Port), EPP (Enhanced Parallel Port), or BPP (Bi-Directional
Parallel Port).
ECP Mode DMA Channel
Use this item to assign the DMA Channel under ECP Mode
function.
Parallel Port IRQ
Use this item to assign IRQ to the parallel port.
OnBoard PCI IDE Controller
Use this item to enable or disable either or both of the onboard
Primary and Secondary IDE channels.
ATA/IDE Configuration
The ATA/IDE option can be configured as either "Enhanced
(default)" or "Compatible" in the BIOS configuration. Windows*
98SE and Windows* Me operating systems do not support En-
hanced mode IDE/Serial ATA resources for more than four
devices. If the ATA/IDE option is set to Enhanced mode, the
operating installation will not be able to recognize the drive, and
the installation will fail. Before installing 98SE or Me, the ATA/
IDE configuration must be changed from Enhanced to Compatible
mode
Onboard IDE RAID Controller
ITE8212 RAID ROM provides two modes, RAID Mode and
ATA/ATAPI mode. You can use this item to select one of these
two modes.
Note A: If you use IDE HDD to install your Operating System,
you must manually change RAID ROM to "IDE Mode", or
Onboard IDE RAID Controller 133 ATA RAID to "ATA/ATAPI
Mode".
Note B: If you use IDE CD-ROM to install your Operating
System, you must manually change Onboard IDE RAID
Controller 133 ATA RAID to "ATA/ATAPI Mode".
Chapter 3: BIOS Setup Utility
