Features Setup Page

This page sets up some parameters for peripheral devices
connected to the system.
CMOS SETUP UTILITY – Copyright (C) 1985-2004, American Megatrends, Inc.
OnBoard Floppy Controller
Serial Port1 Address
Onboard IR Port
Parallel Port Address
Parallel Port Mode
ECP Mode DMA Channel
Parallel Port IRQ
OnBoard PCI IDE Controller
ATA/IDE Configuration
Onboard IDE RAID Controller
Ethernet Device
Audio Device
Onboard USB Function
USB Function For DOS
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help
OnBoard Floppy Controller
Use this item to enable or disable the onboard floppy disk drive
interface.
Serial Port1 Address
Use this item to enable or disable the onboard COM1 serial port,
and to assign a port address.
Onboard IR Port
Use this item to enable or disable the onboard IR port function.
Parallel Port Address
Use this item to enable or disable the onboard Parallel port, and
to assign a port address.
Parallel Port Mode (ECP)
Use this item to select the parallel port mode. You can select
Normal (Standard Parallel Port), ECP (Extended Capabilities
