MITX-430/MITX-440-DVI-2E
Installation and Use Guide
P/N: 6806800K37B
August 2010
Embedded Computing for
Business-Critical Continuity
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MITX-430 and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson MITX-430

Summary of Contents for Emerson MITX-430

  • Page 1 Embedded Computing for Business-Critical Continuity MITX-430/MITX-440-DVI-2E Installation and Use Guide P/N: 6806800K37B August 2010...

  • Page 2: Contact Address

    Emerson reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Emerson to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    1.1.1 MITX-430 ........
  • Page 4 4.12.1 User Defined GPIO ............63 MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 5 ASL Status Codes ..........102 MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 6 Related Documentation ............. . 107 Emerson Embedded Communications Computing Documents ......107 Related Specifications .
  • Page 7 Advanced Menu ............75 MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 8 Supported Drivers ............105 MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 9 List of Tables Table A-1 Emerson Network Power - Embedded Computing Publications ....107 Table A-2 Related Specifications ............107...
  • Page 10 List of Tables MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 11: List Of Figures

    USB Ports Connection ........... 62 MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 12 List of Figures MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 13: About This Manual

    This document uses the following abbreviations: Abbreviation Definition ACPI Advanced Configuration and Power Interface AHCI Advanced Host Controller Interface American Megatrends Inc Active Management Technology Application Processor APIC Advanced Programmable Interrupt Controller ACPI Source Language MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 14 Dynamic Video Memory Technology Driver Execution Environment Error Checking and Correcting Extended Capabilities Parallel Port Extensible Firmware Interface EHCI Enhanced Host Controller Interface Electromagnetic Magnetic Compatibility Emergency Management Services Enhanced Parallel Port Electro-Static Discharge MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 15 Original Equipment Manufacturer PATA Parallel AT Attachment Printed Circuit Board Peripheral Component Interface PCIE Peripheral Component Interface Express PCI Express Graphics Pre-EFI Initialization Programmable Interrupt Controller Programmed Input Output POST Power on Self Test PEIM-to-PEIM Interface MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 16 Standard Parallel Port TACH Tachometer Thermal Dissipation Power Trusted Platform Module Transmit X data UEFI Unified Extensible Firmware Interface UHCI Universal Host Controller Interface VBIOS Video BIOS Voltage Current Circuit VCORE Core Voltage Video Graphics Adapter MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 17 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 18: Comments And Suggestions

    Updated the manual with new marketing numbers MITX- 430/MITX-440-DVI-2E. Comments and Suggestions We welcome and appreciate your comments on our documentation. We want to know what you think about our manuals and how we can make them better. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 19 > Contact Us > Online Form In "Area of Interest" select "Technical Documentation". Be sure to include the title, part number, and revision of the manual and tell us how you used it. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 20 About this Manual About this Manual MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 21: Introduction

    American Megatrends Inc ( between the low-level hardware interfaces and the OS level in an efficient manner that provides superior reliability. The following sections describe some of the key features of MITX-430 single core and MITX- 440-DVI-2E dual core processors. 1.1.1...
  • Page 22 Supports one TPM connector (2x10, 2.54mm Pin header) Module Power management ACPI1.0b compatible Supports ATX power supply COM Port Supports 6 COM ports (two to DSUB-9 in rear I/O region, one RS-232/422/485 port, two Power COM, and one to 2x5Pin header) MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 23: Mitx-440-Dvi-2E

    Supports one DVI (derived from LVDS) Chipset Intel ICH8-M System BIOS feature One piece 4MB SPI boot device Super I/O W83627UHG-LF Integrated in ICH8-M Audio Audio on board (ALC888-GR-LF) Rear: Line-in, Line out, MIC-in MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 24 RS-232/422/485 port, two power COM, and one to 2x5Pin header) LPT Port Supports one parallel port (2x13Pin Header) Front panel 2x5Pin Header, supports power button, reset button, power LED, HDD LED, and standby LED GPIO Supports 4 GPI and 4 GPO MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 25: Standard Compliances

    Equipment. AS/NZS CISPR 22 Class B (Australia/New Limits and methods of measurement of radio Zealand) disturbance characteristics of Information Technology Equipment. VCCI Class B (Japan) Voluntary Control Council for Interference by Information Technology Equipment. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 26: Figure 1-1 Declaration Of Conformity

    Introduction Figure 1-1 Declaration of Conformity MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 27: Mechanical Data

    The following accessories are shipped with the board: Table 1-6 Available Board Accessories Order Number Description MITX-430 Two COM cables, one SATA power cable, one SATA data cable MITX-440-DVI-2E Two COM cables, one SATA power cable, one SATA data cable MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 28: Product Identification

    MITX-430 One IO shield MITX-440-DVI-2E One IO shield Product Identification The following graphic shows the location of the serial number label on the board. Figure 1-2 Single Core Processor Board - Serial Number Location MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 29: Figure 1-3 Dual Core Processor Board -Serial Number Location

    Introduction Figure 1-3 Dual Core Processor Board -Serial Number Location MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 30 Introduction MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 31: Hardware Preparation And Installation

    Table 2-1 Environmental Requirements Requirement Operating Non-operating Temperature C to 55 C with CPU cooler C to 85 Humidity 10% to 90% non-condensing 5% to 95% non condensing Vibration 0.01g^2/Hz at 5-500Hz random vibration MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 32: Thermal Requirements

