Rm1350
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
!
WARNING
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional infor-
mation consult a qualified installer, serv-
ice agency or the gas supplier.
USA
Service Office
Dometic Corporation
2320 Industrial Pkwy.
Elkhart, IN 46516
Phone: 574-294-2511
825127002
(French 825127052)
©2006-2007 Dometic Corporation
LaGrange, IN 46761
®
Corporate Office
2320 Industrial Parkway Elkhart, IN 46516
For Service Center Assistance
Call: 800-544-4881
USER
manUal
REfRigERatoR foR lP-gaS
& ElEctRic oPERation
POUR vOTRE SéCURITé
Si vous sentez une odeur de gaz:
1. Ouvrez les fenêtres.
2. Ne touchez à aucun interrupteur.
3. Éteignez toute flamme nue.
4. Avertissez immédiatement votre
fournisseur de gaz.
POUR vOTRE SéCURITé
Ne pas entreposer ni utiliser de l'essence
ni d'autres vapeurs ou liquides inflamma-
bles à proximité de cet appareil ou de tout
autre appareil.
!
AVERTISSEMENT
Une installation, un réglage, une modifi-
cation, une réparation ou un entretien non
conforme aux normes peut entraîner des
blessures ou des dommages matériels.
Lisez attentivement le mode d'emploi
fourni avec l'appareil. Pour obtenir de
l'aide ou des renseignements supplémen-
taires, consultez un installateur ou un
service d'entretien qualifié ou le fournis-
seur de gaz.
®
CANADA
Dometic Corporation
46 Zatonski, Unit 3
Brantford, ON N3T 5L8
CANADA
Phone: 519-720-9578
MO-M 0710

Advertisement

Table of Contents
loading

Related Manuals for Dometic RM1350

Summary of Contents for Dometic RM1350

  • Page 1 USER ® manUal Rm1350 REfRigERatoR foR lP-gaS & ElEctRic oPERation FOR YOUR SAFETY POUR vOTRE SéCURITé If you smell gas: Si vous sentez une odeur de gaz: 1. Open windows. 1. Ouvrez les fenêtres. 2. Don’t touch electrical switches. 2. Ne touchez à aucun interrupteur. 3. Extinguish any open flame. 3. Éteignez toute flamme nue. 4. Immediately call your gas supplier. 4. Avertissez immédiatement votre fournisseur de gaz. FOR YOUR SAFETY POUR vOTRE SéCURITé Do not store or use gasoline or other Ne pas entreposer ni utiliser de l’essence flammable vapors and liquids in the ni d’autres vapeurs ou liquides inflamma-...

  • Page 3: Table Of Contents

    Thank you for entrusting us to supply your new quality-guaranteed refrigerator. The refrigerator model RM1350 is to be used as a recreational device designed for storage of foods, frozen foods and making ice. Please, when the refrigerator is not in use as a recreational device, turn the system off and open the door(s).

  • Page 4: Refrigerator Overview

    REfRigERatoR oVERViEW Control panel LED display Ice box Automatic travel latch water dispenser Door compartment Finned plate shelf Drip protection Draining pipe Crispers General view of the appliance. Model shown is equipped with ice maker and water dispenser. The number of shelves and door compartments may vary according to model -  -...

  • Page 5: Control Panel

    REfRigERatoR oVERViEW contRol PanEl ON/OFF button (main power) Press the button to turn the refrigerator on or off. AUTO/GAS mode selector button Press the button to turn the AuTO mode on or off. TEMP. SET button The thermostat has 5 settings where 1 indicates the warm- est and 5 the coldest temperature setting.

  • Page 6: Leveling The Refrigerator

    REfRigERatoR oVERViEW aUtomatic tRaVEl latch lEVEling thE REfRigERatoR Leveling is one of the requirements for proper operation with The refrigerator is equipped with a travel latch that automati- absorption refrigerators. To ensure proper leveling the vehicle cally locks the refrigerator’s doors when the RV’s engine is needs to be leveled only so it is comfortable to live in (no notice- running.

  • Page 7: Operating Instructions

    REfRigERatoR oVERViEW aUto modE / gaS modE aUto modE iS tURnEd off (gaS modE) The system operates on LP gas only. The control system The refrigerator is equipped with a control system where the activates the ignition system and makes three attempts to light user can choose to turn the AuTO mode on or off.

  • Page 8: Ice Maker

    “uP/OFF” position about 1-1/2 hours before departing. This will allow the water in the mold to freeze. WatER diSPEnSER WatER SUPPly Rm1350 Wim  The water supply system must have a minimum pressure of 15 pounds per square inch gauge (psig). A 1/4” diameter •...

  • Page 9: Storage Compartments

    StoRagE comPaRtmEntS ShElVES WARNING EXPLOSION HAZARD. Never store explosive ShElf gUaRdS substances in the refrigerator, such as cigarette To prevent food product containers from shifting, two slid- lighter fuel, gasoline, ether or the like. Failure able retainer bars are mounted on the shelves. These can be to heed this warning could cause an explosion employed to separate the shelf into smaller sections which resulting in death or severe personal injury.
  • Page 10 StoRagE comPaRtmEntS A general description of how to remove and replace the shelves. The number of shelves and posititions may vary between refrigerator models. - 10 -...

