FujiFilm YF4A-SA2B Specifications

YF4A-SA2B
Focal Length (mm)
Iris Range
Focus
Operation
Iris
1/3"
Angle Of View
(H×V)
1/4"
Focusing Range (From Front Of The Lens)(m)
Object Dimensions
1/3"
at M.O.D.
1/4"
(H×V)(mm)
Back Focal Distance (in air) (mm)
Exit Pupil Position (From Image Plane) (mm)
Filter Thread (mm)
Mount
Mass (g)
Coil Resistance
Current Consumption
Remarks
* Each of the above products is also available in manual type.
YF4A-SA2B
4
F1.2 - T360(Equivalent to F360)
Manual
Auto(DC Type)*
65°21' × 49°27'
49°27' × 37°15'
- 0.1
132 × 99
99 × 73
8.62
727
–
CS
40
Drive Coil
Damping Coil
22mA(Max.) at DC 4V
(*1) The iris automatically closes when the
camera is turned off.
YF4A-SA2LB:Long Cable Type(230mm)
Fixed Focal
Applicable camera 1 2/3 1/2
(model)
Fixed Focal DC Auto Iris CS Mount ND Filter
24
Wiring
1
200
600
1/3 1/4
For Security
Large RoHS
Long Cable Aperture Ratio Compliant
35 at
1:1.*/***mm
YF***A-SA2
FUJINON CORPORATION
JAPAN
IRIS CONTROL CABLE
(CONNECTOR : 4-PIN PLUG)
36 at
WHITE
Open 3
BLACK
4
RED
2
Toward
Damping
Open
BLUE
1
Connector
4-PIN PLUG
(4mm)
100 +30
0
Unit : mm
Lens
Drive
Coil
Coil
