Extron electronics CTL120-3 Instructions

CTL120-3 Remote Control
This IR remote (Extron part #70-371-01) is to be used with the
SWP123 Presentation Switcher.
Switching input devices
To switch to a new input group and input device using the CTL120-3

remote control:

1. Press and release the SWP SWITCHER button.
2. Press and release the numeric button (1, 2, 3, or 4) on the remote control
unit that corresponds to the desired input group (VGA, S-video, Video,
or Audio, respectively).
3. Press and release the numeric button (1, 2, 3, or 4) on the remote control
unit that corresponds to the desired input device within the selected
group that you want to connect to the output.
4. Press and release the ENT (ENTER) button to execute the switch.