    Make sure that the fresh air supply is not mixed with hot exhaust from other devices. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 33: Power Requirements (Single Core Processor Board)

    One 3.5" SATA HDD One SATA CD-ROM One USB keyboard One USB mouse One PS/2 keyboard One PS/2 mouse 2.1.3.1 Full Loading Running Burn-in Test VGA display only 3.3V Total Current(A) 0.30 Power(W) 0.99 13.59 MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 34: Idle Mode Power Consumption

    If you use all the devices and power internally, then you must add all the power consumption. It is recommended to add more buffer while designing the ATX power supply. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 35: Standby Mode Power Consumption

    The power consumption is tested under the following conditions with: 2*2G SO-DIMM One 2.5” ATA HDD One infonion TPM module One USB keyboard One USB mouse One PS/2 keyboard One PS/2 mouse One 3.5” SATA HDD One 3.5” SATA CD-ROM MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 36: Full Loading Running Burn-In Test

    If you use all the devices and power internally, then you must add all the power consumption. It is recommended to add more buffer while designing the ATX power supply. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 37: Standby Mode Power Consumption

    0.65 Source Board Thermal Management and Placement 2.2.1 Board Thermal Management The motherboard provides some thermal management strategy, including CPU junction temperature monitor. It can take corresponding action to protect system at catastrophic overheating. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 38: Figure 2-1 Board Thermal Management

    MSR of CPU. When the CPU junction temperature is more than 125C, CPU asserts the THERMTRIP# signal, and then stops all bus activities, and the core power must be shut down in the specified time. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 39: Unpacking And Inspecting The Board

    1. Verify that you have received all items of your shipment: Quick Start Guide and Safety Notes summary Motherboard Two COM cables One SATA power cable One SATA data cable Driver CD I/O Shield MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 40: Preparing The Installation Environment

    The spare parts of the components to be installed or replaced are available in the equipment warehouse. When the available spare parts are lacking, contact Emerson Network Power. For details on how to get help from Emerson Network Power, visit http://www.emersonnetworkpower.com/embeddedcomputing.

  • Page 41: Processor Cooler Installation And Removal

    Prepare the cross screwdriver, screws, plastic supports, cooling gel, and ESD-preventive wrist strap. Confirm installation or changing position Confirm the position where the MITX-430/MITX-440-DVI-2E will be installed. Others If a serious problem occurs and cannot be solved when you install or replace the component, contact Emerson Network Power for technical support.

  • Page 42: Memory Module Installation And Removal

    Installing Memory Module 1. Wear the ESD-preventive wrist strap. 2. Lay the MITX-430/MITX-440-DVI-2E, where the SO-DIMM is to be installed on the antistatic desktop. 3. Take the SO-DIMM out of the antistatic package, holding it by the edges.
  • Page 43 Incorrect installation or removal of additional devices or modules damages the product or the additional devices or modules. Before installing or removing additional devices or modules, read the respective documentation and use appropriate tools. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 44 Hardware Preparation and Installation MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 45: Controls, Leds, And Connectors

    Chapter 3 Controls, LEDs, and Connectors Board Layout Figure 3-1shows the location of the major components on the motherboard. Figure 3-1 Single Core Motherboard Components BIOS socket (far side) MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 46: Figure 3-2 Dual Core Motherboard Components

    Controls, LEDs, and Connectors Figure 3-2 Dual Core Motherboard Components BIOS socket (far side) MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 47: Connectors

    Table 3-1 Clear CMOS Header Mode 1-2 short Clear CMOS 3.2.2 LVDS Header (J5) Table 3-2 LVDS Header Pin Definition PIN Name PIN Name VCC_LVDS VCC_LVDS LVDS_A_A0_P LVDS_A_CLK_P LVDS_A_A0_N LVDS_A_CLK_N LVDS_A_A1_P LDDC_CLK LVDS_A_A1_N LDDC_DATA LVDS_A_A2_P LVDS_A_A2_N MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 48: Lvds Backlight Header (P23)

    Table 3-4 LVDS Power HEADER MODE 1-2 short 3.3V (default) 2-3 short 3.2.5 MINI IDE Header (J8) Table 3-5 MINI IDE Header PIN Definition PIN Name PIN Name IDE_RST_R_N IDE_D7 IDE_D8 IDE_D6 IDE_D9 IDE_D5 IDE_D10 MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 49: Usb Flash Header (P10)

    IDE_SEL IDE_ACK_N IDE_IRQ IDE_A1 IDE_DET IDE_A0 IDE_A2 IDE_CS1_N IDE_CS3_N IDE_ACT_N VCC5V VCC5V 3.2.6 USB Flash Header (P10) Table 3-6 USB Flash Header Pin Definition PIN Name PIN Name VCC5V VCC5V USB0_N USB1_N USB0_P USB1_P MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 50: Usb Header (P12)

    Table 3-7 USB Header Pin Definition PIN Name PIN Name VCC5V VCC5V USB0_N USB1_N USB0_P USB1_P 3.2.8 ELO Touch Screen Header (P6) Table 3-8 ELO Touch Screen Header Pin Definition PIN Name PIN Name VCC5V VCC5V USB_N USB_P MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 51: Gpio Header (P4)

    GPO2 GPI2 GPO3 GPI3 VCC5DUAL 3.2.10 COM Header (P9, P27) Table 3-10 COM3, COM6 Header Pin Definition PIN Name PIN Name RING 3.2.11 RS-232/422/485 (P18) Table 3-11 RS-232/422/485 Header Pin Definition PIN Name RS422TX_N MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 52: Power Com (P8, P26)

