Symbol LS 3408 Quick Start Manual

LS/DS 3408
Quick Start Guide
http://www.symbol.com/barcode
See Product Reference Guide for more information
Cord Attachment
1

Host Interfaces

NOTE: Cables may vary depending on configuration
RS-232

Troubleshooting

Scanner not working
No power to scanner Incorrect interface cable used
Check system power; Ensure that correct
ensure power supply, interface cable is used
if required, is connected
Scanner decoding bar code, but data not transmitting to host
Scanner not programmed for correct host interface
Check scanner host parameters or edit options
LS/DS 3408 Programming Bar Codes
Set Defaults
SET DEFAULTS
USB Host Types
HID KEYBOARD EMULATION
IBM HAND-HELD USB
RS-232 Host Types
STANDARD RS-232
ICL RS-232
NIXDORF RS-232 MODE A
1
2
2
USB
Scanner Emulation
Interface/power cables are loose
Check for loose cable
connections
Interface cable is loose
Check for loose cable connections
IBM 46XX Host Types
PORT 5B
PORT 9B
Keyboard Wedge Host Types
IBM PC/AT and IBM PC COMPATIBLE
NIXDORF RS-232 MODE B
FUJITSU RS-232
OPOS/JPOS
Variants
3
Laser Scanner
(ER, FZ)
Accessories
4
IntelliStand
1 Tether Plate
2 LED Indicators
3 Scan Window
4 Scan Trigger
3
Keyboard Wedge
Wand Emulation
Scanner not decoding bar code
Scanner not programmed Bar code unreadable
for bar code type
Ensure bar code is not defaced;
try scanning test bar code of same
Ensure scanner is programmed
bar code type
to read type of bar code being
scanned
Scanned data incorrectly displayed on host
Scanner not programmed for correct host interface
Check scanner host parameters or edit options
Digital Scanner
(DS)
Forklift Holder
4
IBM 46XX
Distance between scanner
and bar code incorrect
Move scanner closer to
or further from bar code
Wand Emulation Host Types
SYMBOL WAND
ENABLE CONVERT TO CODE 39
DISABLE CONVERT TO CODE 39
Carriage Return/Line Feed
SCAN OPTIONS
<DATA><SUFFIX>
ENTER
