  • Page 1 STYLUS...
  • Page 2 The latest/current version of this manual is available on our website. Copyright © 2010 Pride Mobility Products Corp. INFMANU2121/Rev G/November 2010...

  • Page 3: Table Of Contents

    C O N T E N T S INTRODUCTION ..........................4 SAFETY ............................... 5 III. YOUR WHEELCHAIR ........................13 IV. COMFORT ADJUSTMENTS ..................... 16 CARE AND MAINTENANCE ..................... 23 VI. WARRANTY ............................. 27 APPENDIX I - SPECIFICATIONS ....................28 Stylus www.pridemobility.com...

  • Page 4: Introduction

    I . I N T R O D U C T I O N SAFETY WELCOME to Pride Mobility Products (Pride). The wheelchair you have purchased combines state-of-the-art components with safety, comfort, and styling in mind. We are confident that these design features will provide you with the conveniences you expect during your daily activities.
  • Page 5 Pride product and its packaging. Anti-tip wheels must be used to ensure stability when using an an oxygen tank holder. Ensure the ball detents on the quick-release axles snap into place and are fully visable after drive wheel installation. Stylus www.pridemobility.com...

  • Page 6: Ii. Safety

    Check for proper tire inflation. Maintain but do not exceed the psi/bar/kPa air pressure rating indicated on each tire if equipped with pneumatic tires. Check the brakes. See V. “Care and Maintenance.” NOTE: If you discover a problem, contact your authorized Pride Provider for assistance. www.pridemobility.com Stylus...

  • Page 7: Weight Limitations

    Drive your wheelchair straight up the incline. This greatly reduces the possibility of a tip or a fall. Always exercise extreme caution when negotiating an incline. WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered with snow, ice, cut grass, or wet leaves). Stylus www.pridemobility.com...
  • Page 8 WARNING! You should not operate your wheelchair on public streets and roadways. Be aware that it may be difficult for traffic to see you when you are seated on your wheelchair. Obey all local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme caution. www.pridemobility.com Stylus...
  • Page 9 2 in. (5 cm) unless you have the assistance of an attendant. WARNING! Do not attempt to have your wheelchair proceed backward down any step, curb, or other obstacle. This may cause the wheelchair to tip. Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach Stylus www.pridemobility.com...

  • Page 10: Stairs And Escalators

    WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is your wheelchair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be properly belted into seats approved by the vehicle manufacturer. www.pridemobility.com Stylus...
  • Page 11 WARNING! Avoid putting all of your weight on the manual wheel locks and do not use the manual wheel locks for weight bearing purposes, such as transfers. Such use may cause equipment damage or personal injury. WARNING! Avoid putting all of your weight on the front riggings. Such use may cause the wheelchair to tip. Stylus www.pridemobility.com...
  • Page 12 You must adhere to the following safety guidelines if you decide to smoke cigarettes while seated in your wheelchair. Do not leave lit cigarettes unattended. Keep ashtrays a safe distance from the seat cushions. Always make sure cigarettes are completely extinguished before disposal. www.pridemobility.com Stylus...
  • Page 13 I I I . Y O U R W H E E L C H A I R THE STYLUS The Stylus is a rear-wheel drive wheelchair designed to operate both indoors and outdoors on smooth surfaces. BACK CANE HANDLES...

  • Page 14: Iii. Your Wheelchair

    I I I . Y O U R W H E E L C H A I R USING THE STYLUS PUSH TO ENGAGE The Stylus is a manual wheelchair. Either an attendant pushes it, or you move it by gripping the handrims (see figure 5) and turning them in the desired direction of travel.
  • Page 15 I I I . Y O U R W H E E L C H A I R Transporting Your Stylus BACK CANE HANDLES The Stylus was designed to be folded and stored in a secure location, such as the trunk of a car, during motor vehicle transport.

  • Page 16: Comfort Adjustments

    Your authorized Pride Provider has evaluated your wheelchair and made any necessary adjustments to suit your specific requirements. Do not change your seating configuration without first contacting Pride Mobility Products or your authorized Pride Provider.

