REACTOR
SUBWOOFERS
RE-SW120, RE-SW150
Subwoofer Parameters
Max Power Rating
RMS Power Rating
Frequency Response
Impedance
Sensitivity
Mounting Depth
Mounting Diameter
Installation Guidelines
Ensure the audio system is turned off before making any connections to the amplifier, subwoofer or source unit.
Failure to do so could result in permanent damage to the audio system.
When wiring the subwoofer ensure that the wire is protected from sharp objects and always use rubber grommets
when wiring through metal panels. Ensure all terminals and connections are protected from the vehicle chassis and
from each other as failure to do so could result in permanent damage to the audio system.
When connecting the amplifier and subwoofer ensure you connect the positive and negative output wire from the
amplifier to the corresponding subwoofer terminals.
1) Ensure there is adequate clearance and depth for the subwoofer to be mounted
2) Use the supplied ruler to mark out and cut the correct diameter hole
3) Drill the holes for the mounting screws
4) Insert the subwoofer and affix with the appropriate screws (not included)
Optimum Enclosures
Ported
Volume (litres)
Volume (cu.ft.)
Port diameter
Port length
Tuned frequency (Hz)
Sealed
Volume (litres)
Volume (cu.ft.)
Tuned frequency (Hz)
RE-SW120
RE-SW150
600 Watts
750 Watts
250 Watts
320 Watts
30Hz - 2.5kHz
25Hz - 2kHz
4 Ohms
4 Ohms
89 dB
90 dB
155mm (6-
")
172mm (6-
1/8
275mm (10 -
") 349mm (13 -
13/16
RE-SW120
RE-SW150
23
0.8
58.8mm / 2"
101mm / 4"
186mm / 7.35"
285mm / 11.2"
45
23
0.8
80
")
3/4
")
3/4
100
3.5
31
41.6
1.47
54