  • Page 11: Product Care

    PRodUct caRE clEaning dEfRoSting Always keep the refrigerator clean. Cleaning the refrigerator shut off the refrigerator by pressing the main power is usually done after it is defrosted or put into storage. use ON/OFF button (OFF position). lukewarm weak soda solution to clean the interior liner of the Empty the refrigerator.
  • Page 12 maintEnancE & SERVicE dRaining thE icE makER Drain water from the supply line. Remove the plastic nut and water line from outlet Draining of the ice maker must be performed by qualified side of the water solenoid valve. service personnel only. water, compressed air and AC power Drain water from the line.

  • Page 13: Replacing The Heater

    maintEnancE & SERVicE dRaining thE WatER diSPEnSER ElEctRic EqUiPmEnt Rm1350Wim  REPlacing thE hEatER If there is any possibility that the temperature can drop below The heat necessary for the operation of an absorption cooling freezing where the refrigerator is located, the water supply unit is supplied by an electric heater mounted in a pocket of the system (including the water tank and the water valve) must be boiler system.

  • Page 14: Periodic Maintenance

    maintEnancE & SERVicE PERiodic maintEnancE Remove cover from burner housing. Remove the burner mounting screws and then, the burner as- sembly. chEcking thE connEctionS Remove the wire and flue baffle from the top of the LP gas is a flammable gas which has the potential to create a flue tube.

  • Page 15: Troubleshooting

    tRoUblEShooting If you run into a problem, refer to the troubleshooting table below. SymPtom chEck/REmEdial action The refrigerator has stopped • Immediately turn the refrigerator off and see a Dometic dealer. cooling. Refrigerator or freezer is not • Check the thermostat and adjust if necessary. cold enough •...

  • Page 16: Error Codes

    tRoUblEShooting ERRoR codES For information about error codes, refer to the following table. The codes are displayed flashing (alternating between temperature and message). ERRoR codE infoRmation No communication between display and power modules. The temperature setting will be main- tained at the mid positions. The power module will continually attempt to reestablish operation of the display module.

  • Page 17: Appendix A - Spare Parts

    aPPEndix a - SPaRE PaRtS The following table displays commonly used parts which should be available from your Dometic service Center. SPaRE PaRtS PaRt no Baffle 2932667054 Burner 955001672 Crisper 3851089015 Door shelf 3850973011 Door shelf, lower 3851052013 Electrode 2932781046 heater (420w, 120V) 3850644539 jet, cpl.

  • Page 18: Appendix B - Consumer Support

    aPPEndix b - conSUmER SUPPoRt Dometic website www.dometicusa.com Please visit the website for information and news about Dometic products. you can obtain information about how to get in contact, learn about product care, download manuals, leaflets and warranties. Service and spare parts For service, please contact the service Center Assistance, see the front page of this manual - or - visit the Dometic website to find the location of the nearest Dometic service Center.

  • Page 19: Appendix C - Dometic Warranty

    aPPEndix c - domEtic WaRRanty & maintEnancE SchEdUlE imPoRtant! Valuable dometic Refrigerator Warranty & maintenance Schedule Congratulations, and Thank you for purchasing the industry’s best built and best backed RV Refrigerator. Enclosed you will find important warranty and maintenance information on Dometic’s exclusive three (3) year warranty.
  • Page 20 limitEd thREE-yEaR WaRRanty domEtic REfRigERatoRS THE SELLER NAMED BELOW MAKES THE FOLLOWING WARRANTY WITH RESPECT TO THE DOMETIC PRODUCT: This warranty is made only to the first purchaser (herein after referred to as the “Original Purchaser”) who acquires the product for his own use and is installed and operated within the continental united states and Canada. This warranty will be in effect for three years on parts and freight and two years on labor from the date of purchase by the Origi- nal Purchaser.
  • Page 21 REfRigERatoR oWnER maintEnancE yEaRly REcoRd Date: Date: Dealership: Dealership: Address: Address: City: City: State: Zip: State: Zip: Phone: Phone: Technician: Technician: Cleaned Burner Assembly: Yes / No Cleaned Burner Assembly: Yes / No Cleaned/Check All Terminals Connections: Yes / No Cleaned/Check All Terminals Connections: Yes / No Cleaned/Inspect All Ground Connections:...
  • Page 22 notES...
  • Page 23 PRotEction foR yoUR nEW inVEStmEnt we truly appreciate that you have chosen to purchase a Dometic product for your recreational vehicle and we want to help you protect this wise investment. we at Dometic back our products with one of the most comprehensive warranties in the industry.
  • Page 24 ■ ■ WARRANTY vERIFICATION OWNER CONFIRMATION your prompt registration records your right to protection your completed Owner’s registration card serves as under the terms and conditions of your warranty. confirmation of ownership in the event of product damage or theft. ■ ■ FACTORY COMMUNICATION 3 PLUS 3 SERvICE CONTRACT Returning your card of registering on-line guarantees...
