SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL Contents PARTS AND FUNCTIONS OPERATION Platinum Series Manual MAINTENANCE CAUTIONS TROUBLE SHOOTING ● Please read this operation manual before using the air conditioner. Keep this operation manual for future reference. 001053... -
Page 2: Parts And Functions
Parts and Functions Remote controller Indoor Unit POWER/SOFT button is not available for 09k 12k. Loading of the battery Remove the battery cover; Load the batteries as illustrated. 2 R-03 batteries, resetting key (cylinder); Be sure that the loading e" + "/"-"; is in line with th Load the battery,then put on the cover again. -
Page 3: Operation
Operation Base Operation Emergency operation and test operation Emergency Operation: Use this operation only when the remote controller is defective or lost, and with function of emergency running, air conditoner Remote controller can run automatically for a while. When the emergency operation switch is pressed, the " Pi " sound is heard once, which means the start of this operation. -
Page 4: Sleep Operation
Operation Sleep Operation In AUTO mode The unit operaters in corresponding sleep mode Before going to bed,you can simply press the SLEEP adapted to the automatically selected operation button and unit will operate in SLEEP mode and bring mode. you a sound sleep. 4. -
Page 5: Healthy Airflow Operation
Operation For Smart Use of The Air Conditioner Timer On/Off On-Off Operation Set clock correctly before starting TIMER operation. Setting of proper room Do not block the air inlet 1.After unit starts, select your desired operation mode. temperature or outlet 2.Press TIMER button to change TIMER mode. -
Page 6: Maintenance
Maintenance Replacement of Air Purifying Filter (NOTE: Air purifying filter is optional part) ATTENTION: 1.Open the lnlet Grille The white side of the photocatalyst air purifying Prop up the inlet grille by using a filter face outside,and the black side face the unit. small device named grille-support The green side of the bacteria-killing medium air which located in the right side of... -
Page 7: Cautions
Cautions WARNING Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. WARNING Check proper When abnormality such as burnt-small found, Use an exclusive immediately stop the operation button and installation of the power source... -
Page 8: Trouble Shooting
Trouble shooting Cautions Before asking for service, check the following grille of the air Do not obstruct or cover the ventilation first. conditoner.Do not put fingers or any other things into the inlet/outlet and swing louver. Phenomenon Cause or check points Do not allow children to play with the air conditioner .In no When unit is stopped, it won't restart...