    Table 3-13 COM4, COM5 Header Pin Definition PIN Name PIN Name Pin9 Select Table 3-14 COM4, COM5 Pin9 Selection PIN Name P19 1-2 short COM4 Pin9 is Ring P19 2-3 short COM4 Pin9 is 5V P20 1-2 short MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 53: Tpm Header (P2)

    COM5 Pin9 is 12V P22 2-3 short 3.2.13 TPM Header (P2) Table 3-15 TPM Header Pin Definition PIN Name PIN Name PCI_CLK LPC_FRAME TPM_RST# VCC5V LPC_AD3 LPC_AD2 VCC3V3 LPC_AD1 LPC_AD0 SMB_CLK SMB_DAT VCC3V3DUAL LPC_SERIRQ# CLKRUN# TPM_LPC_PD# TPM_LDRQ# MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 54: Lpt Header (P11)

    PIN Name PIN Name STB# ACK# BUSY# SLCT# AFD# ERR# INIT# SLIN# 3.2.15 Front Panel Header (P15) Table 3-17 Front Panel Header Pin Definition PIN Name PIN Name HDD_LED_PWR PWR_LED HDD_LED_N POWER BUTTON# SYSTEM RST# MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 55: Bios Program Header (P16)

    3.2.16 BIOS Program Header (P16) Table 3-18 BIOS Program Header Pin Definition PIN Name PIN Name VCC3V3DUAL SPI_CS0# SPI_CLK SPI_MISO SPI_MOSI 3.2.17 Fan Header (P1, P13) Table 3-19 Smart Fan Header Pin Definition PIN Name VCC12V TACH MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 56: Mini Pcie Led (P14)

    3.2.18 MINI PCIE LED (P14) Table 3-20 MINI PCIE Wireless LAN LED Header Pin Definition PIN Name VCC3V3 WWAN_LED# WLAN_LED# 3.2.19 Case Open Header (P25) Table 3-21 Case Open Header Pin Definition PIN Name Case_open# MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 57: Functional Description

    AMI Aptio EFI FW Pwr/Rst/LED Pwr/Rst/ LED Header Header PS2 KB PS/2 PS2 MS PS 3V SuperIO/ PS 5V Voltage Mon. PS 12V Printer W83627 (opt.) 4xUART 2xUART 2x RS-232 4x RS-232 COM Port Headers MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 58: Pineview-D Processor

    Functional Description Pineview-D Processor The MITX-430/MITX-440-DVI-2E is designed to support the Pineview-D processor. The processor features are as follows: Single chip integrated processor, memory controller, graphic controller with small size of 22mm x 22mm. Manufactured on 45nm process. 2 x 512KB L2 cache for D510 dual-core processor, 1 x 512KB L2 cache for D410 single-core processor, 32KB instruction cache, and 24KB data cache.

  • Page 59: Figure 4-2 Board I2C Device Connection

    Functional Description EMC2103-2-AP CPU thermal sensor 9LPR501SGLFT CLK GEN Memory slot XDP header Figure 4-2 shows the SMBus device connection diagram. Figure 4-2 Board I2C Device Connection MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 60: System Memory

    System Memory The Pineview-D integrates a single channel 64bit non ECC DDR2 controller. There are two 200pin SO-DIMM slots on MITX-430/MITX-440-DVI-2E, and supports up to 4GB (assuming 2Gb density device technology) DDR2 memory at data transfer rate of 667MT/s. Ethernet Interfaces The MITX-430/MITX-440-DVI-2E provides two 10/100/1000 Ethernet, WG82567V and WG82574L.

  • Page 61: Usb Interface

    The ICH8-M supports 10 USB2.0 interface using UHCI or EHCI. Four USB ports are routed to USB+RJ45 connectors. Two USB ports are routed to USB headers, two for USB flash disk, and one for ELO Touch Screen Module. One is routed to Mini PCIE slot. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 62: Vga, Lvds, Lpc, And Audio Interface

    1366 x 768. The LPC is routed to super IO and TPM connector. ICH8-M supports a high definition audio interface and ALC888GR is used as the audio codec. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 63: Dvi Interface

    A 4MB SPI Flash is used as BIOS device. 4.11 IDE The MITX-430/MITX-440-DVI-2E supports a 44pin Mini-IDE header on board. The IDE interface supports up to two IDE devices providing an interface for IDE hard disks and ATAPI devices. Each IDE device has independent timings. The IDE interface supports PIO IDE transfers up to 16 MB/sec and Ultra ATA transfers up to 100 MB/sec.

