. Do not, under any circumstances, cut or remove the third (ground) prong from the NOTE TO CONSUMER: Keep this Owner’s Manual power cord.
Window Installation Instructions. Parts Included Top mounting rail Window sash seal Left accordion Foam top panel window gasket Top mounting rail seal strip Frame guide (2) Right accordion panel Sill bracket (2) Support bracket (2) Window locking bracket Type A (14) Type B (7) Type C (5) Type D (2)
Page 11
Read completely, then follow step-by-step. Window Requirements These instructions are for a standard double- hung window. You will need to modify them for other types of windows. The air conditioner can be installed without the accordion panels if needed to fit in a narrow window.
Window Installation Instructions. Remove the Air Conditioner From the Case Remove the 2 shipping screws from the back of Slide the air conditioner from the case by the case. gripping the base pan handle and pulling forward while bracing the case. Remove the 2 screws on each side of the case.
Page 13
Prepare the Window Loosely attach the sill brackets to the support Open the window and mark the centerline of brackets using the 2 carriage bolts and 2 the window stool. Measure and mark 11″ to the lock nuts. left and right of the centerline. Support bracket Carriage bolt...
Window Installation Instructions. Install the Window Locking Bracket and the Foam Top Window Gasket Attach the window locking bracket with a Cut the foam top window gasket to the window type C screw. width. Stuff the foam between the glass and the window to prevent air and insects from getting into the room.
Before you call for service… Troubleshooting Tips Save time and money! Review the chart below first and you may not need to call for service. Problem Possible Causes What To Do • Make sure the air conditioner plug is pushed completely Air conditioner The air conditioner into the outlet.
Before you call for service… Troubleshooting Tips Normal Operating Sounds You may hear a pinging noise caused by water Water will collect in the base pan during being picked up and thrown against the high humidity or on rainy days. The water condenser on rainy days or when the humidity is may overflow and drip from the outdoor side high.
You can rest easy, knowing that all your valuable household products are protected against expensive repairs. 800-626-2224 Place your confidence in GE and call us in the U.S. toll-free at for more information. *All brands covered, up to 20 years old, in the continental U.S.
Our service number is safety modification. 800 GE CARES (800-432-2737). Model Number Serial Number Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered, or register online at www.GEAppliances.com.
Page 19
Any part of the air conditioner which fails due to a defect in materials or workmanship. One Year During this full one-year warranty, GE will also provide, free of charge, all labor From the date of the and in-home service to replace the defective part.
Contact Us www.GEAppliances.com If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including your phone number, or write to: General Manager, Customer Relations GE Appliances, Appliance Park...
