Fusion Performance PF-SW100D2 User Manual page 2

Peak Power (Watts)
Rated Power (Watts)
Frequency Response
Impedance
Sensitivity
Cone Material
Voice Coil Type Round Wound Copper
Mounting Depth 145mm (5-11/16")
Mounting Diameter 230mm (9-1/16")
PF-SW100D2
Volume 25L (0.88 cu.ft)
Fb (Hz) Tuned frequency
Port Diameter
Port Length 116mm (4-9/16")
PF-SW120D2
Volume
Fb (Hz) Tuned frequency
Port Diameter
Port Length
PERFORMANCE 2 X 2 DUAL OHM SUBWOOFER MANUAL OUTLINES.indd 2
PF-SW100D2 PF-SW120D2
1400 1600
350 400
38Hz - 1.5kHz 30Hz - 1.2kHz
2 x 2 Ohm 2 x 2 Ohm
87dB 89dB
Pressed Paper Pressed Paper
Round Wound Copper
158mm (6-1/4")
279mm (11")
Ported Sealed
15L (0.53 cu.ft)
42Hz 62Hz
76.2mm (3") -
-
Ported Sealed
40L (1.4 cu.ft) 25L (0.88 cu.ft)
38Hz 64Hz
76.2mm (3") -
101mm (4") -