  • Page 64: 4.12.2 Ich8-M Gpio

    (WP) signal, PU VCC3V3DUAL GPIO9 3.3V Resume Multiplexed with Unused, PU VCC3V3DUAL WOL_EN GPIO10 3.3V Resume Multiplexed with Unused, PU VCC3V3DUAL SusPwrAck/ALERT# GPIO11 3.3V Resume Native Multiplexed with Used for SMBus alert SMBALERT# signal, PU VCC3V3DUAL MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 65 Core Multiplexed with Unused, PD GND SATA0GP. GPIO22 3.3V Core Multiplexed with Unused, PU VCC3V3 SCLOCK GPIO23 3.3V Core Native Multiplexed with By default unused, LDRQ1# optionally used as LPC_DRQ1#, connecting to TPM connector MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 66 Multiplexed with Unused, low active HDA_DOCK_EN# GPIO34 3.3V Core Multiplexed with Used as LVDS/DVI display selection HDA_DOCK_RST# 1 = DVI; 0 = LVDS GPIO35 3.3V Core Multiplexed with Used as SATA clock SATACLKREQ# request MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 67 Unused, PU VCC3V3 SDATAOUT1 GPIO49 V_CPU_IO V_CPU_ Native Multiplexed with Used as CPUPWRGD CPUPWRGD GPIO50 5.5V Core Native Multiplexed with Unused, PU VCC3V3 REQ1# GPIO51 3.3V Core Native Multiplexed with Unused, connect to TP GNT1# MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 68: 4.13 Chipset

    Used as a strap pin GNT3# 4.13 Chipset The MITX-430/MITX-440-DVI-2E is designed to use the Intel ICH8M I/O Hub. The ICH8 provides extensive I/O support. Functions and capabilities are as follows: PCI Express Base Specification, supports Revision 1.1. PCI Local Bus Specification, supports Revision 2.3 for 33 MHz PCI operations.

  • Page 69: 4.14 Clock Generator

    Functional Description 4.14 Clock Generator The MITX-430/MITX-440-DVI-2E contains a CK505 clock generator (ICS9LPR501) to provide the clocks for various components. 4.15 Video The graphic core is integrated in Pineview-D processor. The GPU contains a refresh of 3rd generation graphics core, and improved GFX engine. The GPU is a unified graphics driver which does end to end decode.

  • Page 70: 4.17 Super I/O

    W83627 hardware monitor to monitor the system temperature. Fan monitor and control MITX-430/MITX-440-DVI-2E supports CPU fan and system fan speed control. 4.19 SPI Flash MITX-430/MITX-440-DVI-2E uses onboard 4MB SPI flash part to store the firmware including the BIOS and GBE. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 71: 4.20 Watchdog Timer

    I/O, and serial data out. SPI clock frequencies of up to 33MHz are supported. 4.20 Watchdog Timer MITX-430/MITX-440-DVI-2E implements the watchdog timer feature. The SIO chipset is used to implement the watchdog function that supports 1-255s or 1-255m watchdog. 4.21 Debug MITX-430/MITX-440-DVI-2E implements three ways for debugging: VGA for text and graphic information output.
  • Page 72 The RTC also supports a data alarm that allows for scheduling a wakeup event up to 30 days in advance, rather than just 24 hours in advance. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 73: Operation

    If you exit setup without saving any changes, the boot process continues with the search for a boot device. If changes are made, the motherboard loads the new settings and resets, restarting the entire boot process. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 74: Setup Utility

    Save & Exit Save with or without changes, load or save default settings, and Boot Device Selection. 5.4.1 Main Menu Table 5-2 Main Menu Field Description BIOS Vendor BIOS vendor name. Core Version Aptio core version. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 75: Advanced Menu

    Enter SATA device options settings, see Table 5-9 on page IGD- LCD Control Internal Graphics Device (IGD)-LCD control function, see Table 5-10 on page USB Configuration USB configuration parameters, see Table 5-11 on page MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 76: Table 5-5 Acpi Settings

    When the field is disabled in BIOS, OS does not show TPM function. TPM State Turn TPM On or Off. Default state is Disabled. Pending TPM operation Schedule TPM operation, default option is none. Current TPM Status Information MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 77: Table 5-7 S5 Rtc Wake Setting

    + Increase minute(s). Default value is Disabled. Wake up minute increase 1-5. Default value is 1. Table 5-8 CPU Configuration Field Description Processor Type EMT64 EMT64 Processor Speed Processor speed System Bus Speed System bus speed MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 78: Table 5-9 Ide Configuration

    Port status SATA Port 0 Port status SATA Port 1 Port status SATA Port 2 Port status ATA /IDE Configuration Select ATA or IDE configuration. The configurations are: Disabled Compatible Enhanced Default value is Enhanced. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 79: Table 5-10 Igd-Lcd Control

    Note that the optional value DVI and CRT+DVI are only for MITX-440-DVI- LCD Panel Type Select LCD panel used by Internal Graphics Device by selecting the appropriate setup item. The LCD panel types are: 800x600 LVDS 1024x768 LVDS Default value is 1024x768 LVDS. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 80: Table 5-11 Usb Configuration

    Default value is 20 sec. Controller Timeout The time out value for control, bulk, and interrupt transfer. The options are: 1sec 5 sec 10 sec 20 sec 30 sec Default value is 20 sec. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 81: Table 5-12 Emc2103 H/W Monitor

    Table 5-20 on page Watchdog Timer Configuration Enable or disable WDT function, see Table 5-21 on page Intrusion Detect Select state for Intrusion Detect. The states are: Disable Enable Clear Default value is Disable. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 82: Table 5-14 Serial Port 1 Configuration

    Enable or disable serial port. Default value is Enabled. Change Settings Select an optimal settings for super IO device. The options are: Auto IO=2F8h; IRQ=3 IO=3F8h; IRQ=3,4,5,6,7,10,11,12 IO=2F8h; IRQ=3,4,5,6,7,10,11,12 IO=3E8h; IRQ=3,4,5,6,7,10,11,12 IO=2E8h; IRQ=3,4,5,6,7,10,11,12 Default value is Auto. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 83: Table 5-16 Serial Port 3 Configuration