  • Page 17: Iv. Comfort Adjustments

    19.5 in. 6 in. or 8 in. adjusted to the same position. (49.53 cm) (15.24 or 20.32 cm) WARNING! Ensure the quick-release axles are properly secured. 20 in. 8 in. (50.8 cm) (20.32 cm) Figure 14. Seat-to-Floor Height Matrix Stylus www.pridemobility.com...
  • Page 18 NOTE: You may need to tap the bolt head to release the wedge clamp. 2. Adjust the ELR to the desired length. 3. Tighten the bolt head. 4. Repeat the procedure for the other side. BOLT HEAD Figure 17. ELR Length Adjustment www.pridemobility.com Stylus...
  • Page 19 2. Slide the back canes up or down to the desired height. 3. Reinstall the bolts to refasten the back canes to the frame. Figure 19. ELR Calf Pad Position Adjustment BACK CANES BOLT BOLT FRAME Figure 20. Seatback Height Adjustment Stylus www.pridemobility.com...

  • Page 20: Armrest Height Adjustment

    2. Move the armrest up or down to the desired position. 3. Release the pin. Figure 22. Flip-back Armrests 4. Make sure the armrest locks into place. 5. Repeat for the other side if necessary. RELEASE PIN Figure 23. Armrest Height Adjustment www.pridemobility.com Stylus...
  • Page 21 Figure 24. Caster Wheel Position 4. Repeat the procedure for the other side, making sure both caster wheels are adjusted to the same position. WARNING! Changing the seat angle may adversely affect stability and cause the wheelchair to tip over. Stylus www.pridemobility.com...
  • Page 22 Top Bolt Bottom Bolt Caster Position Position Position Wheel Angle Fore 95° Fore Fore 90° Fore 85° Figure 25. Caster Angles BOLT SHAFT BOLT HEAD FORE POSITION 1. POSITION 2. POSITION 3. TOP BOLT BOTTOM BOLT Figure 26. Caster Angle Adjustment www.pridemobility.com Stylus...

  • Page 23: Care And Maintenance

    V . C A R E A N D M A I N T E N A N C E CARE AND MAINTENANCE Your Stylus requires routine maintenance checks. You can perform some of these checks, but others require assis- tance from your authorized Pride Provider. Preventive maintenance is very important. If you follow the mainte- nance checks in this section as scheduled, you can help ensure that your wheelchair gives you years of trouble-free operation.

  • Page 24: V. Care And Maintenance

    WARNING! Never hose off your wheelchair or place it in direct contact with water. Your wheelchair has a painted finish that allows it to be easily wiped clean with a damp cloth. www.pridemobility.com Stylus...
  • Page 25 5. Engage the wheel lock and note the position of the blade. WHEEL LOCK 6. Reposition the wheel lock if necessary. BLADE 7. Repeat the procedure for the other side. TIRE Figure 27. Manual Wheel Lock Adjustment Stylus www.pridemobility.com...
  • Page 26 The following symptoms could indicate a serious prob- lem with your wheelchair. If necessary, contact your authorized Pride Provider. When calling, have the model number, serial number, and nature of the problem. Uneven wear on any of the tires Bent or broken wheel assemblies www.pridemobility.com Stylus...

  • Page 27: Warranty

    Pride’s authorized personnel shall modify, adjust, or repair such product or perform any related service on it. It must be understood that the purchaser assumes full responsibility for the overall safe operation in the environ- ment for which the product is intended to function. Stylus www.pridemobility.com...

  • Page 28: Appendix I - Specifications

    Due to manufacturing tolerances and continued product improvement, this specification can be subject to a variance of (+ or – ) 3%. Test results for Stylus equipped with push-to-lock wheel locks in accordance with ANSI-RESNA WC Vol. 2 Section 03. Maximum operating force for hand operated wheel locks is 60N (+ or –...
  • Page 29 23 in. (58.42 cm) with 18 x 18 in. seat 21.75 in. (55.25 cm) with 20 x 16 in. seat 28.5 in. (72.39 cm) with 20 in. seat 23.5 in. (59.69 cm) with 20 x 18 in. seat Figure 29. Stylus Specifications Stylus www.pridemobility.com...
  • Page 30 N O T E S www.pridemobility.com Stylus...
  • Page 32 Quality Control - Stylus Inclusion of all Parts Fit and Finish Performance Pride keeps a more detailed report on file at the factory. Date Inspected Inspector *INFMANU2121* Product Serial #...
