Extron electronics MLS 100 A User Manual page 25

Specifications, Part Numbers, Accessories, cont'd
Connectors
MLS 100 A, MLS 103 V/SV (5) 3.5 mm captive screw connectors,
MLS 102 VGA ................... 2 mini stereo jacks (female tip-ring-sleeve
Impedance .................................... >10k ohms unbalanced, >20k ohms
Nominal level ............................... -20 dBV (100 mV), -10 dBV (316 mV),
0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV
+4 dBu and 0 dBu are professional audio line level standards.
-10 dBV and -20 dBV are semiprofessional, computer audio, and
consumer audio standards.
Maximum level ............................ +14 dBu, (balanced or unbalanced) at
Input gain adjustment ................. –18 dB to +24 dB, adjustable per input (via
Aux/Mix level adjustment ......... -43 dB to +24 dB (adjustable only via front
Audio output
Number/signal type ................... 1 stereo or mono, balanced/unbalanced
Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±0.1 dB channel to channel
Maximum level (Hi-Z) ................ >+21 dBu, balanced or unbalanced at 1%
Maximum level (600 ohm) ......... >+15 dBm, balanced or unbalanced at 1%
An unbalanced-wired output will result in a 6 dB attenuation.
A balanced-wired output will have unity (0 dB) gain/
attenuation.
Control/remote — switcher
Serial control port ........................ RS-232, 3.5 mm, 5 pole captive screw
Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations A = TX, B = RX, D = GND
MediaLink ™ VersaTools ©
A-4
3 pole
connectors)
(3) 3.5 mm captive screw connectors,
3 pole
balanced, DC coupled
0 dBu (0.775 V), or +4 dBu (1.23 V);
(configurable)
2 dBu
stated %THD+N
RS-232/control software)
panel)
THD+N
THD+N
connector
• Specifications, Part #s, Accessories
Program control ........................... Extron's control/configuration program
General
Power ............................................. Supplied by an optional MediaLink
External power supply (included) 100 VAC to 240 VAC, 50/60 Hz, external,
Power input requirements ......... 12 VDC, 0.4 A
Temperature/humidity .............. Storage: -40 to +158°F (-40 to +70°C) / 10%
Rack mount ................................... Yes, with optional VersaTools
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.7" H x 4.3" W x 3.0" D
Product weight ............................. 0.7 lbs (0.3 kg)
Shipping weight ........................... 3 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
™ ©
MediaLink VersaTools • Specifications, Part #s, Accessories
®
for Windows
Extron's Simple Instruction Set (SIS ™
Controller (MLC) or an external power
supply
autoswitchable; to 12 VDC, 1 A (max.),
regulated
to 90%, noncondensing
Operating: +32 to +122°F (0 to +50°C) /
10% to 90%, noncondensing
®
rack shelf,
part #60-190-20; or standard 1U rack shelf,
#60-190-01
Furniture mountable with optional mini
under-desk brackets, part #70-212-01
Projector mountable with optional
bracket, part #70-217-01
(1U high, quarter rack wide)
4.2 cm H x 11.0 cm W x 7.6 cm D
(Depth excludes connectors and buttons.)
Transit Association)
)
A-5