    Enable or disable serial port. Default value is Enabled. Change Settings Select an optimal settings for super IO device. The options are: Auto IO=2E8h; IRQ=7 IO=3F8h; IRQ=7,10,11,12 IO=2F8h; IRQ=7,10,11,12 IO=3E8h; IRQ=7,10,11,12 IO=2E8h; IRQ=7,10,11,12 IO=2E0h; IRQ=7,10,11,12 IO=2F0h; IRQ=7,10,11,12 Default value is Auto. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 84: Table 5-18 Serial Port 5 Configuration

    Enable or disable Serial Port. Default value is Enabled. Change Settings Select an optimal settings for Super IO Device. The options are: Auto IO=2F0h; IRQ=10 IO=3F8h; IRQ=7,10,11,12 IO=2F8h; IRQ=7,10,11,12 IO=3E8h; IRQ=7,10,11,12 IO=2E8h; IRQ=7,10,11,12 IO=2E0h; IRQ=7,10,11,12 IO=2F0h; IRQ=7,10,11,12 Default value is Auto. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 85: Table 5-20 Parallel Port Configuration

    Enable or disable WDT. Default value is Disabled. WDT Mode Select watchdog mode, default is Minutes. Time-Out Set time to wait before system reset without PS2 Keyboard or mouse operation. Default value is 5. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 86: Table 5-22 W83627Uhg H/W Monitor

    Enable or disable console redirection. Default value is Disabled. COM2: Console Redirection Table 5-24 on page Settings Serial Port for Out-of-Band Enable or disable console redirection. Default value is Management/Windows Disabled. Emergency Management Services (EMS): Console Redirection MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 87: Table 5-24 Com1 And Com2 Console Redirection Settings

    Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to support color, function keys, and so on. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes. Default value is VT100. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 88 Once the buffers are empty, a start signal is sent to restart the flow. Hardware flow control uses two wires to send start/stop signals. Options are None and Hardware RTS/CTS. Default value is None. Terminal Resolution Remote Terminal Resolution, 80x25 (default). MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 89: Chipset Menu

    HD Audio Controller Enable or disable HD Audio Controller. Default value is Enabled. 82567V LAN Controller Enable or disable WG82567V LAN Controller. Default value is Enabled PCI Express Port 0 Default value is Auto. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 90: Boot Menu

    Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. 0 means no waiting (not recommended). Default value is 3. Bootup NumLock State Select the keyboard NumLock state. Options are On and Off. Default value is On. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 91: Security Menu

    Save changes done so far to any of the setup options. Discard Changes Discard changes done so far to any of the setup options. Restore Defaults Restore or load default values for all the setup options. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 92: Post Codes

    DXE execution up to BDS. 0xD0 - 0xDF DXE errors. 0xE0 - 0xE8 S3 Resume (PEI). 0xE9 - 0xEF S3 Resume errors (PEI). 0xF0 - 0xF8 Recovery (PEI). 0xF9 - 0xFF Recovery errors (PEI). MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 93: Standard Status Codes

    North Bridge initialization after microcode loading. South Bridge initialization after microcode loading. OEM initialization after microcode loading. Cache initialization. SEC Error Codes 0xC - 0xD Reserved for future AMI SEC error codes. Microcode not found. Microcode not loaded. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 94: Pei Status Codes

    OEM pre-memory initialization codes. 0x2B Memory initialization. Serial Presence Detect (SPD) data reading. 0x2C Memory initialization. Memory presence detection. 0x2D Memory initialization. Programming memory timing information. 0x2E Memory initialization. Configuring memory. 0x2F Memory initialization (other). MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 95 PEI Error Codes 0x50 Memory initialization error. Invalid memory type or incompatible memory speed. 0x51 Memory initialization error. SPD reading has failed. 0x52 Memory initialization error. Invalid memory size or memory modules do not match. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 96 S3 OS wake error. 0xEC-0xEF Reserved for future AMI error codes. Recovery Progress Codes 0xF0 Recovery condition triggered by firmware (Auto recovery). 0xF1 Recovery condition triggered by user (Forced recovery). 0xF2 Recovery process started. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 97: Pei Beep Codes

    Memory not Installed. Memory was installed twice (InstallPeiMemory routine in PEI Core called twice). DXEIPL was not found. DXE core firmware volume was not found. Reset PPI is not available. Recovery failed. S3 resume failed. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 98: Dxe Status Codes

    South Bridge DXE initialization (South Bridge module specific). 0x75 South Bridge DXE initialization (South Bridge module specific). 0x76 South Bridge DXE initialization (South Bridge module specific). 0x77 South Bridge DXE initialization (South Bridge module specific). MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 99 Reserved for ASL. See Table 5-38 on page 102. 0xA1 IDE initialization is started. 0xA2 IDE reset. 0xA3 IDE detect. 0xA4 IDE enable. 0xA5 SCSI initialization is started. 0xA6 SCSI reset. 0xA7 SCSI detect. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 100 Some of the Architectural Protocols are not available. 0xD4 PCI resource allocation error. Out of resources. 0xD5 No space for legacy option ROM. 0xD6 No console output devices are found. 0xD7 No console input devices are found. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 101: Dxe Beep Codes

