Installing a New Ceiling Fixture Outlet Box

If you do not have an existing fixture located where you wish

to place your fan, an approved ceiling fixture outlet box must

be installed and wired.

WARNING: To reduce the risk of fire, electrical shock,

or personal injury, mount to outlet box marked

acceptable for ceiling fan support using the

mounting hardware provided with the outlet box.

Proceed with installation as follows:

Step 7. Attach the bracket to the ceiling fixture outlet

box with the mounting hardware included with the outlet

box.

Tighten the screws firmly by hand only, being careful not

to bend the bracket by overtightening.

NOTE: On sloped ceilings, align the canopy

opening towards the top or room peak.

CAUTION: To reduce the risk of

personal injury, use only the

mounting hardware provided with

the approved outlet box to install

the crossbar mounting bracket.

Step 8. To hang the fan body in the mounting

bracket, hold the fan body firmly and insert

the ball into the bracket opening. Check that

no wires were pinched. Rotate the fan body

until the slot in the nylon ball fits into the

pin opposite the bracket opening.

CEILING FIXTURE OUTLET BOX
