NOTE:
The eSpark must be traveling up to 3mph before motor will engage. Kick start
up to 3mph while twisting the throttle to engage motor.
Owner's Manual
Read and understand this entire manual before riding!
DO NOT RETURN TO STORE!
NOTE: Manual illustrations are for demonstration purposes only. Illustrations
may not reflect exact appearance of actual product. Specifications subject to
change without notice.
Item Number:
v.1_07-11_US
13111290

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Espark 13111290 and is the answer not in the manual?

Questions and answers

Related Manuals for Razor Espark 13111290

Summary of Contents for Razor Espark 13111290

  • Page 1 ™ NOTE: The eSpark must be traveling up to 3mph before motor will engage. Kick start up to 3mph while twisting the throttle to engage motor. Owner’s Manual Read and understand this entire manual before riding! DO NOT RETURN TO STORE! NOTE: Manual illustrations are for demonstration purposes only.

  • Page 2: Table Of Contents

    Do not ride at night or when visibility is limited. riders are able to safely and responsibly use this product. Razor recommends Observe all other eSpark safety warnings and instructions as provided that you periodically review and reinforce the information in this manual elsewhere in this manual.

  • Page 3: Safety Warnings

    (lace-up shoes with rubber soles), never ride barefooted or in sandals, and local laws and regulations to see where and how you may use your Razor keep shoelaces tied and out of the way of the wheels, motor and drive scooter legally.

  • Page 4: Before You Begin

    (Not Included) with pressure gauge (Not included) Need Help? Visit our web site for replacement parts, product support and a list of authorized service centers at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time.

  • Page 5: Assembly And Set-Up

    aSSEMBLy aND SET-UP q attaching the Handlebars Note: Make sure the cables/ wires are out of the way before inserting the stem into the fork. Open the quick release. Depress the push button (a) Adjust the tension of the located on the front fork and in- quick release to where you can sert the handlebar stem until the close the lever all the way to...

  • Page 6: Connectors/Hardware Maintenance

    aSSEMBLy aND SET-UP q Installing Spark Bar Using two (2) 5mm Allen Re-insert the coupling bolt wrenches remove the coupling through the metal bar and bolt that is attached to the end tighten until Spark Bar is locked of the metal bar of the Spark securely in place.

  • Page 7: Repair And Maintenance

    9-2 - Lock washer 9-1 - 17mm locknut Need Help? Visit our web site for replacement parts, product support and a list of authorized service centers at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time.
  • Page 8 REPaIR aND MaINTENaNCE q Chain and Rear Wheel Replacement Note: Rear wheel hardware Tools required: Phillips screwdriver, 10mm open wrench, two (2) 8mm open wrenches, and two (2) 13mm sequence open wrenches. 18-1 18-2 18-4 18-3 18-6 18-7 18-8 18-5 18-4 18-3 18-2...

  • Page 9: Repair And Maintenance

    CONTAINS SEALED LEAD ACID BATTERIES. BATTERIES MUST BE RECYCLED. Disposal: Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in an environmentally safe manner. Do not dispose of a lead-acid battery in a fire. The battery may explode or leak. Do not dispose of a lead-acid battery in your regular household trash.

  • Page 10: Troubleshooting Guide

    Even with proper care, a rechargeable battery does not last forever. full charge Average battery life is 1 to 2 years depending on scooter use and conditions. Replace only with a Razor replacement battery. Brakes are not adjusted Refer to adjusting the brakes instructions on page 6.

  • Page 11: Troubleshooting Guide

    Loose wires or connectors doesn’t run, but other they are tight. times it does Motor or electrical switch Contact your local Razor authorized service center for diagnosis and repair. damage Scooter makes loud Chain is too dry Apply a lubricant such as 3 in 1 or Tri-Flow to the chain.
  • Page 12 PaRTS Keep your scooter running for years with genuine Razor parts. Visit our website for more information on spare part availability. (Specifications subject to change without notice.) Charger Port Handlebar grip (right/left) Reset Button Single speed twist grip throttle Kickstand...
  • Page 13 SB 1918 (CALIFORNIA) DECLARATION YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER/ELECTRIC RIDE-ON PRODUCT. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.

  • Page 14: Warranty

    PO Box 3610 Cerritos, CA 90703 Copyright © 2003-2011 Razor USA LLC. All rights reserved. RAZOR and the Razor Logo Design are among the registered trademarks of Razor USA LLC in the United States and/or select foreign coun- tries. eSpark is trademark of Razor USA.