    Reset protocol is not available. 5.5.2.6 CPU Exception Status Codes Table 5-37 CPU Exception Status Codes Status Code Description 0x00 Divide error. 0x01 CPU debug exception. 0x02 Non maskable hardware interrupt occurred. 0x03 INT 3 breakpoint. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 102: Asl Status Codes

    Table 5-38 ASL Status Codes Status Code Description 0x01 System is entering S1 sleep state. 0x02 System is entering S2 sleep state. 0x03 System is entering S3 sleep state. 0x04 System is entering S4 sleep state. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 103: Oem-Reserved Status Code Ranges

    OEM SEC initialization after microcode loading. 0x1D - 0x2A OEM pre-memory initialization codes. 0x3F - 0x4E OEM PEI post memory initialization codes. 0x80 - 0x8F OEM DXE initialization codes. 0xC0 - 0xCF OEM BDS initialization codes. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 104 Operation MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 105: Operating System And Driver Support

    The supported Operating Systems are: Microsoft XP SP3 Microsoft XP Embedded Redhat Fedora Core 11 Supported Drivers Table 6-1 Supported Drivers Drivers WinXP 32bit WinXP 64bit Redhat Fedora Chipset Graphic WG82567V WG82574L Audio Codec MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 106 Operating System and Driver Support MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 107: Related Documentation

    Computing Documents The Emerson Network Power - Embedded Computing publications listed below are referenced in this manual. You can obtain electronic copies of Emerson Network Power - Embedded Computing publications by contacting your local Emerson sales office. For documentation of final released (GA) products, you can also visit the following website: http://www.emersonnetworkpowerembeddedcomputing.com...
  • Page 108 SATA High Speed Serialized AT Attachment Revision 1.0a January 7, 2003. http://www.sata-io.org/ SMBus System Management Bus (SMBus) Specification Version 2.0, August 3, 2000. www.sbs-forum.org Universal Serial Bus Specification Revision 2.0, April 27, 2000. http://www.usb.org/ MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 109: Safety Notes

    Emerson and our suppliers take significant steps to make sure that there are no bent pins on the backplane or connector damage to the boards prior to leaving the factory. Bent pins caused by improper installation or by inserting boards with damaged connectors could void the Emerson warranty for the backplane or boards.
  • Page 110 (EMI) shielding to maintain EMC compliance. Board products are tested in a representative system to show compliance with the above mentioned requirements. A proper installation in a compliant system maintains the required performance. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 111 NEC Table 31016 and other national regulations. The protective bonding conductor depends on your power distribution topology. Make sure that you use an appropriate protective bonding conductor regarding the rating of the branch circuit protection. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 112 The product is supplied by a TNV-2 voltage. This voltage is considered hazardous. Make sure that the external power supply meets the relevant safety standards. Make sure that TNV-2 is separated from dangerous voltages (mains) through double or reinforced insulation. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 113 Product Damage If the system is not installed properly, it may fall down. You must provide your own hardware to secure the chassis. Emerson strongly recommends the use of chassis runners to help support the weight of the chassis. Personal Injury or System Damage Accidental dropping of the system can cause personal injury or system damage.
  • Page 114 If you reduce the blower/fan speed the system temperature rises. Constantly control the system temperature once you have reduced the blower/fan speed. While operating the system make sure the environmental and power requirements are met. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 115 System Damage Air Filters Air contamination can pollute the air filters and obstruct the air intake of the system which causes system overheating and component damage. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 116 To guarantee proper airflow through the system the air filters have to be replaced at least every six months. Emerson recommends to replace the air filters every 90 days. Filter replacement frequency depends on the environment the system is subjected to.
  • Page 117 Setting/resetting the switches during operation can cause damage to the product. Check and change switch settings before you install the product. System Damage Wrong jumper settings can make the shelf inoperable. Never change the settings of the jumpers. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 118 If the three-conductor AC power cable is not connected properly, you may get an electric shock. The power cable must be plugged into an approved three-contact electrical outlet with the grounding wire reliably connected to an electrical ground (safety ground) at the power outlet. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 119 Verify that the length of an electric cable connected to a TPE bushing does not exceed 100 m. Make sure the TPE bushing of the system is connected only to safety extra low voltage circuits (SELV circuits). If in doubt, ask your system administrator. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 120 Cables that are not installed securely can cause injuries due to entanglement or tripping. Make sure cables are securely installed. Never change the system’s cabling as delivered by Emerson. The cabling should follow existing cable paths using existing or similar cable fastenings. Check proper function of the system after cabling extensions.
  • Page 121 To avoid short circuits and electric shock, the power lugs must not be energized before removing the screws. It is essential to ensure that the power lugs are not energized before loosening the screws. Be careful with the used tools in order to prevent a short circuit. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 122 Applying reversal power to the PEM causes damage to the electrolytic capacitors of the filter. This is indicated by the red reverse power LED. Only push the breakers to the ON position if the reverse power LED (red) is not lit. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 123 The cooling system is designed to provide sufficient cooling with a single fan tray at work. However, under bad conditions or due to a failure of the remaining fans, the cooling capacity of a single fan tray may not suffice. Perform the fan tray replacement without delays. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 124 The centrifugal forces make the unit difficult to handle. To prevent injury keep fingers and tools away from rotating blades in the fan/blower. Do not touch the blades before they have stopped rotating. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 125 If you open the locks too far, they break. Open the locks on both sides of the sockets until you feel resistance. Do not open them any further. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 126 Use the handle and face plate when removing the product from the enclosure. Product Damage If you install blades and RTMs in the wrong sequence the blades and RTMs are damaged. First install the RTM, then install the matching blade. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 127: Hot Swap

