Shure SM80-LC Specifications

THE SOUND OF THE PROFESSIONALS@
The Shure Model SM80 is a high-quality, omnidirec-
tional condenser microphone designed for the most
demanding professional applications in studio record-
ing, broadcasting and sound reinforcement. It is
especially suitable for applications requiring extremely
wide frequency response, low noise and distortion
characteristics, very low RF susceptibility, and reliable
operation over a wide range of temperature and humid-
ity extremes. The SM80 features a selectable 10 dB
attenuator and a three-position low-frequency response
switch. The case is constructed of steel for ruggedness,
with a stainless steel screen, and finished in durable
vinyl paint.
The SM80 is designed for phantom (simplex) power-
ing from an external supply such as the Shure Model
PS1A, or directly from recording, broadcast or sound
reinforcement equipment. The SM80 operates over a
wide voltage range covering both DIN Standard 45 596
phantom voltages of 12 and 48 volts.
The microphone is supplied with a highly efficient
pop filter grille (Model A81G), attenuator lock, and
swivel adapter. Also available for use with the SM80 are
a unidirectional microphone cartridge (Model R104), a
heavy-duty windscreen (Model A81WS), and a compact,
lightweight microphone stand (Model S15) capable of
being extended to 4.3m (14 ft). A dual-channel power
supply (Model PS1A) is available for providing phantom
power to the SM80.
Wide-range frequency response for exceptionally
n
accurate recording and sound reinforcement appli-
cations
Low noise and high output clipping level char-
n
acteristics
Low distortion characteristics over the entire audio
n
spectrum for a wide range of load impedances
Omnidirectional polar pattern is equally sensitive to
n
sounds from all directions
Very low RF susceptibility
n
Selectable low-frequency response: flat, 6 or 18
n
dB/octave rolloff
10 dB attenuator accessible without disassembly;
n
lockable in either position
Wide-range phantom powering includes DIN 45 596
n
voltages of 12 and 48 Vdc
Rugged construction for outstanding reliability
n
Field-usable over wide range of temperature and
n
humidity conditions
Model SM80-LC: Supplied less cable.
Copyright 1986, Shure Brothers Incorporated
27A1743(FF)
PROFESSIONAL PRODUCTS
GENERAL
VARIATIONS
SPECIFICATIONS
Type
Omnidirectional condenser (electret bias)
Frequency Response
20 to 20,000 Hz (see Figure 1)
TYPICAL FREQUENCY RESPONSE
FIGURE 1
Polar Pattern
Omnidirectional (see Figure 2)
TYPICAL POLAR PATTERNS
FIGURE 2
Printed in U.S.A.
Patent Pending
