POWERPLANT
SUBWOOFER MODELS
PP–SW10E, PP–SW12E, PP–SW15E,
PP–SW10H, PP–SW12H, PP–SW15H

Advertisement

Table of Contents
loading

Related Manuals for Fusion POWERPLANT PP–SW10E

Summary of Contents for Fusion POWERPLANT PP–SW10E

  • Page 1 POWERPLANT SUBWOOFER MODELS PP–SW10E, PP–SW12E, PP–SW15E, PP–SW10H, PP–SW12H, PP–SW15H...
  • Page 2 POWERPLANT Explore the limits of car audio and PowerPlant will get you there. FUSION PowerPlant delivers accurate clear sound reproduction with real power. Push sound further than it’s gone before, confident that PowerPlant products have been engineered, designed and manufactured to...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS • SUBWOOFER FEATURES ........pg 4 •...

  • Page 4: Subwoofer Features

    The cone is dimple pressed with PowerPlant super graphic, catering for style, strength and sound performance. SPIDER In order to keep the cone assembly balanced and linear, FUSION has used green poly cotton flat spiders to reduce the mechanical distortion for better sound quality. VOICE COIL PowerPlant Subwoofers use dual 4 ohm configuration.

  • Page 5: Subwoofer Theile/Small Parameters

    SUBWOOFER THEILE/SMALL PARAMETERS Subwoofer Parameters PP-SW10E PP-SW12E PP-SW15E MAX Power Rating (Watts) 1200 RMS Power Rating (Watts) Coil Height (Hvc) (mm) Compliance (Cms) (uM/N) 281.69 248.25 148.67 Cone Area (Sd) 31.41 49.09 80.42 D.C.Coil Resistance (Re) 1.81 1.82 1.79 Electrical Q (Qes) 0.46 0.39 0.56...
  • Page 6 SUBWOOFER THEILE/SMALL PARAMETERS cont... Subwoofer Parameters PP-SW10H PP-SW12H PP-SW15H MAX Power Rating (Watts) 1200 1500 RMS Power Rating (Watts) Coil Height (Hvc) (mm) Compliance (Cms) (uM/N) 291.8 147.72 Cone Area (Sd) 31.41 49.09 80.42 D.C.Coil Resistance (Re) 1.75 1.85 1.75 Electrical Q (Qes) 0.41 0.411...

  • Page 7: Subwoofer Dimensions Pp-Sw10E

    DIMENSIONS SUBWOOFER PP-SW10E 282mm (11– 1/8") 240mm (9 – 7/16") 282mm (11–1/8") 7 7 7...

  • Page 8: Subwoofer Dimensions Pp-Sw12E

    DIMENSIONS SUBW00FER PP-SW12E 333mm (13 –1/8") 291mm (11– 7/16") 333mm (13 –1/8") 8 8 8...

  • Page 9: Subwoofer Dimensions Pp-Sw15E

    DIMENSIONS SUBWOOFER PP-SW15E 410mm (16–1/8") 366mm (14 – 7/16") 410mm (16 –1/8") 9 9 9...

  • Page 10: Subwoofer Dimensions Pp-Sw10H

    DIMENSIONS SUBW00FER PP-SW10H 282mm (11–1/8") 240mm (9 –7/16") 282mm (11–1/8")

  • Page 11: Subwoofer Dimensions Pp-Sw12H

    DIMENSIONS SUBWOOFER PP-SW12H 333mm (13 –1/8") 291mm (11– 7/16") 333mm (13 –1/8")

  • Page 12: Subwoofer Dimensions Pp-Sw15H

    DIMENSIONS SUBW00FER PP-SW15H 410mm (16 –1/8") 366mm (14– 7/16") 410mm (16 –1/8")

  • Page 13: Enclosures

    ENCLOSURES All enclosures include port and subwoofer displacement. All ports are circle aero ports unless otherwise stated. Ported Enclosures: A ported enclosure is generally larger than a sealed enclosure Sealed Enclosures: A sealed enclosure will be the smallest enclosure you can build. It will have a tight low frequency response, but not as low as a ported enclosure.
  • Page 14 Enclosures should be glued and screwed, because MDF is porous. FUSION recommends sealing the internal sides with a polyurethane sealer prior to installation. To accurately cut the subwoofer hole use the unique FUSION ruler guide included inside the FUSION Subwoofer packaging...