    Power off the rack before installing or removing the product. Data Loss Removing the product with the blue LED still blinking causes data loss. Wait until the blue LED is permanently illuminated before removing the product. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 128 Safety Notes Data Loss (comment: applies to blades with Emerson-IPMC) Removing the RTM with the system power on and the blue LED on the front blade still flashing causes data loss. Before removing the RTM from a powered system, power down the slot and the front blade’s payload by opening the lower handle of the front blade and wait until the blue LED is permanently ON.
  • Page 129 Data Loss If the battery does not provide enough power anymore, the RTC is initialized and the data in the NVRAM is lost. Replace the battery before seven years of actual battery use have elapsed. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 130 When exchanging the on-board lithium battery, make sure that the new and the old battery are exactly the same battery models. If the respective battery model is not available, contact your local Emerson sales representative for the availability of alternative officially approved battery models.
  • Page 131 Safety Notes Environment Environmental Damage Improperly disposing of used products may harm the environment. Always dispose of used products according to your country’s legislation and manufacturer’s instructions. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 132 Safety Notes MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 133: Sicherheitshinweise

    Anwendungen, lebenserhaltenden Geräten oder in Flugzeugen verwendet werden. Einbau, Wartung und Betrieb dürfen nur von durch Emerson ausgebildetem oder im Bereich Elektronik oder Elektrotechnik qualifiziertem Personal durchgeführt werden. Die in diesem Handbuch enthaltenen Informationen dienen ausschließlich dazu, das Wissen von Fachpersonal zu ergänzen, können dieses jedoch nicht ersetzen.
  • Page 134 Sie sicher, dass ausreichend Schutz vor Störstrahlung vorhanden ist. Die Blades müssen mit der Frontblende installiert und alle freien Steckplätze müssen mit Blindblenden abgedeckt sein. Änderungen, die nicht ausdrücklich von Emerson erlaubt sind, können Ihr Recht das System zu betreiben zunichte machen. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 135 Bevor Sie das Produkt oder elektronische Komponenten berühren, vergewissern Sie sich, daß Sie in einem ESD-geschützten Bereich arbeiten. Beschädigung des Systems Bitte beachten Sie, dass die im Handbuch angegebenen Voraussetzungen erfüllt sein müssen, bevor Sie das System installieren. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 136 Beschädigung des Produktes und der Zusatzmodule Fehlerhafter Ein- oder Ausbau von Zusatzmodulen führt zu Beschädigung des Produktes oder der Zusatzmodule. Lesen Sie deshalb vor dem Ein- oder Ausbau von Zusatzmodulen die Dokumentation und benutzen Sie angemessenes Werkzeug. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 137 System ganz unten und die leichteren weiter oben. Falls der Schaltschrank mit Kippsicherungen ausgestattet ist, stellen Sie sicher, dass diese auch installiert und ausgefahren sind, um einen sicheren Stand des Schranks zu gewährleisten. Beginnen Sie erst danach mit dem Einbau oder der Wartung des Systems. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 138 Beschädigung des Produktes Wenn das System nicht ordnungsgemäß installiert wird, kann es herunterfallen. Zur Befestigung des Systemes müssen Sie Ihre eigene Hardware bereitstellen. Emerson empfiehlt ausdrücklich den Einsatz von Schienen um das Gewicht des Chassis zu sichern. Verletzungsgefahr und Beschädigung des Systems Verhindern Sie ein unbeabsichtigtes Herunterfallen des Systems, das Verletzungen oder Beschädigungen am System zur Folge haben kann.
  • Page 139 Stromschlägen. Alle Abdeckungen müssen während des Systembetriebs an Ort und Stelle bleiben. Beschädigung des Systems Die meisten Entstörgeräte gegen Über- oder Störspannungen können das System durch Störspannungen beschädigen, wenn sie in der üblichen Weise verwendet werden. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 140 Systemteilen führen. Um eine ausreichende Kühlung zu gewährleisten, müssen die Luftfilter mindestens alle sechs Monate ausgetauscht werden. Emerson empfiehlt, die Luftfilter alle 90 Tage auszutauschen. Wie oft Filter ausgetauscht werden müssen hängt von der Umgebung ab, in der sich das System befindet.
  • Page 141 Bevor Sie die PEMs austauschen, sollten Sie die Betriebsspannung des Systems optimieren. Stellen Sie Eingansspannung auf einen Nennwert von -48 V bis -60 VDC ein, um einen uneingeschränkten Systembetrieb während des PEM Austauschs zu gewährleisten. Verletzungen oder Kurzschlüsse Blade oder Stromversorgung MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 142 Produktes führen. Prüfen und ändern Sie die Schaltereinstellungen, bevor Sie das Produkt installieren. Beschädigung des Systems Falsche Jumper-Einstellungen können dazu führen, dass das System nicht mehr funktioniert. Ändern Sie deshalb nie die Einstellungen der Jumper. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 143 Erden Sie das Systemchassis, um das Risiko eines Stromschlags so gering wie möglich zu halten. Falls Sie das System nicht ordungsgemäß erden, kann dies außerdem zu vielfältigen Störgeräuschen, eletrostatischen Entladungen und Interferenzen im Hochfrequenzbereich führen. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 144 Stellen Sie sicher, dass die Kabel sicher installiert sind, um Verletzungen zu vermeiden. Verändern Sie nie die von Emerson ausgelieferte Verkabelung des Systems. Stellen Sie sicher, dass die Verkabelung schon existierenden Kabelführungen folgt und bestehende oder ähnliche Befestigungen verwendet. Überprüfen Sie nach der Erweiterung der Verkabelung, ob das System ordnungsgemäß...
