Fusion MS-AB108 Instruction Manual

MARINE ACTIVE SUBWOOFER
MS-AB108

SPECIFICATIONS

MAX POWER RATING
FREQUENCY RESPONSE
LOW PASS FILTER (VARIABLE)
TUNING
WOOFER SIZE
FUSE
DIMENSIONS
PRODUCT CONTENTS
1x MS-AB108 Active subwoofer
1x Power / GND/ Remote-ON wire loom
1x RCA Cable
Mounting Hardware
Manual
Warranty Card
CONTROL DESCRIPTIONS
LEVEL
This allows the adjustment of the amplifier input level. Turn clockwise to
increase the level. If the sound becomes distorted reduce the level.
LOW PASS FILTER (LPF)
This allows the adjustment of the highest frequency the Marine Active
Enclosure will produce.
This should be adjusted to blend with your main speakers. Typically, this
will be set to around 100Hz (approximately the central position of the
control knob).
WARNING! Audio Systems can produce sound levels over 135dB. Continuous exposure to sound pressure levels over 100dB may cause permanent hearing loss!
www.fusionelectronics.com
PUBLISHED BY FUSION ELECTRONICS LIMITED: © Copyright 2009 by FUSION Electronics Limited. All rights reserved. Specifications and design are subject to change without notice.
YOU CAN HELP PROTECT THE ENVIRONMENT! Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center.
210 Watts
30Hz – 250Hz
30Hz – 250Hz
Bass Reflex
8" down firing
10 Amp
Length 515mm - 20 1/4"
Width 233mm - 9 3/16"
Height 190mm - 7 1/2"
INSTALLATION
Make sure the Marine Active Enclosure is firmly secured.
»
» Check before drilling or cutting holes.
DO NOT work near gas tanks, fuel lines, hydraulic lines or electrical
»
wiring.
» DO NOT mount the Marine Active Enclosure in such a way as to pinch
or damage the wires.
» Make sure everything is firmly connected, before attaching the +12V
wire. Make sure the +12V wire is fused as close as possible to the
battery. ALWAYS use a fuse with the recommended rating.
(Wiring diagram on reverse)
RECORD YOUR PURCHASE DETAILS HERE:
MODEL NUMBER
DATE OF PURCHASE
AFFIX RECEIPT HERE
v 1.0