  • Page 15: Enclosure Test Curves

    ENCLOSURE TEST CURVES SUBWOOFER PP-SW10E SEALED Amplitude Response (dB-SPL/Hz at 1 m) with 750 watts 1000 PORTED Amplitude Response (dB-SPL/Hz at 1 m) with 750 watts 1000...
  • Page 16 ENCLOSURE TEST CURVES SUBW00FER PP-SW12E SEALED Amplitude Response (dB-SPL/Hz at 1 m) with 900 watts 1000 PORTED Amplitude Response (dB-SPL/Hz at 1 m) with 900 watts 1000...
  • Page 17 ENCLOSURE TEST CURVES SUBWOOFER PP-SW15E SEALED Amplitude Response (dB-SPL/Hz at 1 m) with 1200 watts 1000 PORTED Amplitude Response (dB-SPL/Hz at 1 m) with 1200 watts 1000...
  • Page 18 ENCLOSURE TEST CURVES SUBW00FER PP-SW10H SEALED Amplitude Response (dB-SPL/Hz at 1 m) with 900 watts 1000 PORTED Amplitude Response (dB-SPL/Hz at 1 m) with 900 watts...
  • Page 19 ENCLOSURE TEST CURVES SUBWOOFER PP-SW12H SEALED Amplitude Response (dB-SPL/Hz at 1 m) with 1200 watts 1000 PORTED Amplitude Response (dB-SPL/Hz at 1 m) with 1200 watts 1000...
  • Page 20 ENCLOSURE TEST CURVES SUBW00FER PP-SW15H SEALED Amplitude Response (dB-SPL/Hz at 1 m) with 1500 watts 1000 PORTED Amplitude Response (dB-SPL/Hz at 1 m) with 1500 watts 1000...

  • Page 21: Tech Tips

    TECH TIPS POWER CABLE CALCULATOR TOTAL AMPERAGE 0-4 FT 4-7 FT 7-10 FT 10 -13 FT 13-16 FT 16-19 FT 19-22 FT 22-28 FT 0 – 20 20 – 35 35 – 50 50 – 65 65 – 85 85 – 105 105 –...
  • Page 22 SUBWOOFER RULER GUIDE Use the FUSION ruler guide to create a perfect subwoofer mounting surface. Fig. 1 1: Mark the centre position on the MDF (Medium Density Fibre) board where the subwoofer is to be mounted. (mm) Centre 1 " 0 10"...
  • Page 23 (mm) Centre 1 " 0 10" outside 12" 12" outside 15" 15" outside usionc r udio com cutout 263mm cutout 312mm cutout 389mm (inch) Fig. 3 3: Insert a pencil into the correct subwoofer cut out measurement. 10", 12", or 15". Fig.
  • Page 24 SERIES AND PARALLEL SUBWOOFER WIRING FOR DUAL VOICE COIL SUBS Parallel Voice Coil Wiring (2 Ohm operation) To wire a DVC subwoofer in parallel (to get 2 Ohms), use two short pieces of speaker wire and link the positive from one coil to the positive of the second coil, and do the same for the negative as shown in fig 1.
  • Page 25 PARALLEL WIRING FORMULA FOR 2 SPEAKERS 4 Ohm 8 Ohm 2.67 Ohms R1 x R2 4 Ohms x 8 Ohms LOAD IMPEDANCE 2.67 Ohms R1 + R2 4 Ohms + 8 Ohms SERIES WIRING FORMULA FOR 2 SPEAKERS – – 4 Ohm 4 Ohm –...

  • Page 26: Trouble Shooting

    TROUBLE SHOOTING No sound from your subwoofer: Check amplifier and wiring connections. Distorted sound: Check the connections from amplifier, processor or head unit. Subwoofer makes unusual noise in sealed enclosure: The enclosure may have leaks causing a lack of back pressure. Remove the subwoofer and ensure the enclosure is completely sealed. Use sealer and polyurethane to do this.
  • Page 27 YOU CAN HELP PROTECT THE ENVIRONMENT! PUBLISHED BY FUSION ELECTRONICS LIMITED: Please remember to respect the local regulations: © Copyright 2006 by FUSION Electronics Limited. Hand in the non-working electrical equipment All rights reserved. Specifications and design are to an appropriate waste disposal center.
  • Page 28 Specifi cations and design are subject to change without notice.