  • Page 145 Die Mini-B USB Kabelverbindung besitzt keine Arretiervorrichtung. Falls Sie das Mini-B USB Kabel versehentlich entfernen, während das Produkt läuft, könnte der Betrieb gestört oder das Produkt beschädigt werden. Stellen Sie sicher, dass das Mini-B USB Kabel ordnungsgemäß mit dem Produkt verbunden ist. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 146 Schrauben unterbrochen sein. Überzeugen Sie sich vor dem Lösen der Schrauben unbedingt, dass die Stromzufuhr unterbrochen ist und während des Austausches unterbrochen bleibt. Vermeiden Sie Kurzschlüsse, indem Sie sehr vorsichtig mit dem Werkzeug umgehen. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 147 Beschädigung der Spannungsversorgungseinheit Wird die Spannungsversorgungseinheit verkehrt angeschlossen, werden die Elektrolytkondensatoren der Filter beschädigt. Den falschen Anschluss zeigt die rote LED "Reverse Power". Schalten Sie die Unterbrecher deshalb nur, wenn die rote LED nicht leuchtet. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 148 Das Kühlsystem ist dafür ausgelegt, auch mit nur einem funktionierenden Lüftermodul ausreichende Kühlung zur Verfügung zu stellen. Unter bestimmten Umständen oder wenn ein verbleibender Lüfter ausfällt, kann es jedoch sein, dass ein Lüftermodul nicht ausreicht. Führen Sie den Lüfteraustausch deshalb ohne Verzögerung aus. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 149 Lüfterschublade aus dem Chassis ziehen, werden die Lüfterschaufeln freigelegt. Sie können verletzt werden, wenn Sie Werkzeuge oder Finger in rotierende Lüfter einführen. Achten Sie deshalb beim Austausch der Lüfterschublade auf die rotierenden Lüfterschaufeln. Berühren Sie die Lüfterschaufeln erst, wenn diese still stehen. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 150 Speichermodul im Steckplatz stecken. Es wird nicht automatisch aus dem Steckplatz ausgehebelt. Öffnen Sie die Justierklemmen an den Seiten der Steckplätze bis Sie einen Widerstand spüren. Öffnen Sie sie nicht weiter, da die Klemmen sonst abbrechen können. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 151 Verhindern Sie eine Systemüberlastung, indem Sie die gesamte aufgenomme Leistung aller eingebauten Komponenten, überprüfen. Stellen Sie sicher, dass der Ausgangsstrom jedes Verbrauchers innerhalb der zulässigen Grenzwerte liegt. Für weitere Informationen lesen Sie die Dokumentation der jeweiligen Komponente. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 152 Datenverlust führen. Warten Sie daher, bis die blaue LED durchgehend leuchtet, bevor Sie das Produkt ausbauen. Beschädigung des Produktes (applies to blades with Emerson-IPMC) Wenn Sie das RTM ausbauen, während das System läuft und die blaue LED auf dem Front Board noch blinkt, können Daten verloren gehen.
  • Page 153 Laserprodukte für das gesamte RTM. Werden diese Bestimmungen nicht eingehalten, so können Verletzungen die Folge sein. Wenn Sie SFP/SFP+-Module betreiben, die als Laserprodukte klassifiziert sind, stellen Sie sicher, dass die entsprechenden Bestimmungen für Laserprodukte eingehalten werden. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 154 Tauschen Sie daher die Batterie nach spätestens einem Jahr aus. Datenverlust Der Austausch der Batterie führt unweigerlich zu Datenverlust bei Bauteilen, die die Batterie als Backup verwenden. Sichern Sie daher alle Daten, die bei Austausch der Batterie verloren gehen. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 155 Wenn SIe die Lithium-Batterie auf dem Produkt austauschen, stellen Sie sicher, dass die alte und die neue Batterie vom gleichen Typ sind. Ist der Batterietyp nicht verfügbar, wenden Sie sich an Emerson um herauszufinden, welcher Batterietyp offiziell alternativ verwendet werden darf.
  • Page 156 Sicherheitshinweise Umweltschutz Umweltverschmutzung Falsche Entsorgung der Produkte schadet der Umwelt. Entsorgen Sie alte Produkte gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)

  • Page 157: Index

    Shipment Inspection functional blocks Single core SMBus Interface and Devices SPI Flash GFX engine standards GPIO Configuration Storage Super I/O Supported Drivers Supported Operating System heat sinks System Memory High humidity HW Monitor MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 158 Index Thermal Requirements VGA, LVDS, LPC, and Audio Interface Trusted Platform Module Video USB Interface Watchdog Timer weight MITX-430/MITX-440-DVI-2E Installation and Use Guide (6806800K37B)
  • Page 160 Precision Cooling Surge & Signal Protection Emerson, Business-Critical Continuity, Emerson Network Power and the Emerson Network Power logo are trademarks and service marks of Emerson Electric Co. All other product or service names are the property of their respective owners.

This manual is also suitable for:

Mitx-440-dvi-2e

Table of Contents
